MYP Year 4 Chemistry — Chemical Reactions and Bonding

29 min readStandardCore unit — assessed through Criterion A (knowing & understanding) data-response questions and Criterion C practical investigations; thermal decomposition and mass-conservation graphs are the most repeated question types

This unit is where MYP examiners stop asking you to describe and start asking you to deduce — from a table of masses, a decomposition temperature trend, or an equation you've never seen before. The four skills that actually get marked: naming a reaction type from evidence (not guessing), predicting what a reactive metal will do, explaining bonding in terms of electrons (not vague 'attraction'), and proving mass is conserved when you balance an equation. Get comfortable with , and displacement reactions — they appear in almost every paper.

Overview

Five ideas run through this whole unit and they build on each other. You classify a reaction by what happens to reactants and products (types of reactions). You predict whether a reaction will even happen using the reactivity series. You explain why substances behave as they do using bonding (electron transfer, sharing, or delocalisation). You describe what's reacting using correct formulas. And you prove nothing is lost or gained using balanced equations and conservation of mass.

  • Every 'deduce' question in this unit wants you to read a pattern from data or an equation — not recall a fact from memory.
  • Thermal decomposition (, , , , ) is the single most-tested reaction across past papers.
  • Bonding questions almost always ask for electron behaviour (transferred, shared, or delocalised) — 'strong attraction' alone earns zero marks.

The shape of the chapter

Command terms that decide your marks in this unit

Command termWhat it demandsAOMark-earning move
IdentifyName the substance/relationship/pattern directly from given data — no explanation needed.Criterion AOne correct word or formula = full marks; adding wrong reasoning doesn't cost marks but doesn't earn them either.
StateGive a short, precise answer with no justification required.Criterion AMarker wants the fact only — e.g. 'ionic bond' or '+1 charge', not a sentence of explanation.
DescribeGive a detailed account of what happens, including the trend/pattern shown by data.Criterion A/CMust reference the actual numbers or observation, not just 'it increases'.
DeduceReach a conclusion using evidence given in the question — the answer isn't stated anywhere, you build it.Criterion CYou must show the working/reasoning link, e.g. ratio calculation, or the mark for the conclusion alone is withheld.
ExplainGive reasons — state what happens AND why, usually referencing particles/electrons/energy.Criterion A/CA correct fact with no mechanism (e.g. 'because they attract') scores half marks at best.
ConstructBuild a balanced equation, graph or model from raw information.Criterion CMissing state symbols or unbalanced coefficients lose the mark even if the formulas are right.
JustifySupport a claim with evidence or reasoning drawn directly from the source given.Criterion C/DYou must quote the equation/data, not just assert the conclusion.

Key point

Almost every mark loss in this unit comes from one habit: stating a fact without linking it to the evidence given. If a question gives you numbers, an equation or an observation, your answer must reference it directly.

Types of Reactions

You classify a reaction by counting reactants and products and watching what breaks apart or joins together. This unit tests four types repeatedly: combination, decomposition, displacement, and combustion. Thermal decomposition dominates past papers because it's easy to test with real lab data — heat a solid, weigh what's left, identify the gas released.

  • Combination (synthesis): two or more reactants → one product. Example: .
  • Decomposition: one reactant → two or more products, usually needs heat, light or electricity as a trigger.
  • Single displacement: a more reactive element kicks a less reactive one out of a compound.
  • Combustion: a substance reacts with oxygen, releasing heat and light — often producing and if it's a fuel containing carbon and hydrogen.
Thermal decomposition
The breakdown of a single compound into two or more simpler substances using heat energy alone.No other reactant is added — heat is the only input.
Combination reaction
A reaction in which two or more reactants join to form a single product.
Displacement reaction
A reaction in which a more reactive element takes the place of a less reactive element in a compound.

Testing the gas products of thermal decomposition

Standard apparatus for identifying gases released during thermal decomposition.

Bunsen burnerRetort stand and clampBoiling tube with solid reactantDelivery tubeGlowing splint (relights = oxygen)Limewater (turns cloudy = carbon dioxide)

General patterns for each reaction type

Combination — two reactants form one product.

Decomposition — one reactant forms two or more products.

Single displacement — a more reactive element replaces a less reactive one.

Double displacement — ions swap partners, often forming a precipitate.

Worked example

Reading the anion–product relationship (based on Q1)

[3]
Thermal decomposition of several ionic compounds gives: , , , . (a) Identify the relationship between the anion in each reactant and the products formed. [2] (b) Deduce the products of the thermal decomposition of magnesium carbonate, .

Worked example

Classifying a reaction from its equation (based on Q6/Q8)

[2]
A red solid is heated strongly and a glowing splint relights at the mouth of the tube: . (a) Identify the two products. (b) Deduce the type of reaction and justify using the equation.

Common mistake

Counting reactants/products incorrectly when one side has a coefficient, e.g. reading as '3 reactants' because of the coefficients.

Consequence: Misclassifies a combination reaction as something else — loses the classification mark even with correct equation copied down.

Fix: Count distinct substances (different formulas), not the numbers in front of them. is two substances (Mg and O₂), not three.

Examiner tip

When a question gives you an equation and asks you to 'deduce the type of reaction', always name the reaction type AND quote the specific evidence (number of reactants vs products) from that exact equation — generic definitions without reference to the given equation are marked as incomplete.

Key takeaways

  • Combination = fewer products than reactants; decomposition = more products than reactants.
  • Thermal decomposition needs only heat — no second reactant is added.
  • The anion in a decomposing ionic compound predicts the gas released; the cation stays behind in a solid.
  • Always justify a classification by pointing at the actual equation given, not a memorised definition.

Reactivity Series and Reaction Predictions

The reactivity series ranks metals by how readily they lose electrons to form ions. It lets you predict two things examiners love to test: whether a displacement reaction will actually happen, and how a metal compound will behave when heated.

  • A more reactive metal will always displace a less reactive metal from its compound in solution — never the reverse.
  • Metals higher in the series form more stable ionic compounds, which means their carbonates need more energy (higher temperature) to decompose.
  • This second point is exactly what's tested with Group 2 carbonate decomposition data — the trend is not random, it tracks reactivity down the group.

Reactivity series and a displacement reaction

The reactivity series (most reactive at top) alongside a real displacement reaction: zinc metal displaces copper from blue copper(II) sulfate solution.

Potassium (most reactive)SodiumCalciumMagnesiumAluminiumZincIronLead(Hydrogen)CopperSilverGold (least reactive)Zinc strip + blue CuSO4 solutionFading blue solution + brown copper deposit

Mnemonic

Please Stop Calling Me A Zoo, I Like Hot Coffee, Says Grandma

First letters give the reactivity series in order: Potassium, Sodium, Calcium, Magnesium, Aluminium, Zinc, Iron, Lead, Hydrogen, Copper, Silver, Gold — most reactive to least reactive.

Worked example

Decomposition temperature trend down Group 2 (based on Q5)

[4]
Decomposition temperatures: 350°C, 825°C, 1100°C, 1360°C. (a) Describe the relationship between decomposition temperature and position in Group 2. (b) Deduce a reason for this trend in terms of reactivity/ion size.

Sacrificial anodes and metal extraction

Ship hulls and underground pipelines are bolted to blocks of zinc or magnesium — metals higher in the reactivity series than iron. The more reactive metal corrodes preferentially ('sacrifices' itself), protecting the iron structure. The same series explains why gold is found as pure nuggets in nature (too unreactive to form compounds easily) while iron must be extracted from ore by displacement with carbon in a blast furnace.

Common mistake

Assuming a displacement reaction will occur just because two different metals are mixed, without checking their relative positions in the series.

Consequence: Predicts a reaction that doesn't happen (e.g. copper + zinc sulfate solution) — loses the prediction mark entirely.

Fix: Always compare positions first: only a metal above another in the series can displace it from solution.

Key takeaways

  • The reactivity series predicts displacement outcomes: higher metal always displaces a lower one from solution.
  • Reactivity increases down Group 1 and Group 2 as outer electrons are lost more easily.
  • More reactive metals form more thermally stable compounds — hence higher decomposition temperatures.
  • This series underpins metal extraction methods and corrosion protection in real engineering.

Ionic, Covalent and Metallic Bonding

Bonding explains why compounds form and why they have the properties they do. The examiner never wants 'strong attraction' as an answer — they want you to say what's happening to electrons: transferred, shared, or set free to roam.

  • Ionic bonding: complete transfer of electrons from a metal to a non-metal, creating oppositely charged ions held by electrostatic attraction.
  • Covalent bonding: non-metal atoms share pairs of electrons to complete their outer shells — no ions are formed.
  • Metallic bonding: metal atoms release their outer electrons into a shared 'sea' of delocalised electrons surrounding a lattice of positive ions.
Ionic bond
The electrostatic force of attraction between oppositely charged ions, formed when electrons are transferred from a metal atom to a non-metal atom.
Covalent bond
A bond formed when two non-metal atoms share one or more pairs of electrons to achieve a stable outer electron shell.
Metallic bond
The electrostatic attraction between a lattice of positive metal ions and a 'sea' of delocalised electrons that move freely throughout the structure.

Electron transfer forming sodium chloride

One outer electron from each sodium atom transfers to a chlorine atom, forming Na+ and Cl- ions held together by ionic bonding.

Na atom (2,8,1)Cl2 moleculeArrow showing electron transferNa+ ionCl- ion

Metallic bonding — the electron sea model

Positive metal ions sit in a fixed lattice while delocalised electrons move freely between them, explaining conductivity and malleability.

Positive metal ionDelocalised electronElectrostatic attraction

Worked example

Ionic bond formation from electron transfer (based on Q7)

[4]
Sodium transfers one electron to chlorine. (a) State the charges on the ions formed and explain how this electron transfer leads to the formation of an ionic bond. (b) Explain why this reaction is classified as a combination reaction, referring to the number of reactants and products.

Ionic vs covalent vs metallic bonding

FeatureIonicCovalentMetallic
Particles bondingMetal + non-metal atomsNon-metal + non-metal atomsMetal atoms only
Electron behaviourTransferred completelyShared in pairsDelocalised across whole structure
Structure formedGiant ionic latticeSimple molecules or giant covalent latticeGiant metallic lattice
Melting pointHigh (strong electrostatic forces)Low for simple molecules, very high for giant covalentGenerally high
Conducts electricity?Only molten or in solution (free ions)No (no free charged particles)Yes, always (free delocalised electrons)
ExampleNaCl, Cu, Fe, Mg

Bonding mix-ups examiners specifically test

Concept AConcept BThe distinction that matters
Ionic bondCovalent bondIonic = electrons fully transferred (metal + non-metal); covalent = electrons shared (non-metal + non-metal).
MoleculeFormula unit / ionic latticeCovalent substances form discrete molecules (e.g. ); ionic compounds form a continuous lattice, so 'NaCl molecule' is always wrong — it's a formula unit.
IonAtomAn ion is charged because it has unequal protons and electrons after transfer/gain/loss; an atom is neutral.

Common mistake

Calling an ionic compound like NaCl 'a molecule of sodium chloride'.

Consequence: Marked wrong even if the rest of the bonding explanation is correct — examiners specifically flag this as a structural misconception, not just wording.

Fix: Use 'formula unit' or describe the giant ionic lattice — never 'molecule' for an ionic compound.

Key takeaways

  • Ionic bonding = electron transfer between metal and non-metal, producing oppositely charged ions.
  • Covalent bonding = electron sharing between non-metals, no ions formed.
  • Metallic bonding = delocalised electrons moving freely around a lattice of positive metal ions, explaining conductivity and malleability.
  • Never describe bonding as just 'attraction' — name the electron behaviour every time.

Chemical Formulas and Equations

A correct formula comes from balancing charges, not guessing subscripts. For ionic compounds, the total positive charge must equal the total negative charge — the criss-cross method gives you this automatically. State symbols then tell the reader the physical state of every substance at the moment of reaction, which examiners test directly.

  • State symbols: solid, liquid, gas, aqueous (dissolved in water).
  • Word equations describe the reaction in words; symbol equations show formulas and must be balanced with state symbols to score full marks.
  • Ionic charges must cancel to zero in the final formula — that's the whole logic behind criss-crossing.
Empirical formula
The simplest whole-number ratio of atoms of each element in a compound.
Molecular formula
The actual number of atoms of each element present in one molecule of a covalent compound.
State symbol
A bracketed letter after a formula showing the physical state of that substance under the reaction conditions: (s), (l), (g), (aq).

Criss-cross method for ionic formulas

The charge on each ion becomes the subscript of the other ion (ignoring the sign), giving the simplest whole-number formula.

Mg2+Cl-Crossed arrows swapping charge numbersMgCl2

Common ions for formula writing

Ion nameSymbolCharge
SodiumNa++1
PotassiumK++1
CalciumCa2++2
MagnesiumMg2++2
AluminiumAl3++3
Copper(II)Cu2++2
ChlorideCl--1
OxideO2--2
HydroxideOH--1
CarbonateCO3 2--2
NitrateNO3--1
SulfateSO4 2--2

Worked example

Constructing an equation with state symbols (based on Q3)

[2]
Hydrogen peroxide solution decomposes into liquid water and oxygen gas when heated. (a) Construct the balanced equation, including state symbols. (b) Explain what the state symbol indicates about the oxygen produced.

Common mistake

Using for hydrogen peroxide solution instead of , because 'it looks like a liquid'.

Consequence: State symbol mark lost — specifically means dissolved in water, which is what 'hydrogen peroxide solution' means; is reserved for pure liquids.

Fix: Ask: is this a solution (dissolved in water) or a pure substance? Solutions are always , never .

Examiner tip

'Construct' means build the full equation from scratch — formula, balance, AND state symbols all in one answer. Losing any one of these three loses the mark even if the other two are perfect.

Key takeaways

  • Ionic formulas come from balancing charges to zero — use the criss-cross method, then simplify the ratio.
  • State symbols are examined explicitly: , , , — know exactly what each means physically.
  • A 'construct' answer needs correct formulas, balanced coefficients, and state symbols together.

Balancing Equations and Conservation of Mass

The law of conservation of mass says atoms are never created or destroyed in a chemical reaction — they're only rearranged. That means the total mass of reactants must exactly equal the total mass of products, and a balanced equation is just this law written in symbols.

  • Balance by changing coefficients (the big numbers in front of formulas) — never touch subscripts, because that changes what the substance actually is.
  • If a solid decomposes and you know the mass of solid product left, the 'missing' mass tells you the mass of gas that escaped.
  • A graph of product mass against reactant mass that passes through the origin as a straight line proves a fixed, constant ratio between them — exactly what conservation of mass predicts.

Law of conservation of mass

Total mass before reaction equals total mass after reaction — no atoms are gained or lost.

Memorise

For a decomposition where a gas escapes, the mass 'lost' from the solid equals the mass of gas released.

Mass of CuO produced vs mass of CuCO3 decomposed

The straight line through the origin shows mass of CuO is directly proportional to mass of CuCO3 decomposed, with a constant gradient of 0.6.

x-axis: Mass of CuCO3 (g), 0 to 10y-axis: Mass of CuO (g), 0 to 6Data points (2.0, 1.2), (4.0, 2.4), (6.0, 3.6), (8.0, 4.8)Line through originGradient = 0.6

Worked example

Extracting a mass ratio from the graph's gradient (based on Q2)

[3]
A student decomposes CuCO3 and records: mass CuCO3 (g) = 2.0, 4.0, 6.0, 8.0; mass CuO (g) = 1.2, 2.4, 3.6, 4.8. (a) Deduce the relationship between mass of CuO and mass of CuCO3. (b) Construct the balanced equation for this decomposition.

Worked example

Balancing without breaking conservation of mass

[2]
Balance:

Common mistake

Balancing an equation by changing subscripts instead of adding coefficients in front of formulas.

Consequence: Even if the atom counts happen to match, this creates a different (often non-existent) substance and scores 0 marks for the whole equation.

Fix: Only ever change the big number written in front of a formula. If you need to touch a subscript, you've made an error somewhere else — go back and recheck.

Cement production and the mass of CO2 released

The thermal decomposition of limestone, , is the key chemical step in making cement. Global cement production exceeds 4 billion tonnes a year, and because of conservation of mass, roughly 1 tonne of is released for every tonne of cement clinker made — this reaction alone accounts for about 8% of global emissions. Engineers are exploring carbon capture at cement plants and alternative binders precisely because you cannot 'balance away' this mass — every atom of carbon in the limestone has to go somewhere.

Examiner tip

When a question links mass data to conservation of mass, always show the atom-count check (or the mass-lost-as-gas calculation) explicitly — stating 'mass is conserved' without the numbers backing it up only earns partial credit.

Key takeaways

  • Conservation of mass: total mass of reactants = total mass of products, always.
  • Balance equations using coefficients only — changing subscripts creates a different substance and voids the answer.
  • A straight-line graph through the origin for product mass vs reactant mass proves direct proportion; its gradient is the experimental mass ratio.
  • Mass 'lost' from a solid during decomposition equals the mass of gas released — useful for calculating gas mass without weighing it directly.

Quick Reference

Chemical Reactions and Bonding — everything on one page

Formulas

  • Combination reaction
  • Decomposition reaction
  • Single displacement (more reactive metal wins)
  • Law of conservation of mass
  • Mass of escaped gas in decomposition

Key facts

Reactivity series (most to least reactive)
K, Na, Ca, Mg, Al, Zn, Fe, Pb, (H), Cu, Ag, Au
Carbonate decomposition products
Metal oxide + CO2
Hydroxide decomposition products
Metal oxide + H2O
Chlorate/peroxide decomposition products
Metal chloride/water + O2
State symbols
(s) solid, (l) liquid, (g) gas, (aq) aqueous

Mnemonics

  • Please Stop Calling Me A Zoo, I Like Hot Coffee, Says GrandmaReactivity series order: Potassium, Sodium, Calcium, Magnesium, Aluminium, Zinc, Iron, Lead, Hydrogen, Copper, Silver, Gold.

Don't confuse

  • Ionic bond vs Covalent bond: Ionic = electrons transferred (metal + non-metal); covalent = electrons shared (non-metal + non-metal).
  • Combination vs Decomposition: Combination has fewer products than reactants; decomposition has more products than reactants.
  • Molecule vs Ionic formula unit: Covalent substances exist as molecules; ionic compounds exist as a lattice described by a formula unit, never a 'molecule'.

Command terms

Identify/State:
Give the fact only — no reasoning needed or rewarded.
Describe:
Report the observed pattern using the actual numbers/observations given.
Deduce:
Build a conclusion from evidence in the question — show the calculation or logical link.
Explain:
State what happens AND the particle/electron-level reason why.
Construct:
Produce a full balanced equation with correct formulas AND state symbols.
Justify:
Support your claim by quoting the specific equation/data given in the question.

Exam checklist

  • Can I name the anion→gas pattern for carbonate, hydroxide, chlorate and peroxide decomposition?
  • Can I predict a displacement reaction outcome using the reactivity series, not guesswork?
  • Do I explain bonding using electron transfer/sharing/delocalisation every time, never just 'attraction'?
  • Do I always include state symbols in a constructed equation?
  • Do I balance using coefficients only, never subscripts?
  • Can I read a direct-proportion relationship off a graph and state both 'proportional' and the numerical ratio?
