MYP Sciences Year 5 — Atomic Structure and the Periodic Table
Most students try to memorise the periodic table like a phone book. Don't. Every fact examiners ask for here — melting points, ionisation energies, why lead poisons bones, why sulfur is the odd one out in Period 3 — traces back to just two ideas: how many protons are pulling on the electrons, and how many shells are in the way. Learn to read the table as a map of electron configuration, and 'explain the trend' questions stop being memory tests and start being logic problems you can actually solve under exam pressure.
Overview
Why the periodic table is the ultimate cheat sheet
The periodic table isn't a list you memorise — it's a map of electron configuration. Every trend examiners ask about (radius, ionisation energy, reactivity, melting point) traces back to one thing: how strongly the nucleus holds onto its outer electrons. Get that idea locked in and half your 'explain the trend' marks are already banked.
- Mendeleev built it from patterns in mass and reactivity before anyone knew what a proton was — modern tables are ordered by atomic number (Z), not mass, which is why tellurium (Z=52) sits before iodine (Z=53) despite being heavier.
- Vertical columns = groups (18 of them): same number of valence electrons, similar chemistry.
- Horizontal rows = periods (7 of them): same highest occupied shell, properties change gradually left to right.
- Four 'chapters' get tested here: where an element sits (groups/periods), how properties change around the table (trends), what's inside the atom (subatomic structure), and how electrons are arranged (shells/configurations) — isotopes glue the last two together.
The shape of the chapter
Command terms this topic actually tests
| Command term | What it demands | AO | Mark-earning move |
|---|---|---|---|
| State | give a short factual answer, no explanation required | AO1 | 1 mark for the correct fact/name only — adding reasoning here wastes time, not marks |
| Describe | give a detailed account of a pattern/trend without explaining why | AO1/AO2 | marks need direction + pattern (e.g. 'decreases then increases') — a bare 'it changes' scores zero |
| Deduce | reach a conclusion using data/information given in the question | AO2 | must reference the actual numbers/pattern given, not general theory — examiners check you used THIS data |
| Explain | give reasons using a model or theory (shielding, nuclear charge, structure) | AO2 | needs a causal link word (because/as/since) — repeating the trend without a cause loses the explain marks |
| Justify | give reasons that support a specific placement or conclusion | AO3 | must tie explicitly back to the claim being justified, not just restate a fact |
| Evaluate | weigh strengths and limitations to reach a judgement | AO3 | one-sided answers cap at half marks — examiners want the 'however' |
Key point
Periodic Table Groups and Periods
Rows, columns and the logic behind them
Mendeleev's 1869 table sorted elements by atomic mass and left gaps where properties didn't fit — his boldest move was predicting elements that hadn't been discovered yet. The modern table (fixed by Moseley in 1913) orders elements by atomic number, which is why it's called the Periodic Law: properties repeat periodically when elements are arranged by increasing atomic number.
- Group (vertical column, 1-18): same number of valence electrons, so similar chemical behaviour — every Group 1 metal forms a +1 ion, every Group 17 halogen forms a -1 ion.
- Period (horizontal row, 1-7): same highest occupied shell; for main-group elements, period number = number of occupied shells.
- Block (s, p, d, f): tells you which subshell the last electron entered — Groups 1-2 are s-block, Groups 13-18 are p-block, Groups 3-12 (transition metals) are d-block, lanthanides/actinides are f-block.
- Named families worth knowing by name, not just number: Group 1 alkali metals, Group 2 alkaline earth metals, Group 17 halogens, Group 18 noble gases.
- Periodic Law
- the properties of elements repeat periodically when the elements are arranged in order of increasing atomic number.
- Group
- a vertical column of the periodic table; elements share the same number of valence electrons.
- Period
- a horizontal row of the periodic table; elements share the same number of occupied electron shells.
- Block
- a region of the table (s, p, d, f) named after the type of subshell being filled by the outermost electron(s).
- Valence electron
- an electron in the outermost occupied shell, responsible for most chemical bonding behaviour.
The periodic table by block
Block position tells you which subshell an element's outermost electron occupies.
Mendeleev's prediction that made chemistry a science
Worked example
Using periodic law to check a prediction (Q7-style)
Worked example
Tungsten's position and its melting point (Q3-style)
Group number ≠ number of valence electrons for every group
Assuming Group number always equals valence electron count (true using the modern 1-18 numbering only for Groups 1, 2, and 13-18 — for p-block groups you must subtract 10).
Consequence: Applying 'valence electrons = group number' directly to Group 17 gives 17 electrons, which is wrong — the correct value is 7. This loses the mark whenever a question links group number to valence electrons.
Fix: For p-block groups (13-18), subtract 10 from the group number to get valence electrons (Group 17 → 17 − 10 = 7). For d-block (transition metals, Groups 3-12), this simple rule doesn't apply at all — don't force it there.
Key takeaways
- Groups = columns = same valence electron count = similar chemistry; Periods = rows = same number of occupied shells.
- The modern table is ordered by atomic number (Z), not atomic mass — this fixes anomalies like Te sitting before I.
- s, p, d, f block position directly tells you which subshell the outermost electron occupies.
- Mendeleev's gallium prediction is the classic example of the periodic table as a predictive model, not just a filing system.
Periodic Trends and Element Properties
One cause, four trends
Every trend in this section comes down to a tug-of-war between nuclear charge (pulling electrons in) and shielding (inner electrons blocking that pull). Increase the pull relative to the pushback, and atoms get smaller and hold their electrons tighter. Learn that one sentence and you can derive every row of the trends table instead of memorising it.
- Across a period (left to right): protons increase but shielding stays roughly constant (same shell) → nuclear pull on outer electrons increases → atomic radius decreases, ionisation energy increases, electronegativity increases.
- Down a group (top to bottom): a whole extra shell is added each time → shielding increases faster than any effect of nuclear charge → atomic radius increases, ionisation energy decreases, electronegativity decreases.
- Metallic character (ability to lose electrons) increases down a group and decreases across a period — the mirror image of ionisation energy.
- Reactivity splits by element type: reactive metals (Group 1) get MORE reactive down the group (easier to lose the outer electron); reactive nonmetals (Group 17) get LESS reactive down the group (harder to attract an extra electron through more shielding).
Periodic trends map
Two independent trend directions — across a period and down a group — combine to fix every element's position on each property.
Ionisation energy — the equation examiners actually want
First ionisation energy (IE₁): energy needed to remove one mole of electrons from one mole of gaseous atoms.
- — one mole of gaseous atoms of element M
- — one mole of gaseous +1 ions
Must be gaseous, isolated atoms — this is why IE data is always quoted for the gas phase.
Second ionisation energy (IE₂), and so on for IE₃, IE₄... — each successive IE is always larger than the previous one.
A sudden, disproportionately large jump between two successive IEs signals you've broken into a new inner shell — that jump is the group-number giveaway.
Worked example
Deducing a group from successive ionisation energies (Q5-style)
Worked example
Period 3 melting points and sulfur's anomaly (Q8-style)
Worked example
Reading an investigation from data (Q6-style)
Lead poisoning and periodic radius
Metals vs metalloids vs nonmetals
| Property | Metals (left/centre) | Metalloids (stair-step) | Nonmetals (upper right) |
|---|---|---|---|
| Luster | Shiny | Sometimes shiny | Dull |
| Conductivity | Good conductors (heat & electricity) | Semiconductors | Poor conductors (insulators) |
| Malleability | Malleable and ductile | Brittle | Brittle solids, or gases/liquids |
| Electron behaviour | Lose electrons easily (low IE) | Variable | Gain electrons easily (high electronegativity) |
| Oxide character | Basic oxides | Amphoteric oxides | Acidic oxides |
Trend direction summary
| Property | Across a period (→) | Down a group (↓) |
|---|---|---|
| Atomic radius | Decreases | Increases |
| Ionisation energy | Increases | Decreases |
| Electronegativity | Increases | Decreases |
| Metallic character | Decreases | Increases |
| Reactivity — Group 1 metals | n/a (compare within group) | Increases |
| Reactivity — Group 17 nonmetals | n/a (compare within group) | Decreases |
Frequently confused
| Concept A | Concept B | The distinction that matters |
|---|---|---|
| Atomic radius | Ionic radius | Atomic radius is measured for the neutral atom; losing electrons (forming a cation) shrinks the radius sharply (fewer shells or less shielding), while gaining electrons (forming an anion) increases it — same element, different value depending on charge. |
| Ionisation energy | Electronegativity | Ionisation energy measures how hard it is to REMOVE an electron from an isolated atom (kJ/mol); electronegativity measures how strongly an atom ATTRACTS shared electrons within a bond (relative scale, no units) — one is about losing, the other about pulling. |
| Reactivity of Group 1 metals down the group | Reactivity of Group 17 nonmetals down the group | Metal reactivity increases down the group (easier to lose the outer electron as shielding grows); nonmetal reactivity decreases down the group (harder to attract an extra electron as the nucleus gets further away) — opposite directions, same underlying cause (shielding). |
Reactivity trend for Period 3 metals (Q1-style)
Assuming all Period 3 metals react with water the same way, or that reactivity with water and reactivity with oxygen must rank identically.
Consequence: Blanket statements like 'metals react vigorously with water' are penalised when Al barely reacts with cold water at all — you lose the accuracy mark for not distinguishing Na (violent), Mg (very slow, needs steam), and Al (protected by a thin, unreactive Al₂O₃ oxide layer that prevents water reaching the metal).
Fix: State the pattern AND the reason: reactivity with water decreases Na > Mg > Al because ionisation energy increases across the period (harder to lose electrons to form the hydroxide), and note Al's protective oxide layer as an additional specific factor, not just 'lower reactivity'.
FONCl anchors electronegativity
Electronegativity anchor points
FONCl
The four most electronegative elements in decreasing order: Fluorine > Oxygen > Nitrogen > Chlorine. Use it to quickly check any electronegativity ranking question.
Key takeaways
- All period/group trends reduce to one balance: nuclear charge pulling electrons in vs shielding pushing back.
- Metal reactivity increases down a group; nonmetal reactivity decreases down a group — same cause, opposite direction, because one loses electrons and the other gains them.
- A large jump in successive ionisation energies marks a new inner shell — count electrons before the jump to get the group number.
- Melting point trends across a period follow bonding type (metallic → giant covalent → simple molecular); anomalies like sulfur are explained by molecular size, not periodic position.
Structure of the Atom
What's actually inside
Every atom is built from three particles, and the periodic table is really just a sorted list of how many of each an atom has. Get the three particles and their locations locked in — this is the foundation every later calculation (isotopes, ions, configurations) rests on.
- Nucleus: tiny, dense centre holding protons (+1 charge, mass ≈1 u) and neutrons (0 charge, mass ≈1 u) — accounts for almost all the atom's mass.
- Electron shells: surround the nucleus, hold electrons (−1 charge, negligible mass ≈1/1836 u) — account for almost all the atom's volume.
- Atomic number (Z) = number of protons = defines the element (change Z, change the element).
- Mass number (A) = protons + neutrons (NOT electrons — electrons barely add mass).
- Neutral atom: protons = electrons, so overall charge is zero; an ion has protons ≠ electrons.
- Atomic number (Z)
- the number of protons in the nucleus of an atom; defines the element.
- Mass number (A)
- the total number of protons and neutrons in the nucleus of an atom.
- Nuclide
- a specific type of atom characterised by a fixed number of protons and neutrons, written as .
- Ion
- an atom (or group of atoms) that has lost or gained electrons, giving it an overall positive or negative charge.
Rutherford-Bohr model of a sodium atom
Electron arrangement 2,8,1 for sodium — 1 valence electron in shell 3 is why sodium forms a +1 ion and sits in Group 1.
Nuclide notation and the two whole-number rules
Nuclide notation: A = mass number (top), Z = atomic number (bottom), X = element symbol.
- — mass number = protons + neutrons
- — atomic number = number of protons
Mass number equals atomic number plus number of neutrons.
- — number of neutrons
Mass number vs relative atomic mass
Treating the mass number (A) shown in nuclide notation as identical to the relative atomic mass (Ar) printed on the periodic table.
Consequence: Using 35 (the mass number of the most common chlorine isotope) instead of 35.45 (Ar of chlorine, a weighted average across isotopes) in a calculation gives an answer close in size but marked wrong — examiners check you understand WHY they differ.
Fix: Mass number (A) is always a whole number and belongs to one specific isotope. Relative atomic mass (Ar) is a decimal, weighted-average value across ALL naturally occurring isotopes of that element — use Ar for mole/mass calculations, use A only for identifying a specific isotope.
Key takeaways
- Protons fix the element (atomic number); neutrons can vary (isotopes); electrons balance protons in a neutral atom.
- Mass number = protons + neutrons; relative atomic mass is a separate, weighted-average decimal value.
- Almost all mass sits in the nucleus; almost all volume is empty space occupied by the electron shells.
Isotopes and Relative Atomic Mass
Same element, different mass
Isotopes are the reason the periodic table's mass values are ugly decimals instead of clean whole numbers — chlorine's 35.45 isn't a typo, it's an average across two isotopes that exist in fixed natural proportions.
- Isotopes: atoms of the same element (same Z, same protons) with different numbers of neutrons, so different mass numbers.
- Chemically near-identical (same electron configuration, same reactivity); physically different (different mass, some isotopes radioactive).
- Relative atomic mass (Ar) is NOT a simple average of the mass numbers — it's a weighted average, using each isotope's natural abundance (%) as the weighting.
- Isotope
- atoms of the same element with the same number of protons but a different number of neutrons, giving a different mass number.
- Relative atomic mass (Ar)
- the weighted average mass of the naturally occurring isotopes of an element, relative to the mass of a carbon-12 atom.
- Natural abundance
- the percentage of atoms of an element in a natural sample that are a particular isotope.
Weighted average calculation
Relative atomic mass = sum of (each isotope's mass number × its percentage abundance), divided by 100.
- — relative atomic mass (dimensionless, relative to carbon-12)
Mass spectrum of chlorine
The relative peak heights ARE the abundances used directly in the weighted-average calculation for Ar.
Worked example
Calculating Ar of chlorine from isotopic data
Ar close to a whole number ≠ only one isotope
Key takeaways
- Isotopes share atomic number (protons) but differ in neutron number and mass number.
- Relative atomic mass is a weighted average using isotopic abundance, never a simple average of mass numbers.
- The periodic table's decimal masses exist BECAUSE isotopes occur in fixed natural proportions.
Electronic Configuration and Shell Model
From shells to subshells
The simple shell model (2, 8, 8...) gets you through most of MYP chemistry, but exam questions push further into spdf notation — the same information, written with more precision about exactly which subshell each electron sits in.
- Shell model: electrons fill shells in order; maximum capacity is (shell 1: 2, shell 2: 8, shell 3: 8 for main-group filling order, though it can technically hold 18 once d-orbitals fill later).
- Each shell (except shell 1) splits into subshells labelled s, p, d, f, each with a fixed maximum: s holds 2 electrons, p holds 6, d holds 10, f holds 14.
- Electrons fill the lowest-energy subshell available first (Aufbau principle) — this is why 4s fills before 3d, even though 3 < 4: the order follows energy, not shell number.
- Valence electrons = electrons in the outermost occupied shell — these determine group number and almost all chemical behaviour.
- Shell
- a principal energy level (n = 1, 2, 3...) that an electron can occupy around the nucleus.
- Subshell
- a division within a shell (s, p, d, f), each holding a fixed maximum number of electrons and having its own energy level.
- Orbital
- a region within a subshell that can hold a maximum of 2 electrons.
- Aufbau principle
- electrons fill the lowest-energy available subshell first, before moving to a higher-energy one.
- Valence shell
- the outermost occupied electron shell, whose electrons determine the group number and chemical reactivity.
Shell capacity
Maximum number of electrons a shell can hold, where n is the shell (principal quantum) number.
- — shell number (1, 2, 3...)
Filling order (Aufbau diagonal rule)
Follow the diagonal arrows, not the shell numbers — this is why 4s fills before 3d.
Remembering the Aufbau filling order
Draw the diagonal, don't trust the row number
List subshells in columns s, p, d, f with rows n = 1 to 7 stacked beneath each other, then draw a diagonal arrow sweeping from top-left downward — reading off the arrow gives 1s, 2s, 2p, 3s, 3p, 4s, 3d, 4p... directly, without needing to memorise the sequence by rote.
Worked example
Chlorine's configuration, group and period (Q2-style)
Confusing shell/period number with valence electron count
Reading off the highest n value and using it for BOTH the period AND assuming it equals the valence electron count.
Consequence: For chlorine, n=3 correctly gives Period 3, but valence electrons are 7 (from 3s²3p⁵), not 3 — mixing these up in the same answer contradicts your own working and costs the justification mark.
Fix: Keep the two questions separate: 'which shell number is highest?' → period; 'how many electrons are IN that highest shell (adding across all its subshells)?' → group (count valence electrons directly).
The periodic table's real limitation (Q3(b)-style)
Key takeaways
- spdf notation shows exactly which subshell each electron occupies, filled in Aufbau (diagonal) order, not simple shell-number order.
- Period = highest occupied principal shell number; Group = number of valence electrons in that outer shell.
- 4s fills before 3d — energy order, not shell number order, governs filling.
- Justification questions require you to reference the actual configuration you derived, not just state the known group/period from memory.
Quick Reference
Atomic Structure & Periodic Table — quick reference
Formulas
- nuclide notation: A = mass number, Z = atomic number
- mass number = protons + neutrons
- weighted-average relative atomic mass
- maximum electrons in shell n
- definition of first ionisation energy
Key facts
- Number of groups
- 18
- Number of periods
- 7
- Shell 1 max electrons
- 2
- Shell 2 max electrons
- 8
- Cl electron configuration
- 1s² 2s² 2p⁶ 3s² 3p⁵
Mnemonics
- FONClF > O > N > Cl, decreasing electronegativity anchor points
- Draw the diagonalAufbau filling order 1s, 2s, 2p, 3s, 3p, 4s, 3d... follows diagonal arrows across an s/p/d/f grid, not shell-number order
Don't confuse
- Atomic radius vs Ionic radius: neutral atom vs charged ion — cations shrink, anions grow, relative to the neutral atom
- Ionisation energy vs Electronegativity: energy to REMOVE an electron (kJ/mol) vs strength of ATTRACTING shared electrons in a bond (no units)
- Mass number (A) vs Relative atomic mass (Ar): whole number for ONE isotope vs weighted-average decimal across ALL natural isotopes
Command terms
- Deduce:
- use the given data/pattern explicitly — don't just quote theory
- Explain:
- state the trend AND give the causal mechanism (shielding/nuclear charge)
- Justify:
- tie your reasoning explicitly back to the specific placement/claim
- Evaluate:
- give a limitation as well as a strength — one-sided answers cap marks
Exam checklist
- Can you state group number, period number and block just from an electron configuration?
- Can you explain (not just describe) why atomic radius decreases across a period?
- Can you spot the 'big jump' in successive ionisation energies and convert it to a group number?
- Can you calculate Ar from isotopic abundance data without averaging mass numbers directly?
- Can you write a complete spdf electron configuration and justify group/period from it?
