Matter And the Particle Model

Cover illustration for Matter And the Particle Model (Chemistry MYP Year 4).
MYP · Chemistry MYP Year 4

Matter And the Particle Model

24 min readStandardFoundational unit — nearly every MYP Y5 Chemistry paper has at least one data-based question testing particle spacing/motion reasoning, and it feeds directly into IB DP Chemistry's particulate model of matter

Every question in this unit is doing the same job in disguise: it gives you something you can measure — a volume change under pressure, a density value, a temperature that won't budge while heating continues, a smoke particle jittering under a microscope — and asks you to explain it using particle spacing, particle motion and the forces between particles. Learn to read data tables this way and the whole unit stops being separate facts and becomes one repeated argument.

Overview — the particle model as one repeated argument

All matter — the copper block, the water and the air trapped in a syringe — is built from particles that never stop moving. What actually differs between solid, liquid and gas is just three things: how close the particles are packed, how strongly they pull on each other, and how much energy they have to move around. Every worked example in this unit is really asking you to link one of those three things to a real observation.

  • Solid: particles locked in fixed positions, vibrating on the spot — strong forces, minimal spacing, fixed shape and volume.
  • Liquid: particles still close together but free to slide past one another — fixed volume, no fixed shape.
  • Gas: particles far apart with negligible forces between them, moving fast and randomly in every direction — no fixed shape or volume.
  • The examiners' favourite move: give you raw numbers (density, % volume change, spacing) and make YOU work out the state. 'Gases are compressible' memorised alone never scores full marks — you must use the numbers given.

The shape of the chapter

Command term guidance

Command termWhat it demandsAOMark-earning move
DeduceReach a conclusion using information given — must use specific numbers/observations from the question.Data analysisNo mark for the correct conclusion alone; the cited figure earns the mark.
ExplainGive reasons using cause-and-effect language linking observation to particle behaviour.ApplicationMark is for the causal link ('because... therefore...'), not for restating the fact.
DescribeState what is observed/true in detail, no reasons required.KnowledgeExtra reasoning doesn't lose marks here but won't add any either.
JustifyGive evidence-based reasons that support a specific stated claim.AnalysisMust reference the exact claim in the question, not general theory.
EvaluateWeigh strengths and limitations to reach a balanced judgement.EvaluationOne-sided answers (only benefits or only drawbacks) cap at half marks.
CompareGive similarities AND differences between two or more things.AnalysisListing features of each separately with no direct link between them loses marks.
DistinguishState the difference(s) between two similar concepts.AnalysisTwo separate definitions with no explicit point of difference scores zero.

Key point

Every mark in this topic rewards linking an observation (compressibility %, density, diffusion distance, a flat line on a heating curve) back to particle spacing and particle motion — naming the state alone never earns full marks.

  1. States of Matter — Solids, Liquids, Gases

This is the most heavily tested part of the unit because it's the easiest one to attach real data to. A syringe experiment (copper, water, air under pressure) or a table of densities does the same job either way: it forces you to connect a measurable, macroscopic quantity to particle spacing you can't see directly.

  • Compressibility (how much volume shrinks under pressure) depends almost entirely on empty space between particles — gases have huge empty space, solids and liquids have almost none.
  • Density tells the same story from a different angle: mass per unit volume is low when particles are far apart and high when they're packed tightly.
  • Shape and volume behaviour follow directly from how free particles are to move: solids hold shape and volume, liquids hold volume but flow to fit a container's base, gases expand to fill whatever container they're given.
  • Don't confuse 'particles are far apart' (the real reason gases compress) with 'particles move fast' — even an extremely fast-moving particle locked in a solid lattice can't squeeze the solid smaller, because there's simply no gap for it to move into.

Particle arrangement in a solid, liquid and gas

Same particles, three different amounts of order and spacing — that spacing is the only real difference between the states of the same substance.

Solid — regular fixed lattice, vibration onlyLiquid — irregular, close-packed, particles slide past each otherGas — widely spaced, random rapid motion in all directions
Solid
A state of matter in which particles are held in fixed positions by strong attractive forces and can only vibrate — giving fixed shape and fixed volume.Locked in place, jiggling only.
Liquid
A state of matter in which particles are close together but have enough energy to move past one another — giving fixed volume but no fixed shape.Takes the shape of its container, keeps its volume.
Gas
A state of matter in which particles are far apart with negligible forces between them, moving rapidly and randomly — giving no fixed shape and no fixed volume.Expands to completely fill any container.
Compressibility
A measure of how much a substance's volume decreases under applied pressure; large for gases (lots of empty space between particles), essentially zero for solids and liquids (particles already touching).
Density
Mass per unit volume (); reflects how tightly packed a substance's particles are.

Comparing the three states of matter

PropertySolidLiquidGas
ShapeFixedTakes shape of containerFills entire container
VolumeFixedFixedVariable — expands to fill space
Particle spacingVery close, touchingClose, touchingVery far apart
Particle arrangementRegular, ordered latticeIrregular, random but closeIrregular, random, widely spread
Particle motionVibrate about fixed pointsSlide past each otherMove fast in straight lines until collision
CompressibilityPractically noneVery slightly compressibleHighly compressible
Relative densityUsually highestUsually intermediateUsually lowest (~1000× less than liquid)

Worked example

Deducing the gas from syringe data

[5]
A student sealed a copper block (20.0 mL), 50.0 mL of water, and 50.0 mL of air in three separate syringes. A pressure of 200 kPa was applied to each plunger. Results: Copper 20.0 → 20.0 mL; Water 50.0 → 49.9 mL; Air 50.0 → 25.0 mL. (a) Deduce which substance is a gas, using the data to support your answer. [2] (b) Using the particle model, explain why air compresses so much more than water or copper. [3]

Common mistake

Explaining compressibility using particle speed ('gas particles move fast so they compress easily') instead of particle spacing.

Consequence: This loses the explanation mark even though it sounds plausible — examiners specifically check for 'empty space between particles'; speed-based answers are marked as a misconception, not partial credit.

Fix: Anchor compressibility answers to empty space between particles. Quick check: 'could pressure physically push particles into a gap that already exists?' — yes for gas, no for solid/liquid.

Examiner tip

Whenever a question gives a table of volumes, densities, or percentages, treat it as a 'deduce' question even if the wording says 'explain' — quote at least one number from the table, or you cap at half the available marks.

Key takeaways

  • State is decided by particle spacing + particle motion, not by which substance it is — the same substance (H₂O) can be solid, liquid or gas.
  • Compressibility and density are the two properties examiners use as indirect evidence of particle spacing — learn to read them both ways (data → state, and state → predicted data).
  • Gas ≠ 'particles move fast'; gas = 'particles are far apart'. Speed explains diffusion rate and temperature, not compressibility.

  1. Particle Model and Kinetic Theory

Kinetic theory is the set of assumptions that turns the particle model from a description into an explanation: particles are always moving, that motion is random, and how fast they move on average is controlled directly by temperature. Examiners use this section to test whether you understand WHY particles behave as described in Section 1, not just that they do.

  • Core assumptions: matter is made of particles in constant, random motion; collisions between particles conserve overall kinetic energy (elastic collisions); the particles' own volume is negligible compared to the space they occupy — a good approximation for gases, a poor one for solids and liquids.
  • Average kinetic energy of particles is directly proportional to absolute temperature (Kelvin) — raise the temperature, average particle speed rises, though not every single particle speeds up equally.
  • This is why temperature must be converted to Kelvin before reasoning about kinetic energy — 0°C does not mean 'no motion'; 0 K (absolute zero) theoretically does.
  • Forces between particles (strongest in solids, weakest in gases) combine with spacing to determine compressibility, diffusion rate, and how easily a substance changes state — kinetic theory is the thread tying Sections 1, 3 and 4 together.

Converts a Celsius temperature to Kelvin — the absolute scale kinetic theory uses.

— absolute temperature (K)
— Celsius temperature (°C)
Memorise

Average kinetic energy of particles is directly proportional to absolute temperature — double the Kelvin temperature, double the average KE.

— average kinetic energy of particles (J)

This describes a population average — some particles move faster, some slower, at any given temperature.

Kinetic theory
A model stating that all matter is composed of particles in continuous, random motion, and that the average kinetic energy of these particles increases with absolute temperature.
Absolute zero
0 K (−273°C), the theoretical temperature at which particle motion is at an absolute minimum.
Elastic collision
A collision in which kinetic energy is conserved overall — assumed in kinetic theory so particles don't gradually lose energy from colliding.

Worked example

Sorting compressibility data into states

[4]
Four unknown samples were tested for compressibility under a fixed applied pressure: Sample A 0.1% decrease; Sample B 35%; Sample C <0.01%; Sample D 28%. (a) Deduce which samples are gases, justifying with particle arrangement theory. [2] (b) Explain how the data for samples A and C are consistent with them being the same broad category of state, even though their % values differ slightly. [2]

Frequently confused

Concept AConcept BThe distinction that matters
TemperatureHeat (thermal energy transferred)Temperature measures the AVERAGE kinetic energy of particles (intensive — doesn't depend on amount); heat is the total energy transferred between objects (depends on mass) — a cup and a swimming pool of water at the same temperature hold wildly different amounts of heat energy.

Key point

Kinetic theory's assumptions are simplifications. 'Negligible particle volume' and 'no forces between particles' fit gases well but fit liquids and solids poorly — expect occasional questions asking you to spot where the model is a weaker match.

Key takeaways

  • Kinetic theory gives you the WHY behind Section 1's observations: random particle motion, average speed set by absolute temperature.
  • Always convert to Kelvin before reasoning about kinetic energy — Celsius has no direct proportional relationship to KE.
  • 'Deduce which are gases' from compressibility data is really asking you to spot the order-of-magnitude jump between gas values (tens of %) and solid/liquid values (well under 1%).

  1. Changes of State and Energy Transfer

Every change of state is a physical change where energy transfers in or out but particles keep their identity — melting ice is still H₂O, not a new substance. The trap examiners set here is the 'plateau': temperature holding steady while energy is clearly still being supplied. Explaining why temperature doesn't rise during a phase change is the single most-tested idea in this section.

  • Melting (solid→liquid) and freezing (liquid→solid) happen at the melting point; boiling/vaporisation (liquid→gas, energy IN) and condensation (gas→liquid, energy OUT) happen at the boiling point; sublimation (solid→gas) and deposition (gas→solid) skip the liquid state entirely (dry ice, frost forming from water vapour).
  • Evaporation differs from boiling: it happens at ANY temperature, only at the liquid's surface, and only affects the highest-energy particles — boiling happens throughout the whole liquid, at one fixed temperature.
  • During a phase change, energy supplied goes entirely into weakening/breaking (melting, boiling) or strengthening/forming (freezing, condensing) forces between particles — NOT into speeding particles up. That's why temperature stays flat on a heating curve during melting and boiling.
  • Once the phase change is complete, further energy input goes back into raising kinetic energy — and temperature starts rising again.

Heating curve for a pure substance (ice → water → steam)

Both flat plateaus are periods where energy input is converting to potential energy (breaking intermolecular forces), not kinetic energy — notice the boiling plateau is much longer than the melting one.

Solid heating (KE increasing)Melting plateau at 0°C (PE increasing, KE constant)Liquid heating (KE increasing)Boiling plateau at 100°C (PE increasing, KE constant) — longer than the melting plateauGas heating (KE increasing)
Melting point
The fixed temperature at which a solid changes to a liquid (equal to the freezing point of the same substance).
Boiling point
The fixed temperature at which a liquid changes to a gas throughout its whole volume.
Evaporation
The escape of higher-energy particles from the surface of a liquid into the gas state, occurring at any temperature below the boiling point.
Sublimation
The direct change from solid to gas without passing through the liquid state (e.g. solid CO₂ / dry ice).
Latent heat
Energy absorbed or released during a change of state at constant temperature, used entirely to change the strength of forces between particles rather than their kinetic energy.

Worked example

Reading a heating curve

[3]
A pure solid is heated at a constant rate. Its temperature rises steadily, then holds flat at 80°C for several minutes even though heating continues, then rises again. (a) Identify what is happening during the flat section. [1] (b) Explain, in terms of particle energy, why the temperature does not rise during this section even though heat is still being supplied. [2]

Common mistake

Assuming a flat line on a heating curve means 'nothing is happening' or 'no energy is being transferred'.

Consequence: Loses the explanation mark — the plateau is a period of intense particle rearrangement, not zero activity; examiners specifically reward mentioning continued energy transfer.

Fix: State explicitly: 'energy is still being transferred, but it's going into breaking/forming forces between particles, not increasing their kinetic energy.'

Examiner tip

When comparing the melting plateau to the boiling plateau on the same heating curve, the boiling plateau should almost always be longer — far more energy is needed to fully separate particles into a gas than to loosen them into a liquid. If asked to explain the length difference, this is the point to make.

Compressed fuel and industrial refrigerants

Compressed natural gas (CNG) buses store fuel at up to 200 atm precisely because gas is so compressible — huge volumes of methane packed into a manageable cylinder — but that same compressibility (lots of stored energy in a small space) is the safety limitation: a cylinder rupture releases a large volume rapidly. Industrial refrigeration faces a similar trade-off: HFC refrigerants compress easily and are non-toxic but carry a high global warming potential if leaked; ammonia is a natural, zero-GWP refrigerant whose stronger intermolecular forces and toxicity demand strict handling protocols — the same particle-level properties that make a substance useful also define its risks.

Key takeaways

  • A flat section on a heating/cooling curve = phase change in progress; energy is still transferring, just into potential (bond) energy, not kinetic energy.
  • Boiling needs more energy than melting for the same substance because it fully separates particles rather than just loosening their fixed positions — expect a longer plateau.
  • Evaporation ≠ boiling: evaporation happens at the surface, at any temperature; boiling happens throughout the liquid, at one fixed temperature.

  1. Diffusion and Brownian Motion

Diffusion and Brownian motion are the two pieces of evidence examiners use to prove particles are real and moving, even though no one can see an individual atom or molecule. They test the same underlying idea — constant random particle motion — from two different angles: diffusion is what you observe happening to a substance; Brownian motion is what you observe happening to a much larger visible particle bombarded by invisible smaller ones.

  • Diffusion: the net movement of particles from a region of higher concentration to lower concentration, driven by random motion — no stirring or outside force needed.
  • Diffusion rate rises with higher temperature (faster random motion) and falls with larger/heavier particles (more inertia, slower average speed at a given temperature); it's fastest in gases, slower in liquids, essentially absent in solids.
  • Brownian motion: the random, jittery, zigzag movement of a relatively large visible particle (smoke particle, pollen grain) suspended in a fluid, caused by constant unequal bombardment from the fluid's much smaller, invisible, fast-moving particles.
  • Brownian motion is historically important evidence that atoms/molecules genuinely exist and move — you can't see air or water molecules doing the hitting, but you can see the effect on something big enough to watch under a microscope.

Brownian motion of a smoke particle in air

The zigzag path of the visible smoke particle is caused by unequal, random collisions from air molecules too small to see — direct evidence of constant random particle motion.

Large visible smoke particleInvisible fast-moving air molecules (much smaller)Random zigzag path of the smoke particle over time
Diffusion
The net movement of particles of a substance from a region of higher concentration to a region of lower concentration, as a result of their random motion.
Brownian motion
The random, irregular movement of visible particles suspended in a fluid, caused by collisions with the fluid's much smaller, invisible, fast-moving particles.
Concentration gradient
The difference in concentration of a substance between two regions, which drives net diffusion until the substance is evenly spread.

Worked example

Ammonia and hydrogen chloride diffusion tube

[3]
Cotton wool soaked in concentrated ammonia solution is placed at one end of a glass tube and cotton wool soaked in concentrated hydrochloric acid at the other end, simultaneously. Both gases diffuse along the tube and react to form a white ring of ammonium chloride where they meet — the ring forms noticeably closer to the hydrochloric acid end. Explain this observation using the particle model. [3]

Diffusion vs Brownian motion

Concept AConcept BThe distinction that matters
DiffusionBrownian motionDiffusion is the net spreading of an actual substance (perfume, dye, gas) down its own concentration gradient, observed at a macroscopic scale; Brownian motion is the random jittery path of ONE visible particle caused by being struck by invisible smaller particles, observed under a microscope — Brownian motion is evidence FOR particle motion, diffusion is a consequence OF particle motion.

Mnemonic

Grandma Loves Soup — Gas fastest, Liquid slower, Solid essentially none

Recall the order of diffusion rate across states: gases diffuse fastest (particles far apart, move rapidly and freely), liquids diffuse more slowly (particles closer together, more collisions), solids show no meaningful diffusion at room temperature (particles fixed in place).

Common mistake

Describing Brownian motion as 'the movement of molecules' rather than the movement of the large visible particle being hit by molecules.

Consequence: Confuses cause and effect — loses the mark for correctly identifying what is actually observed under the microscope.

Fix: State it precisely: the LARGE particle (smoke, pollen) moves randomly BECAUSE it is repeatedly, unevenly struck by much smaller, invisible, fast-moving particles — the small particles themselves are not what you're watching move.

Key takeaways

  • Diffusion = net movement of a substance down its concentration gradient; Brownian motion = random jitter of a large visible particle caused by invisible collisions — don't swap these definitions.
  • Diffusion rate order: gas > liquid > solid, and within a state, lighter particles diffuse faster than heavier ones at the same temperature (same average KE, different speed).
  • Brownian motion is the historical proof that invisible particles are real and moving — describe the visible particle's zigzag path as the EFFECT, not the cause.

  1. Physical vs Chemical Changes

Every change of state from Section 3 is a physical change — melting ice is still H₂O, just rearranged. This final section asks you to draw the line between changes where the substance's identity is preserved (physical) and changes where entirely new substances with new properties are formed (chemical) — a distinction examiners test by giving you a scenario and asking you to justify which type it is.

  • Physical change: no new substance formed, same particles just rearranged (state, shape, size or mixing) — usually easy to reverse (freezing water, dissolving salt, cutting paper, melting wax).
  • Chemical change: new substance(s) formed with different chemical properties from the original — usually hard or impossible to reverse by physical means (burning wood, rusting iron, cooking an egg, a reaction producing a gas or precipitate).
  • Evidence pointing to a chemical change: colour change, gas bubbles produced, a solid precipitate appearing from clear solutions, an unexpected temperature change, and — most reliably — the new substance having different properties (density, melting point, reactivity) from the starting material(s).
  • Mass is conserved in BOTH physical and chemical changes — that's not a useful discriminator; the useful discriminator is always 'is it still chemically the same substance, just rearranged/relocated?'

Physical change vs chemical change

FeaturePhysical changeChemical change
New substance formed?No — same substance, different form/arrangementYes — different substance(s) with new properties
ReversibilityUsually easily reversible (often just by adding/removing heat)Usually difficult or impossible to reverse by physical means
Energy changeOften present (state changes) but no new bonds formed within moleculesBonds broken and formed — often a larger, more noticeable energy transfer
Typical evidenceChange in state, shape, size, or physical appearance onlyColour change, gas produced, precipitate formed, unexpected temperature change
ExamplesMelting ice, dissolving salt, boiling water, cutting woodBurning wood, rusting iron, baking a cake, digesting food
Physical change
A change in which a substance's form, state, size or shape alters but no new substance is produced — the same chemical composition remains throughout.
Chemical change
A change in which one or more new substances form with chemical properties different from the starting material(s), usually via bond breaking and forming.
Reversible change
A change that can be undone to recover the original substance(s), typically by reversing the energy transfer (e.g. re-freezing melted water) — most physical changes are reversible this way.

Frequently confused

Concept AConcept BThe distinction that matters
Dissolving sugar in waterBurning sugar (charring)Dissolving is physical — sugar particles spread among water particles but stay chemically unchanged, and you can recover solid sugar by evaporating the water; burning/charring is chemical — new substances (carbon, water vapour, gases) form with different properties, and no physical process gets the sugar back.

Worked example

Classifying an observation as physical or chemical

[2]
A student heats a strip of magnesium ribbon in a Bunsen flame. It glows brightly white and turns into a brittle grey-white powder. Justify whether this is a physical or a chemical change. [2]

Key takeaways

  • The only reliable test for a chemical change is 'has a new substance with different properties formed?' — colour change and energy release are supporting evidence, not proof on their own.
  • All changes of state (melting, boiling, freezing, condensing, subliming) are physical changes — same substance, different particle arrangement/spacing.
  • Mass conservation applies to both physical and chemical changes, so it can never be used to distinguish between them.

Quick Reference

Formulas

  • Convert before reasoning about kinetic energy
  • Average KE is directly proportional to absolute temperature
  • Density — indirect evidence of particle spacing

Key facts

Melting point = freezing point (same substance)
Same temperature, opposite direction of energy transfer
Absolute zero
0 K = −273°C
Order of diffusion rate
Gas > Liquid > Solid (negligible)

Mnemonics

  • Grandma Loves SoupDiffusion rate order: Gas fastest, Liquid slower, Solid essentially none

Don't confuse

  • Temperature vs Heat: Temperature = average KE per particle (intensive); heat = total energy transferred (depends on amount of substance)
  • Diffusion vs Brownian motion: Diffusion = net spread of a substance down a concentration gradient; Brownian motion = random jitter of one visible particle from invisible collisions
  • Evaporation vs Boiling: Evaporation: surface only, any temperature; Boiling: throughout the liquid, one fixed temperature

Command terms

Deduce:
Quote the actual number/data from the table in your answer
Explain:
Give the causal 'because...therefore' link to particle spacing/motion/forces
Justify:
Support the specific claim given, using evidence, not general theory
Evaluate:
Give both a strength AND a limitation — one-sided answers cap at half marks

Exam checklist

  • Did I quote a number from the data table, not just describe it in words?
  • Did I explain compressibility using particle SPACING, not particle speed?
  • Did I state what energy goes into during a phase-change plateau (potential energy from breaking/forming forces), not just 'nothing happens'?
  • Did I distinguish diffusion (net substance movement) from Brownian motion (jitter of one visible particle)?
  • Did I justify physical vs chemical using 'new substance + irreversibility', not colour change alone?
