MYP Year 4 Sciences: Physics — Work and Energy
Every question in this unit is really the same question wearing different clothes: where did the energy go, and how fast did it get there? A rod conducting heat, a piston squeezing gas, a Sankey diagram for a light bulb, a ball falling off a cliff, a motor lifting a crate, a power station burning coal — all of them are asking you to track joules from one place/form to another without ever letting them appear from nowhere or vanish into nothing.
Overview — The Shape of This Chapter
Work and Energy stitches together six ideas you've met piece by piece: how heat moves (conduction, convection, radiation), how force spreads over area (pressure), how real machines split energy into useful and wasted output, how energy changes form while its total stays fixed, how work/power/efficiency are calculated, and finally where the energy actually comes from (renewable vs non-renewable resources).
- One law underpins everything here: energy is never created or destroyed, only transformed or transferred — 'wasted' energy still exists, it's just spread out as heat that's hard to reuse.
- Heat and temperature are NOT the same physical quantity — mixing them up is the single most common conceptual error in this unit's written answers.
- Real machines are never 100% efficient. If a calculated efficiency comes out above 100%, that's a red flag that input/output values got swapped.
- Resource questions blend physics (how the fuel behaves) with sustainability (whether it runs out) — command terms like Discuss and Evaluate expect both sides.
The shape of the chapter
Command terms that decide your mark
| Command term | What it demands | AO | Mark-earning move |
|---|---|---|---|
| Identify | State the specific name/value/pattern requested | AO1 | Answer must name the exact thing (e.g. 'material' not 'copper is fastest') — vague answers lose the mark. |
| Describe | Give a detailed factual account of what happens | AO1/AO2 | State the sequence/pattern — no reasoning or mechanism required yet. |
| Explain | Give reasons — the mechanism or cause behind an observation | AO2 | Must include the 'because'; a bare description with no causal link scores zero on an Explain command. |
| Calculate | Produce a numerical answer with working shown | AO3 | Method marks live in the working — a correct final number with no steps can still lose marks. |
| Compare | State similarities AND differences between two things | AO2/AO3 | One-sided answers (only differences, or only similarities) are capped at partial credit. |
| Discuss | Present points for and against, balanced | AO3 | Both sides must be weighed — a one-sided 'discussion' is marked as incomplete. |
| Evaluate | Weigh strengths and weaknesses and reach a judgement | AO3 | Must end in a stated conclusion — a list of pros/cons with no verdict misses the top mark band. |
Key point
Heat Transfer: Conduction, Convection, Radiation
All three mechanisms move thermal energy from hot to cold, but the particle-level story behind each one is completely different — and exam answers get marked on whether you can describe THAT story, not just name the mechanism.
- Conduction: energy passes particle-to-particle by vibration and collision. In metals, free (delocalised) electrons carry most of the energy along, which is why metals conduct far better than non-metals like wood or plastic.
- Convection: only happens in fluids. Heated fluid expands, becomes less dense, rises, and is replaced by cooler, denser fluid sinking in — this circulating loop is a convection current.
- Radiation: energy travels as electromagnetic (infrared) waves and needs no medium at all — it's the only mechanism that works through a vacuum, which is exactly how the Sun's energy reaches Earth.
- The rate at which a rod conducts heat depends on four things: thermal conductivity of the material, cross-sectional area , temperature difference across it, and length (a longer/thicker path slows the flow).
- Conduction
- Transfer of thermal energy through a material by particle vibration and collision (plus free-electron movement in metals), with no bulk movement of the material itself.
- Convection
- Transfer of thermal energy through a fluid by the physical movement of heated (less dense) fluid rising and cooler (denser) fluid sinking.
- Radiation
- Transfer of thermal energy as electromagnetic waves, requiring no medium — the only heat transfer mechanism that works through a vacuum.
- Thermal conductivity ()
- A material property (units ) describing how readily it conducts heat; high = fast conductor (metals), low = good insulator (wood, plastic, air).
Rate of heat conduction through a uniform rod or slab
- — rate of heat transfer (power) (W)
- — thermal conductivity (W m^{-1} K^{-1})
- — cross-sectional area (m^2)
- — temperature difference across the rod (K or °C)
- — length of the rod (path the heat travels) (m)
here means joules transferred per second (i.e. power in watts) — don't confuse the dot notation with electric charge .
Heat conduction through a metal rod
The rate of conduction depends on k, A, ΔT and L exactly as in the formula.
Convection current in a heated room
Warm, less-dense air rises; cool, denser air sinks — creating a continuous circulating loop.
Worked example
Comparing copper and aluminium rods (conductivity ratio)
Worked example
Identifying variables in a conduction experiment
Conductivity vs temperature
Describing a material with high thermal conductivity as 'hotter' or saying it 'conducts more heat', rather than describing the correct physical idea: it conducts heat at a faster RATE.
Consequence: In 'identify the trend' questions (e.g. ranking five materials by conductivity), using temperature language instead of rate language gets the trend description marked wrong even when the numbers quoted are correct.
Fix: Thermal conductivity is a fixed material property (like density) — it never changes with how hot something feels. Always phrase trends as 'faster/slower rate of heat transfer', never 'hotter/colder'.
Squaring the radius, not the diameter
The three-word conduction explanation
Wildfires and building material choice
Conduction vs Convection vs Radiation
| Mechanism | Medium required | How energy moves | Typical example |
|---|---|---|---|
| Conduction | Solid (best), or a still fluid | Particle-to-particle vibration/collision; free electrons in metals | A metal spoon heating up in hot coffee |
| Convection | Fluid only (liquid or gas) | Bulk movement of heated, less-dense fluid rising and cooler fluid sinking | A radiator warming a whole room |
| Radiation | None — works through a vacuum | Electromagnetic (infrared) waves | Sunlight warming Earth across empty space |
Thermal conductivities and the metal/non-metal trend
| Material | k (W m⁻¹ K⁻¹) | Class |
|---|---|---|
| Copper | 400 | Metal — excellent conductor (many free electrons) |
| Aluminium | 205 | Metal — good conductor, lighter than copper |
| Glass | 1.0 | Non-metal — poor conductor |
| Wood | 0.15 | Non-metal — good insulator |
| Plastic | 0.05 | Non-metal — excellent insulator |
Frequently confused
| Concept A | Concept B | The distinction that matters |
|---|---|---|
| Heat | Temperature | Temperature is the average kinetic energy of particles (a state); heat is energy transferred between objects due to a temperature difference (a process) — a small spark and a large warm bath can share the same temperature yet have wildly different heat content. |
| Conduction | Convection | Conduction transfers energy with no bulk movement of matter (particles just vibrate in place); convection requires the heated matter itself to physically move from one place to another. |
Mnemonic
No medium, no problem — it's Radiation
If heat crosses a vacuum (space, or the vacuum gap in a thermos flask), it can only be travelling as radiation — conduction and convection both need particles present to carry the energy.
Key takeaways
- Conduction (particle collisions + free electrons in metals), convection (bulk fluid movement), radiation (EM waves, no medium) are mechanistically distinct — never swap their explanations.
- : bigger k, bigger A, bigger ΔT → faster transfer; bigger L → slower transfer.
- Rank materials by conductivity using rate/time data, not by how hot they 'feel'.
- Material choice in engineering (steel vs wood) always trades conductivity against other factors — sustainability, cost, flammability.
Pressure
Pressure is force spread over area — the same force concentrated on a smaller area produces a much larger pressure, which is why a knife cuts and snowshoes don't sink.
- Pressure in a liquid increases with depth, because deeper points support the weight of more fluid stacked above them.
- Atmospheric pressure decreases with altitude, since there's progressively less air above you pressing down.
- In an enclosed fluid, a change in pressure applied at one point is transmitted equally throughout the fluid in all directions — Pascal's principle, the basis of hydraulic systems.
- Hydraulics let you multiply force: a small force on a small piston creates the same pressure as a much larger force spread over a larger piston — but the large piston moves a proportionally smaller distance, so no energy is created for free.
- Pressure
- Force acting perpendicular to a surface, divided by the area over which it acts.
- Pascal (Pa)
- SI unit of pressure; .
- Hydraulic system
- A device using an enclosed, incompressible fluid to transmit and multiply force between two pistons of different area, obeying Pascal's principle.
Pressure equals force divided by the area it acts over
- — pressure (Pa (N/m²))
- — force perpendicular to the surface (N)
- — area (m^2)
Pascal's principle: pressure is transmitted equally through an enclosed fluid, so this lets you find the force multiplication in a hydraulic system
The trade-off: piston 2 moves a smaller distance than piston 1 in exactly the ratio that force is multiplied — total work in equals total work out.
Hydraulic press (force multiplication)
Same pressure throughout the fluid; larger piston area gives a larger output force but moves a smaller distance.
Worked example
Hydraulic car jack
Area units in pressure calculations
Substituting an area given in cm² directly into without converting to m².
Consequence: Since , this leaves the final pressure out by a factor of 10,000 — one of the most common lost marks in pressure calculations.
Fix: Always convert every area to m² first (divide cm² values by 10,000) before substituting into the pressure formula.
Examiner tip
Key takeaways
- — same force over a smaller area gives a much bigger pressure.
- Pressure increases with depth in liquids (weight of fluid above) and decreases with altitude (less air above).
- Pascal's principle lets hydraulics multiply force, but the larger piston always moves proportionally less — energy is conserved, not created.
- Convert areas to m² before any pressure calculation — this is the #1 unit-error mark loss in this topic.
Energy Transformations in Real-World Devices
Every device is an energy converter: it takes energy in one form and converts it into a mix of a useful form (what it's designed to do) and wasted forms (almost always heat, sometimes sound). Sankey diagrams visualise this split, with the width of each arrow drawn proportional to the power or energy it represents.
- Input energy = useful output energy + wasted output energy — the total width of a Sankey diagram never changes, it just splits.
- Wasted energy hasn't disappeared — it's transformed into a form that's harder to make use of, almost always low-grade heat.
- Reading a Sankey diagram means matching the band you're asked about (useful vs wasted) to its correct label — don't assume position (top/bottom) always means the same thing.
- Energy transformation
- The conversion of energy from one form to another, e.g. chemical → kinetic in a car engine.
- Useful energy output
- The portion of the energy transformed into the form the device was designed to produce.
- Wasted energy output
- The portion of energy transformed into a form other than the intended one — almost always heat, sometimes sound — that isn't put to further use.
Sankey diagram — electric motor
Band width is proportional to power (W); the input band splits exactly into the two output bands.
Worked example
Reading efficiency and energy from a Sankey diagram
Common devices and their energy transformation chains
| Device | Input energy | Useful output | Main wasted form |
|---|---|---|---|
| Electric kettle | Electrical | Thermal (heats water) | Sound; some heat lost to surroundings |
| LED bulb | Electrical | Light | A small amount of heat |
| Petrol car engine | Chemical (fuel) | Kinetic | Heat and sound — the majority of input is wasted |
| Solar panel | Light (solar) | Electrical | Heat (reflected/absorbed, not converted) |
| Microphone | Sound | Electrical | A small amount of heat |
'Energy is used up'
Describing wasted energy as 'lost' in the sense of destroyed, or saying a device 'uses energy up'.
Consequence: This directly contradicts the law of conservation of energy — examiners specifically penalise 'energy is destroyed/used up' phrasing on Explain-style answers about efficiency and transformations.
Fix: Say energy is transformed, transferred, or dissipated — wasted energy still exists, it's just spread out as low-grade heat that's difficult to use for further useful work.
Why LED bulbs replaced incandescent bulbs
Key takeaways
- Input = useful output + wasted output, always — Sankey diagram widths must sum correctly.
- Efficiency compares USEFUL output to TOTAL input, never the wasted band to the input.
- Wasted energy isn't destroyed — it's transformed into a hard-to-reuse form, almost always heat.
- Higher efficiency devices (e.g. LEDs vs incandescent bulbs) waste a smaller fraction of the same input energy.
Forms and Conservation of Energy
Energy shows up in many forms, but the law of conservation of energy says the total amount in an isolated system never changes — only the mix of forms does.
- Kinetic energy (moving objects), gravitational potential energy (height in a field), elastic potential energy (stretched/compressed materials), chemical energy (bonds in fuel/food/batteries), thermal energy, electrical energy, light, sound, nuclear energy — all interconvertible.
- Law of conservation of energy: energy cannot be created or destroyed, only transformed from one form to another or transferred from one object to another.
- In real (non-ideal) situations, some mechanical energy is always transformed into heat via friction or air resistance — total energy is still conserved, it's just harder to track once it's spread out as heat.
- Kinetic energy
- Energy an object possesses due to its motion.
- Gravitational potential energy (GPE)
- Energy stored due to an object's position (height) within a gravitational field.
- Law of conservation of energy
- Energy cannot be created or destroyed; it can only be transformed from one form to another or transferred between objects — the total energy of an isolated system is constant.
Kinetic energy of a moving object
- — mass (kg)
- — speed (m/s)
Gravitational potential energy relative to a reference height
- — mass (kg)
- — gravitational field strength (m/s^2 (≈10 on Earth for estimates))
- — height above the reference level (m)
Beyond the syllabus — elastic potential energy formula
MYP Year 5 expects you to know elastic potential energy exists (stored in stretched springs, bows, elastic bands) and that it converts to kinetic energy on release, but the formula (with spring constant and extension ) is not required at this level — it belongs to later study. Know the concept, not the equation.
Energy bar charts along a falling/swinging path
Total bar height (KE + GPE) stays constant at every point if there's no friction — that's conservation of energy in action.
Worked example
Falling object with and without friction
Assuming a frictionless world by default
Automatically assuming GPE converts ENTIRELY to KE, even when a question explicitly gives a measured (slower) final speed or mentions friction/air resistance.
Consequence: Ignoring given data means the answer contradicts the question's own numbers and loses marks for not applying conservation of energy correctly with an energy-loss term.
Fix: Always write , and solve for whichever term is missing — never default to the frictionless case unless the question says to ignore air resistance/friction.
Key takeaways
- Energy exists in many forms; the law of conservation of energy says the total never changes, only the mix.
- and are the two forms you must be able to calculate.
- If a real (frictional) speed is lower than the ideal conservation-of-energy prediction, the 'missing' energy became heat/sound — never 'lost' or 'destroyed'.
- Elastic PE is a concept you need to know exists, but its formula is beyond this level.
Work, Power and Efficiency
Work is only done when a force causes displacement in the direction of that force. Power is how quickly work is done. Efficiency compares what you usefully get out to what you actually put in.
- No displacement, no work — however hard you push against an immovable wall, the work done on it is zero.
- Force perpendicular to motion also does zero work — carrying a heavy bag while walking at constant height does zero work against gravity, since your walking motion is horizontal while gravity acts vertically.
- Power measures rate: two machines can do identical total work but at wildly different powers if one takes far longer to do it.
- Efficiency can never exceed 100% for a real device — if a calculation gives more, an input/output value has been swapped or a unit error has crept in.
- Work
- Energy transferred when a force causes an object to move a distance in the direction of the force; (or for an angled force).
- Power (watt)
- The rate at which work is done or energy is transferred; .
- Efficiency
- The fraction (usually expressed as a %) of total energy input that is converted into useful energy output.
Work done by a force acting at angle to the direction of motion
- — applied force (N)
- — displacement (m)
- — angle between force and displacement (degrees)
For most MYP problems the force acts along the direction of motion, so this simplifies to (, ).
Power as the rate of doing work
- — work done (J)
- — time taken (s)
Efficiency of an energy-converting device
Work done as area under a Force–distance graph
The graph is a straight rising segment followed by a flat segment — split the shaded area into a triangle and a rectangle to find total work.
Worked example
Work done from a non-rectangular Force–distance graph
Worked example
Work, power and efficiency together
Efficiency over 100%
Computing an efficiency greater than 100% and writing it down without flagging it as impossible.
Consequence: Signals an error further back in the calculation (input/output swapped, or a units mistake) — method marks are usually still awarded, but the 'sensible final answer' mark is lost if the impossible result isn't caught and corrected.
Fix: Efficiency can never exceed 100% for a real device — if your result says otherwise, re-check whether you divided useful-by-total (correct) or total-by-useful (wrong) before finalising your answer.
Zero work when force and motion are perpendicular
Frequently confused
| Concept A | Concept B | The distinction that matters |
|---|---|---|
| Work | Power | Work (joules) is the total energy transferred; power (watts) is how quickly that transfer happens — two devices can do the same total work at wildly different powers if one takes much longer. |
Key takeaways
- Work requires displacement in the direction of the force — zero displacement or a perpendicular force both give zero work.
- Power is the RATE of doing work; identical work at different speeds means different power.
- Efficiency = useful output ÷ total input × 100%, and must always be ≤ 100%.
- Work done from a Force–distance graph is the area under it — split non-rectangular shapes into triangles/rectangles first.
Renewable and Non-Renewable Resources
Energy resources are classified by how quickly they're replenished. Almost all of them trace back to the Sun (solar, wind, hydro, biomass, and fossil fuels formed from ancient sunlight-fed organisms) — except nuclear, geothermal, and tidal power.
- Renewable resources are naturally replenished on a human timescale: solar, wind, hydro, biomass, geothermal, tidal.
- Non-renewable resources are finite: coal, oil, and natural gas take millions of years to form; nuclear fuel (uranium) is a single-use mined resource.
- 'Renewable' and 'low-carbon' are not the same thing — nuclear power has very low carbon emissions but is still non-renewable, since its fuel runs out.
- Resource choice always weighs multiple factors together: cost, reliability (intermittency of solar/wind vs continuous fossil/nuclear supply), and environmental impact.
- Renewable resource
- An energy resource that is naturally replenished on a human timescale (e.g. sunlight, wind, flowing water).
- Non-renewable resource
- An energy resource that exists in a finite quantity and is not replenished on a human timescale once used (e.g. coal, oil, natural gas, uranium).
- Sustainable
- Meeting present energy needs without compromising the ability of future generations to meet theirs — considers both resource renewability and environmental/social impact.
Renewable vs Non-renewable resources
| Feature | Renewable | Non-renewable |
|---|---|---|
| Replenishment | Naturally replenished (solar cycle, water cycle, wind) | Takes millions of years, or a single extraction of a finite deposit |
| Carbon emissions | Generally low or zero at point of use | High for fossil fuels; low for nuclear, but with radioactive waste |
| Examples | Solar, wind, hydro, biomass, geothermal, tidal | Coal, oil, natural gas, nuclear fuel (uranium) |
| Reliability | Often intermittent (weather/time-dependent) | Generally continuous, on-demand supply |
Nuclear power is not renewable
Classifying nuclear power as 'renewable' because it produces very little carbon dioxide.
Consequence: Confuses 'low-carbon' with 'renewable' — this loses the mark in classification questions, since uranium fuel is a finite, mined resource.
Fix: Ask 'does the fuel run out?' — uranium does, so nuclear is non-renewable, despite its low emissions. Renewable ≠ clean/low-carbon; they're two separate criteria.
Worked example
Discussing sustainable building materials (Discuss command term)
Examiner tip
Key takeaways
- Renewable = naturally replenished on a human timescale; non-renewable = finite, runs out.
- Low-carbon and renewable are different criteria — nuclear is low-carbon but non-renewable.
- Resource and material choices always trade off multiple factors: cost, reliability, environmental impact, sourcing practice.
- Discuss/Evaluate answers need both sides weighed AND a final judgement — a one-sided or conclusion-free answer loses marks.
Quick Reference
Work and Energy — everything on one page
Formulas
- Rate of heat conduction — square the radius for a cylindrical rod's area, don't skip it.
- Pressure — convert area to m² first.
- Pascal's principle for hydraulics — force multiplies, distance shrinks by the same factor.
- Kinetic energy.
- Gravitational potential energy.
- Work — zero if force ⟂ displacement.
- Power — rate of doing work.
- Never exceeds 100% for a real device.
Key facts
- Thermal conductivity of copper
- ≈ 400 W m⁻¹K⁻¹
- Thermal conductivity of aluminium
- ≈ 205 W m⁻¹K⁻¹
- Thermal conductivity of wood
- ≈ 0.15 W m⁻¹K⁻¹
- g used for estimates
- 10 m/s²
- 1 m²
- 10,000 cm²
Mnemonics
- No medium, no problem — it's RadiationThe only heat transfer mechanism that works through a vacuum.
Don't confuse
- Heat vs Temperature: Heat is energy transferred (process); temperature is average particle KE (state).
- Conduction vs Convection: Conduction: no bulk matter movement. Convection: matter itself physically moves.
- Work vs Power: Work = total energy transferred (J); power = how fast that transfer happens (W).
- Renewable vs Low-carbon: Renewable means the fuel doesn't run out; low-carbon means low emissions — nuclear is low-carbon but non-renewable.
Command terms
- Identify:
- Name the exact variable/pattern requested — one precise word/phrase, not a sentence about a specific value.
- Explain:
- State the mechanism with 'because' — a description alone scores zero.
- Compare:
- Give at least one similarity AND one difference explicitly.
- Discuss:
- Weigh both sides and end with a stated judgement.
Exam checklist
- Converted all areas to m² before any pressure or conduction calculation?
- Squared the radius (not diameter) for cylindrical rod cross-sectional area?
- Checked efficiency answer is ≤ 100%?
- For Force–distance graphs, split non-rectangular shapes into triangles/rectangles before summing area?
- Used 'transformed/transferred', never 'destroyed/used up', when describing wasted energy?
- For Discuss/Evaluate answers, weighed both sides AND stated a final judgement?
