Pure Substances, Mixtures and Separation
MYP Year 5 Chemistry — Pure Substances, Mixtures and Separation
This topic is really one question asked six different ways: how do you know what you're looking at, and how do you pull it apart? Examiners test it almost entirely through data — a melting point range, a solubility curve, a chromatogram — so the skill isn't memorising definitions, it's reading evidence and matching it to the right classification or technique. Get the sharp-vs-range criterion for purity solid first; everything else in this chapter builds on it.
Overview: Purity, Mixtures and Separation
Chemistry starts by sorting matter into two boxes: pure substances (elements and compounds — one type of particle, fixed composition, constant physical properties) and mixtures (two or more substances physically combined in a variable ratio, each keeping its own properties). Everything else in this chapter — solubility, filtration, distillation, chromatography — is really just a toolkit for telling the two apart and for un-mixing mixtures back into their pure components.
- The single most-tested skill: use melting/boiling point behaviour (sharp value vs range) as evidence of purity, not appearance.
- Separation technique choice always comes back to one question: what physical property differs between the components? (particle size, magnetism, boiling point, solubility, colour/adsorption).
- MYP loves ‘classify and justify’ questions — a bare label (‘mixture’) with no reasoning tied to data scores zero for the justification mark.
The shape of the chapter
Command terms that drive the marks in this topic
| Command term | What it demands | AO | Mark-earning move |
|---|---|---|---|
| Define | Give the precise scientific meaning, not an example. | Criterion A | Must include ‘fixed composition’ and ‘one type of particle/element or compound’ — an example alone (e.g. ‘like water’) earns 0. |
| Classify | Assign to a category (element / compound / mixture) using a stated criterion. | Criterion A | Category alone is often only half the mark — the criterion used (mp range, composition) must be named. |
| Justify / Explain | Give reasoning that links evidence to a conclusion. | Criterion A/D | ‘Because it's pure’ restates the conclusion — must cite the actual evidence (e.g. ‘the 0.5°C range matches a single substance’). |
| Deduce | Reach a conclusion using ONLY the data given in the question. | Criterion B | Bringing in outside numbers instead of the table provided loses the mark even if the final answer is numerically right. |
| Distinguish | State the point(s) of difference between two named things. | Criterion A | Describing each thing separately without a direct contrast scores lower than a stated discriminator. |
| Describe | Give a detailed, accurate account without justifying why. | Criterion A | Adding unrequested explanation doesn't gain extra credit but also isn't penalised — however skipping detail (units, conditions) loses marks. |
Key point
Pure and Impure Substances
A pure substance contains only one type of particle — either a single element (only one kind of atom, e.g. ) or a single compound (atoms of two or more elements joined in one fixed ratio, e.g. ). Because every particle is identical, a pure substance has constant, reproducible physical properties: a sharp, fixed melting point and boiling point. A mixture contains two (or more) substances physically combined in a ratio that can vary — its melting point smears out into a range, and is usually depressed below the purest component's true value, because foreign particles disrupt the regular packing of the lattice.
- Sharp mp/bp (narrow range, often quoted to ±0.5 °C) → pure. A wide range (several °C or more) → mixture/impure sample.
- A sharp range on its own only proves purity — to prove identity you must compare the value to a known literature melting point for that specific substance.
- Elements and compounds are both pure; only combinations of different pure substances in variable proportion count as mixtures.
- The law of definite/multiple proportions is the compositional signature of a compound: the masses of one element combining with a fixed mass of another element are always in small whole-number ratios — mixtures show no such constraint.
- Pure substance
- Matter made of only one type of particle (a single element or a single compound) with a fixed chemical composition and constant physical properties.Includes compounds — 'one type of particle' means one type of formula unit/molecule, not one type of atom.
- Element
- A pure substance made of only one type of atom; cannot be broken into simpler substances by chemical means.
- Compound
- A pure substance formed when atoms of two or more elements bond chemically in a fixed whole-number ratio; can only be split back into elements by a chemical reaction.
- Mixture
- Two or more pure substances physically combined (not chemically bonded) in a ratio that can vary; each component keeps its own chemical identity and properties.
Heating curve: pure substance vs mixture
The flat plateau is the tell: temperature stalls at one exact value only while a pure solid melts.
Worked example
Classifying samples from melting-point data
Worked example
Using literature values to test identity, not just purity
Worked example
Fixed composition and the law of multiple proportions
Sharp mp proves purity, not identity
Assuming a sharp, narrow melting range by itself proves what a substance IS.
Consequence: Loses the mark when no literature value is given to compare against (as with Sample Z, whose literature value is unknown) — you can only conclude 'this is pure', not 'this is X'.
Fix: State explicitly: sharp range = pure substance (purity claim); matching a specific literature value = identity claim. Never claim identity without a reference value to compare to.
Commercial 'purity' vs chemical purity
Treating 99.9% pure copper as chemically 100% pure because it's labelled 'pure' industrially.
Consequence: Marks lost for failing to distinguish the strict chemical definition (100% one substance, one type of particle) from an industrial purity grade.
Fix: Answer with both: chemically, true purity means zero foreign particles; 99.9% copper is described as 'pure' commercially but the remaining 0.1% impurity still measurably affects properties like electrical conductivity and corrosion resistance.
Extracting pure copper — at an environmental cost
Key takeaways
- Purity = fixed composition + one type of particle (element OR compound) + constant physical properties.
- Sharp/narrow melting range (≈≤1 °C) → pure; wide range and depression below the true value → mixture.
- A sharp range proves purity only — match to a literature value to claim identity.
- Compounds obey the law of (multiple) definite proportions — combining masses land on simple whole-number ratios; mixtures do not.
Solutions, Colloids and Suspensions
Mixtures aren't all the same kind of mixture — how thoroughly one substance disperses through another depends on particle size. A solution disperses down to individual ions/molecules (sub-nanometre), giving a mixture so uniform it looks like a single substance. A suspension contains particles large enough to be seen and to settle under gravity. A colloid sits in between: particles too small to settle out on their own, but large enough to scatter light.
- Solutions: homogeneous throughout, never settle, pass through any filter, don't scatter a light beam.
- Colloids: look uniform to the naked eye but scatter light visibly (Tyndall effect) because particles are big enough to reflect photons but small enough to stay dispersed via constant collision with solvent molecules (Brownian motion).
- Suspensions: visibly cloudy/heterogeneous, particles settle on standing, and are removed by ordinary filter paper.
- Solution
- A homogeneous mixture where solute particles are dispersed at the molecular/ionic level in a solvent; does not scatter light and cannot be separated by filtration.
- Colloid
- A mixture where particles (roughly 1–1000 nm) are dispersed throughout a medium finely enough to stay suspended indefinitely, but coarsely enough to scatter light (Tyndall effect).
- Suspension
- A heterogeneous mixture containing visible, relatively large particles that settle out over time and can be removed by filtration.
- Tyndall effect
- The scattering of a light beam by dispersed particles in a colloid, making the beam's path visible; true solutions do not show this effect.
Solution vs colloid vs suspension
| Property | Solution | Colloid | Suspension |
|---|---|---|---|
| Particle size | < 1 nm (ions/molecules) | ~1–1000 nm | 1000 nm (visible) |
| Appearance | Clear, uniform | Often cloudy but uniform | Visibly cloudy/heterogeneous |
| Settles on standing? | Never | No (stays dispersed) | Yes, over time |
| Filterable with paper? | No | No (needs ultrafiltration/membrane) | Yes |
| Tyndall effect? | No (beam invisible) | Yes (beam visibly scattered) | Yes but usually just looks opaque |
| Example | Salt water, sugar syrup | Milk, fog, gelatine | Muddy river water, sand in water |
Tyndall effect: solution vs colloid
Same torch, same angle — the only difference is particle size big enough to scatter light.
Worked example
Classifying an unknown cloudy liquid
Mnemonic
Solutions Simply dissolve, Colloids Scatter light, Suspensions Settle
Three S-words track the size ladder in order: Simply dissolved (smallest, solution) → Scatters light without settling (colloid) → Settles out completely (suspension, largest particles).
Purity and mixture mix-ups
| Concept A | Concept B | The distinction that matters |
|---|---|---|
| Colloid | Suspension | Both look cloudy, but a colloid never settles and passes through filter paper (particles stay suspended via Brownian motion); a suspension settles out and is removed by filtration. |
| Pure compound | Mixture | A compound (e.g. NaCl) has ONE fixed melting point because it is one type of particle; a mixture melts over a RANGE because it contains two or more different substances at a variable ratio. |
| Mixture | Impure sample of a compound | A mixture usually shows a wide, strongly depressed melting range (large amounts of a second substance); an impure compound shows only a small deviation close to the pure literature value (trace contamination), e.g. 801–810 °C against a literature value of 801 °C. |
Real-world application
Key takeaways
- Particle size decides the category: solution < colloid < suspension.
- Diagnostic tests, in order of usefulness: does it settle? Is it filterable? Does it scatter light (Tyndall)?
- Never classify by appearance alone — cloudiness alone doesn't distinguish colloid from suspension.
Solubility and Factors Affecting It
Solubility is the maximum mass of a solute that will dissolve in a fixed mass of solvent (usually 100 g water) at a stated temperature, forming a saturated solution — one that cannot dissolve any more solute at that temperature (extra solute simply sits undissolved). A solution that has less than the maximum dissolved is unsaturated; one forced to hold more than the equilibrium amount (by careful cooling of a hot saturated solution) is supersaturated and unstable.
- For most solids, solubility rises with temperature — more thermal energy helps break the solid lattice apart and disperse ions/molecules into solution.
- For gases, solubility FALLS with rising temperature (and rises with pressure) — heating gives dissolved gas molecules enough energy to escape the liquid, which is why warm fizzy drinks go flat faster.
- 'Like dissolves like': polar solvents (water) dissolve polar/ionic solutes well; non-polar solvents dissolve non-polar solutes well.
- Stirring, crushing the solid, and heating all change the RATE at which the maximum amount dissolves — none of them change the actual solubility value itself.
Solubility
Solubility is the mass of solute (g) that saturates 100 g of solvent at a given, stated temperature.
- — solubility (g per 100 g solvent)
- — mass of solute dissolved at saturation (g)
Always quote a temperature alongside a solubility value — the number is meaningless without it.
Solubility curves for KNO3 and NaCl
Steep curve = strongly temperature-dependent solubility; flat line = barely affected by temperature.
Worked example
Reading a solubility curve to find crystallised mass
Rate of dissolving vs solubility
Saying stirring, crushing, or warming 'increases the solubility' of a solid.
Consequence: Conflates rate and equilibrium amount — loses the mark on 'state which factors affect solubility' style questions.
Fix: Only temperature (and pressure, for gases) change the actual solubility value (maximum mass dissolvable). Stirring, particle size and temperature (as a rate factor) only change how FAST that maximum is reached — the ceiling itself doesn't move due to stirring or crushing.
Examiner tip
Key takeaways
- Solubility = max mass of solute per 100 g solvent at a stated temperature (saturated solution).
- Solid solubility usually rises with temperature; gas solubility falls with temperature and rises with pressure.
- Always rescale 'per 100 g' solubility data to the actual solvent mass given in the question before subtracting.
- Stirring/crushing/heating change rate of dissolving, NOT the solubility ceiling itself.
Filtration, Evaporation and Crystallization
These three techniques all separate a solid from a liquid, but they answer different questions. Filtration separates an insoluble solid from a liquid using a barrier (filter paper) that lets liquid through but traps particles too big to pass. Evaporation removes the solvent entirely (boiling it off) to leave the dissolved solute behind as solid residue — fast, but destroys heat-sensitive solutes and gives small, impure crystals. Crystallisation grows large, pure crystals by evaporating a solution only until it becomes saturated, then cooling it slowly so the solute comes out of solution gradually as an ordered solid, leaving impurities behind in the remaining liquid (mother liquor).
- Choose filtration when the mixture is a solid + liquid where the solid does NOT dissolve.
- Choose evaporation-to-dryness only when the solute is stable at high heat and crystal size/purity don't matter.
- Choose crystallisation when the solute would decompose on strong heating, or when large, well-formed, purer crystals are the goal.
- Physical properties other than solubility can separate mixtures too — e.g. magnetism separates iron from non-magnetic solids without any chemical change occurring.
Filtration apparatus
Residue stays on the paper; filtrate is whatever passes through — know which one is which for the mark.
Worked example
Separating iron and sulfur without a chemical reaction
Evaporating to dryness when crystallisation is needed
Answering 'evaporate the solution to dryness' when asked to obtain large, pure crystals of a heat-sensitive salt (e.g. copper sulfate) or when spitting/decomposition is a risk.
Consequence: Loses the method mark — copper sulfate crystals decompose/lose water of crystallisation if boiled fully dry, and rapid evaporation gives small, impure crystals, not the large pure ones the question usually asks for.
Fix: State: heat/evaporate only until the solution is saturated (test with a hot wire loop/drop test), then leave to cool slowly so large crystals form gradually, and filter off the crystals from the remaining mother liquor.
Choosing the right technique
| Technique | Separates | Property exploited | Typical example |
|---|---|---|---|
| Filtration | Insoluble solid from a liquid | Particle size (too big to pass through paper pores) | Sand from water |
| Evaporation (to dryness) | Dissolved solute from its solvent | Different boiling points of solvent vs solute | Recovering salt quickly from salt water |
| Crystallisation | Dissolved solute, as large pure crystals | Solubility decreasing on cooling a saturated solution | Purifying copper sulfate crystals |
| Magnetic separation | Magnetic solid from non-magnetic solid(s) | Magnetism | Iron filings from sulfur powder |
Key takeaways
- Filtration: solid too big to pass through paper stays as residue; liquid/dissolved parts pass through as filtrate.
- Evaporation-to-dryness is fast but destroys heat-sensitive solutes and gives small, impure crystals.
- Crystallisation = evaporate only to saturation, then cool slowly, for large, pure crystals.
- Not every separation relies on solubility — magnetism, particle size, and boiling point are all fair game depending on the mixture.
Distillation and Fractional Distillation
Distillation separates a liquid from dissolved solutes, or separates two miscible liquids, by exploiting differences in boiling point. In simple distillation, the mixture is heated; the component with the lowest boiling point vaporises first, travels up and through a condenser where it cools back to liquid, and is collected separately (the distillate) — this is how pure water is recovered from seawater, since dissolved salts don't vaporise at water's boiling point. Fractional distillation is used when two or more liquids with CLOSE boiling points need separating (miscible liquids, not solid-in-liquid) — a fractionating column packed with glass beads/plates provides repeated evaporation–condensation cycles up its length, letting the more volatile liquid reach the top and distil off first while the less volatile one lags behind.
- Simple distillation: one volatile liquid + non-volatile dissolved solute(s), e.g. seawater → pure water + solid salts left behind.
- Fractional distillation: two or more volatile liquids with similar boiling points, e.g. separating crude oil into fractions, or ethanol from a fermentation mixture.
- The thermometer bulb must sit level with the side-arm outlet, not dipped in the liquid — it must read the temperature of the VAPOUR about to leave, confirming which component is currently boiling off.
Simple distillation apparatus
The thermometer position is the classic diagram-mark trap — bulb level with the side-arm, never in the liquid.
Worked example
Classifying substances and explaining purification by distillation
Examiner tip
Thermometer position in the distillation diagram
Drawing (or describing) the thermometer bulb dipped into the liquid being heated.
Consequence: Loses the diagram-labelling mark — the thermometer must read the temperature of the vapour leaving through the side-arm, not the liquid's temperature.
Fix: Bulb sits exactly level with the side-arm opening, so it measures the vapour just about to distil over — this is how you confirm which substance is currently boiling off.
Real-world application
Key takeaways
- Simple distillation: separates a volatile liquid from a non-volatile dissolved solute (e.g. water from salt).
- Fractional distillation: separates two or more miscible liquids with close boiling points using a fractionating column.
- Thermometer bulb must be level with the side-arm — a classic diagram mark.
- Always state BOTH heating-to-boiling AND condensing when explaining the process.
Chromatography and Its Applications
Chromatography separates the different substances within a mixture based on how strongly each one is attracted to a stationary phase (e.g. chromatography paper) versus how soluble it is in a moving mobile phase (the solvent). Substances that cling more to the paper move slowly and stay low; substances that dissolve more readily in the solvent are carried further up. The result — a chromatogram — shows each component of the original mixture as a separate spot at its own characteristic height.
- The baseline (starting spot line) must be drawn in pencil, never ink or pen — ink itself is a mixture of dyes that would dissolve and travel, contaminating the results.
- The Rf (retention factor) value is characteristic of a substance for a GIVEN solvent and temperature, letting you match an unknown spot to a known reference.
- Used in forensics (ink/drug analysis), food testing (identifying illegal dyes), and separating plant pigments (chlorophylls, carotenoids).
Retention factor (Rf)
Both distances are measured from the baseline, not from each other.
- — retention factor (no unit (always between 0 and 1))
Rf is only comparable between runs done with the SAME solvent, paper and temperature.
Paper chromatogram and Rf measurement
Both distances are measured from the same baseline — a very common measuring error.
Worked example
Calculating and interpreting Rf values
Using pen instead of pencil for the baseline
Marking the sample spots or baseline in ink/pen rather than pencil.
Consequence: The ink itself dissolves in the solvent and travels up the paper, adding extra false spots and ruining the separation — a described-method mark is lost even if the rest of the technique is correct.
Fix: Always specify pencil for the baseline: graphite is insoluble in the chromatography solvents used, so it stays put and doesn't interfere with the real spots.
Examiner tip
Chromatography beyond the classroom
Key takeaways
- Chromatography separates substances by differing attraction to stationary phase vs solubility in mobile phase.
- Rf = distance solute travelled ÷ distance solvent travelled, both measured from the same baseline.
- Rf is reproducible for a given substance/solvent/temperature — used to match unknowns against references.
- Baseline must be pencil, never ink, or the baseline itself contaminates the chromatogram.
Quick Reference
Formulas
- Solubility — always quote with a stated temperature and units g/100 g water.
- Both distances measured from the same baseline; Rf has no units, range 0–1.
Key facts
- Sharp melting point range for a pure substance
- ≈ ≤1 °C, compared against a literature value
- Rf value range
- 0 to 1, no units
- Thermometer bulb position in distillation
- Level with the side-arm, not touching the liquid
- Colloid particle size
- ≈ 1–1000 nm
- KNO3 solubility at 60 °C (data-booklet-style curve)
- 110 g per 100 g water
Mnemonics
- Solutions Simply dissolve, Colloids Scatter light, Suspensions SettleOrdered by increasing particle size and matching diagnostic test.
Don't confuse
- Colloid vs Suspension: Colloid never settles and passes filter paper; suspension settles and is filterable.
- Pure compound vs Mixture: Compound has one sharp melting point (fixed composition); mixture melts over a depressed range (variable composition).
- Mixture vs Impure sample of a compound: Mixture: wide, strongly depressed range. Impure compound: small deviation close to the pure literature value.
Command terms
- Define:
- State composition + fixed property consequence, not just an example.
- Classify:
- Name the category AND the criterion used (mp range, filterability, settling).
- Justify/Explain:
- Tie the conclusion back to the specific data given, not a general restatement.
- Calculate:
- Show formula, substitution, and final answer with correct units (or state 'no units' for Rf).
Exam checklist
- Classify using measurable behaviour (mp/bp range, settling, filterability) — never appearance alone.
- State BOTH heating-to-boiling AND condensing when explaining distillation.
- Rescale 'per 100 g' solubility data to the actual solvent mass given in the question.
- Baseline in pencil for chromatography — ink contaminates the run.
- Quote solubility with units and a stated temperature.
- Compare an experimental melting point to a literature value to claim identity, not just purity.
