Waves Sound and Light

Cover illustration for Waves Sound and Light (Physics MYP Year 5).
MYP · Physics MYP Year 5

Waves Sound and Light

24 min readStandardAssessed under MYP Sciences Criteria A (Knowing & Understanding) and C (Processing & Evaluating); typically one full unit test plus data-based questions in end-of-year exam

Every wave question you'll get on this topic reduces to one idea: energy travels, matter doesn't. Once that's locked in, the rest is bookkeeping — matching frequency to energy, matching medium to wave type, matching angle to the normal. The exam bank for this unit leans hard on data tables (EM spectrum values), applied scenarios (hospitals, tunnels, sonar) and 'explain using wave properties' questions — so these notes are built around calculation plus reasoning, not just definitions.

Overview — How This Topic Fits Together

A wave transfers energy from one place to another without transferring matter. Sound and light are the two waves you'll be tested on most, and they sit at opposite ends of a key divide: sound is a mechanical wave (needs a medium — solid, liquid or gas), light is an electromagnetic wave (travels through vacuum at ). Almost every question in this unit is really asking you to apply correctly, identify a wave's position in the EM spectrum, or track a ray of light across a boundary.

  • The EM spectrum questions in the exam bank are data-heavy — you'll be given frequency/energy/wavelength tables and asked to spot the pattern, not just recall the order.
  • Communication and technology questions test why a property (penetration, diffraction, straight-line travel) makes a wave suitable — or unsuitable — for a real application.
  • Sound questions almost always hinge on echo timing or medium-dependence of speed.
  • Reflection/refraction questions are ray-diagram plus Snell's law — examiners penalise angles measured from the surface instead of the normal every single time.

The shape of the chapter

Command terms this topic tests hardest

Command termWhat it demandsAOMark-earning move
StateGive a short factual answer with no supporting argument.AO1One correct fact = full marks; extra unrequested explanation earns nothing.
IdentifyName or select the correct item from given information.AO1Must use the exact term (e.g. 'gamma rays', not 'high energy rays').
ExplainGive a reasoned account linking cause to effect.AO2Needs a 'because...' chain — a bare fact with no linking word drops a mark.
DeduceReach a conclusion from data given in the question, showing the reasoning.AO2/AO3Marks are for the working/logic, not just the final number.
CalculateObtain a numerical answer showing all working.AO2Correct substitution earns a mark even if the final arithmetic slips — but no working shown caps you at the answer mark only.
JustifySupport a conclusion with a specific reason drawn from evidence.AO3A conclusion with no evidence link scores zero, even if the conclusion is correct.
Discuss / EvaluatePresent more than one viewpoint and weigh them.AO3One-sided answers cap at half marks — you must acknowledge a counterpoint.

Key point

All electromagnetic waves travel at the same speed in a vacuum () — what changes across the spectrum is frequency and wavelength, never speed. Sound has no such constant: its speed depends entirely on the medium it's moving through.

  1. Electromagnetic Spectrum and Its Uses

The electromagnetic spectrum is a continuous range of waves that all travel at in vacuum but differ in frequency and wavelength. Because is fixed at , frequency and wavelength are inversely related — this single fact drives almost every EM spectrum question you'll see.

  • Order from lowest to highest frequency (and shortest to longest wavelength going the other way): radio, microwave, infrared, visible, ultraviolet, X-ray, gamma.
  • Photon energy increases with frequency () — gamma rays carry the most energy per photon of any EM wave, radio the least.
  • Ionizing radiation (UV, X-ray, gamma) carries enough energy per photon to strip electrons from atoms — this is why X-rays and gamma rays need shielding and dose limits, while radio and microwaves don't damage tissue the same way.
  • X-rays are useful for imaging bone precisely because bone (dense, calcium-rich) absorbs them strongly while soft tissue lets them pass — the contrast in absorption is what creates the image.

Key terms

Electromagnetic wave
A transverse wave of oscillating electric and magnetic fields that requires no medium and travels at in a vacuum.Unlike sound, EM waves cross empty space — this is how sunlight reaches Earth.
Photon
A discrete packet of EM energy; its energy depends only on the wave's frequency.Higher frequency = more energetic photons, not 'brighter' photons.
Ionizing radiation
EM radiation with enough photon energy to remove electrons from atoms (UV, X-ray, gamma).The dividing line for 'dangerous' EM radiation in medical and safety contexts.

The electromagnetic spectrum

Frequency and photon energy increase left to right; wavelength increases right to left.

RadioMicrowaveInfraredVisible lightUltravioletX-rayGamma rayWavelength scale (m)Frequency scale (Hz)

Core relationships

wave equation for EM waves in vacuum

— speed of light in vacuum (m s^{-1} (= 3.0\times10^{8}))
— frequency (Hz)
— wavelength (m)
Memorise

photon energy

— energy of one photon (J)
— Planck's constant (6.63\times10^{-34}\text{ J s})
— frequency (Hz)

Higher frequency always means higher photon energy — this is the relationship every EM spectrum data table is testing.

Worked example

Deducing the missing energy value from a data trend

[3]
A student records photon energies for four EM waves: Radio ( Hz, J), Infrared ( Hz, J), Visible light ( Hz, J), and Ultraviolet ( Hz, ? J). Deduce the missing energy value and state the trend the data shows.

Worked example

From standing wave spacing to wave speed (microwave oven)

[3]
A microwave oven at GHz produces standing waves inside its cavity. The distance between two adjacent antinodes is measured as cm. (a) Deduce the wavelength. (b) Calculate the speed of the microwaves.

EM spectrum: uses and hazards

Wave typeApprox. frequencyCommon useHazard / note
Radio– HzBroadcasting, emergency services commsNon-ionizing; essentially harmless at normal exposure
Microwave– HzCooking, mobile phone signals, satellite linksCan heat tissue at high intensity (skin/eye heating)
Infrared– HzRemote controls, thermal imaging, fibre-optic signalsFelt as heat; non-ionizing
Visible light– HzHuman vision, optical fibres, photographyNon-ionizing
Ultraviolet– HzSterilisation, vitamin D synthesis, UV curingIonizing; causes sunburn and skin damage
X-ray– HzMedical imaging of bone, airport security scanningIonizing; strictly dose-limited
Gamma ray HzCancer radiotherapy, sterilising medical equipmentHighest photon energy; most ionizing, heavily shielded

Mnemonic

Rico's Mother Insists Visiting Uncle Xavier's Garage

Radio, Microwave, Infrared, Visible, Ultraviolet, X-ray, Gamma — the EM spectrum in order of increasing frequency (and photon energy).

Common mistake

Saying wavelength and frequency both 'increase' or both 'decrease' together across the spectrum.

Consequence: Directly contradicts with fixed — examiners flag this as a fundamental misunderstanding worth losing the full mark, not just a slip.

Fix: Say it as one sentence every time: as frequency increases, wavelength decreases proportionally, because their product must stay equal to .

For 'identify the highest-energy wave' questions

Don't just name gamma rays — link it to frequency explicitly: 'Gamma rays have the highest frequency of any EM wave, and since , they carry the highest energy per photon.' A bare name with no link only gets the identify mark, not the justify mark if both are asked.

mmWave scanners, 5G, and the ethics of exposure limits

Airport body scanners and 5G networks both use the millimetre-wave band (30–300 GHz), sitting between microwave and infrared. Because this band can measurably heat skin and eye tissue at high intensity, and dense 5G transmitter networks mean constant low-level public exposure, safety regulators face a genuine 'Discuss/Evaluate' scenario: current guidelines assume uniform population exposure, but children, pregnant people and those with implants may respond differently — exactly the kind of nuance an evaluate-style answer needs to acknowledge on both sides.

Key takeaways

  • EM spectrum order (low to high frequency): radio, microwave, infrared, visible, ultraviolet, X-ray, gamma.
  • All EM waves travel at m s in vacuum; only and change, and they're inversely related.
  • Photon energy rises with frequency — gamma rays have the most energy per photon, radio the least.
  • Ionizing (UV, X-ray, gamma) vs non-ionizing (radio, microwave, infrared, visible) is the key hazard distinction examiners test.

  1. Light in Communication and Technology

Modern communication is built on choosing the right EM wave for the job. Radio waves diffract around obstacles and travel long distances through air, which is exactly why they suit broadcast and emergency-service radios — but that same reliance on line-of-sight-plus-diffraction is why thick obstacles like tunnels and mountains can still block them. Light (usually infrared) carried inside optical fibres uses total internal reflection to send signals with almost no loss over huge distances.

  • Radio waves: long wavelength lets them diffract around buildings and hills, and they penetrate walls reasonably well — but thick rock, metal, or reinforced concrete (as in long tunnels) blocks or heavily attenuates the signal because too little of the wave diffracts through or around such a dense, extended barrier.
  • Optical fibres: carry light pulses (usually infrared) along a glass core, trapped by total internal reflection at the core-cladding boundary — this is the backbone of broadband internet and telephone networks.
  • Microwaves: short wavelength gives them a narrow, directional beam — ideal for satellite links and mobile phone masts, but they can't bend around obstacles the way radio waves do.

Total internal reflection inside an optical fibre

Each reflection occurs because the ray strikes the boundary at an angle greater than the critical angle.

CoreCladdingAngle of incidence > critical angleLight signal direction

Critical angle for total internal reflection

critical angle in terms of refractive index of the denser medium

— critical angle (degrees)
— refractive index of the medium light is travelling in (relative to the less dense medium outside)

Total internal reflection only happens going from a denser medium into a less dense one, at angles greater than .

Worked example

Finding the critical angle for a glass fibre core

[2]
A fibre-optic core is made of glass with refractive index , surrounded by cladding acting like air. Calculate the critical angle, and state the condition needed for light to stay trapped inside the core.

Worked example

Explaining radio signal loss in a tunnel

[2]
A paramedic crew reports that radio communication fails when their ambulance enters a long road tunnel. Explain, using the wave properties of radio waves, why the signal is lost.

Common mistake

Explaining tunnel signal loss with 'radio waves travel in straight lines so they can't turn corners' alone.

Consequence: This ignores diffraction entirely, which is the actual property being tested — answers that skip it typically only get partial credit.

Fix: Always name diffraction as the property that usually helps radio signals bend around obstacles, then explain why the tunnel's scale defeats it.

Fibre broadband vs copper cable

A single optical fibre thinner than a human hair can carry far more data than a thick copper cable, because light pulses trapped by total internal reflection lose very little energy over tens of kilometres — copper cables lose signal to electrical resistance much faster. This is why undersea fibre-optic cables, not radio or satellite links, carry the vast majority of the world's internet traffic between continents.

Key takeaways

  • Radio waves diffract around obstacles, which is why they work for broadcast comms — but thick, extended barriers (tunnels, mountains) still block them.
  • Optical fibres transmit light signals using total internal reflection, requiring the ray to strike the core-cladding boundary above the critical angle every time.
  • Choice of EM wave for a technology always comes down to matching a specific wave property (diffraction, penetration, directionality) to the application's constraints.

  1. Wave Properties and Types

Every wave — mechanical or electromagnetic — is described by the same set of quantities, and every wave question ultimately checks whether you can read these off a diagram or apply correctly. Waves also split into two types based on how the medium (or field) oscillates relative to the direction the wave travels.

  • Transverse waves: oscillation is perpendicular to the direction of travel — light, water waves, waves on a string.
  • Longitudinal waves: oscillation is parallel to the direction of travel, creating compressions and rarefactions — sound is the standard example.
  • Amplitude relates to the energy a wave carries (bigger amplitude = more energy); wavelength and frequency together fix the wave's speed through .

Quantities every wave has

Amplitude
Maximum displacement of a point on the wave from its rest (equilibrium) position.Determines the energy/loudness/brightness of the wave, not its speed.
Wavelength ()
Distance between two consecutive identical points on a wave (e.g. crest to crest).Measured in metres.
Frequency ()
Number of complete oscillations passing a point per second.Measured in hertz (Hz); determines pitch (sound) or colour (light).
Period ()
Time taken for one complete oscillation.The reciprocal of frequency: .
Wave speed ()
Distance the wave pattern travels per second.For a given medium, fixed by the medium's properties, not by the wave's frequency.

Transverse wave — labelled features

Three complete wavelengths of a transverse wave with amplitude 2 cm and wavelength 4 cm.

CrestTroughAmplitudeWavelengthEquilibrium line

The wave equation and period

wave speed equation, applies to all waves

— wave speed (m s^{-1})
— frequency (Hz)
— wavelength (m)
Memorise

period-frequency relationship

— period (s)
— frequency (Hz)

Worked example

Reading wave speed from amplitude, wavelength and period

[3]
A wave on a rope has amplitude 0.5 m, wavelength 2.0 m and period 0.4 s. Calculate its frequency and its speed.

Transverse vs longitudinal waves

FeatureTransverseLongitudinal
Oscillation directionPerpendicular to travel directionParallel to travel direction
Pattern shownCrests and troughsCompressions and rarefactions
ExamplesLight, water waves, waves on a stringSound, seismic P-waves
Needs a medium?Not always (light needs none; water waves do)Always (needs particles to compress)

Easy mix-ups

Concept AConcept BThe distinction that matters
FrequencyPeriodFrequency counts oscillations per second (Hz); period is the time for one oscillation (s) — they're reciprocals, , never equal in value unless Hz.
AmplitudeWavelengthAmplitude is a vertical measurement (height, tied to energy); wavelength is a horizontal measurement (distance, tied to speed via ) — they answer completely different questions.

Mnemonic

T-Trouble Travels sideways, L-ongitudinal Lines up

Transverse = oscillation Transverse (sideways) to travel; Longitudinal = oscillation runs Lengthways (parallel) to travel.

Key takeaways

  • applies to every wave — mechanical or EM — and is the formula examiners return to most.
  • Amplitude relates to energy carried; wavelength and frequency together fix wave speed — don't mix these roles up.
  • Transverse = perpendicular oscillation (light, water); longitudinal = parallel oscillation with compressions/rarefactions (sound).

  1. Sound Waves and Their Behavior

Sound is a longitudinal mechanical wave — it must have particles to compress and rarefy, which is why sound cannot travel through a vacuum, unlike light. Its speed depends on the medium: sound travels fastest through solids (particles are closely packed and transmit vibrations quickly), slower through liquids, and slowest through gases like air.

  • Pitch is determined by frequency: higher frequency = higher pitch.
  • Loudness is determined by amplitude: bigger amplitude = louder sound (more energy carried).
  • An echo is a reflected sound wave — timing an echo lets you calculate distance, provided you remember the sound travels there and back.
  • Speed of sound in air at room temperature is roughly ; in water it's about ; in steel it can exceed .

Sound wave — compressions and rarefactions

Regions of high particle density (compressions) alternate with low density regions (rarefactions); the distance between two adjacent compressions is one wavelength.

CompressionRarefactionWavelengthDirection of wave travel

Sound-specific application of the wave equation

same wave equation, applied with the speed of sound in the relevant medium

— speed of sound in the medium (m s^{-1})
— frequency (Hz)
— wavelength (m)

distance to a reflecting surface from echo timing

— distance to the reflecting surface (m)
— speed of sound in the medium (m s^{-1})
— total time for the sound to travel there and back (s)

The division by 2 accounts for the round trip — this is the step almost everyone forgets under exam pressure.

Worked example

Sonar depth-finding using echo timing

[2]
A ship's sonar sends a sound pulse downward and detects the echo after s. The speed of sound in seawater is . Calculate the depth of the water beneath the ship.

Common mistake

Forgetting to halve the total echo distance when calculating depth or distance to a barrier.

Consequence: Gives an answer exactly double the correct value — a very common one-mark loss on otherwise fully correct working.

Fix: Always write 'total distance = there + back, so depth = total distance ÷ 2' as an explicit line of working, not just in your head.

Common mistake

Assuming sound and light both travel through a vacuum.

Consequence: Sound absolutely cannot travel through a vacuum — this is a factual error, not a rounding slip, and loses full marks on 'explain why sound can't travel in space' style questions.

Fix: State clearly: sound is a mechanical wave and needs particles to compress and rarefy; space is (essentially) a vacuum, so there's nothing to carry the vibration.

When asked to compare speed of sound across media

Give the reason, not just the ranking: 'sound travels fastest in solids because particles are closest together and transmit vibrations most efficiently between neighbours' — a bare ranking (solid > liquid > gas) with no reasoning only earns the state mark, not the explain mark.

Key takeaways

  • Sound is a longitudinal mechanical wave — needs a medium, cannot cross a vacuum.
  • Pitch ↔ frequency; loudness ↔ amplitude — keep these two pairings straight.
  • Speed of sound is medium-dependent (fastest in solids, slowest in gases) — never assume it equals .
  • Echo/sonar distance calculations always require halving the total round-trip distance.

  1. Reflection and Refraction of Light

Reflection bounces light back off a surface without it changing medium; refraction bends light as it crosses into a medium where its speed changes. Both are always measured from the normal — an imaginary line perpendicular to the surface at the point where the ray hits it, never from the surface itself.

  • Law of reflection: angle of incidence = angle of reflection, both measured from the normal.
  • Refraction: light bends towards the normal when entering a denser (higher refractive index) medium, and away from the normal when leaving it — because its speed decreases entering a denser medium.
  • The refractive index describes how much a medium slows light down relative to vacuum: bigger means slower light and more bending.

Key terms

Normal
An imaginary line drawn perpendicular to a surface at the point of incidence.All angles (incidence, reflection, refraction) are measured from this line, never from the surface.
Refractive index ()
The ratio , comparing the speed of light in vacuum to its speed in a medium.Larger = light travels slower in that medium = more bending at a boundary.
Critical angle ()
The angle of incidence in the denser medium at which the refracted ray travels exactly along the boundary (refraction angle = 90°).Beyond this angle, refraction stops entirely and total internal reflection occurs instead.

Refraction of light at an air-glass boundary

The refracted ray bends towards the normal because glass is optically denser than air, slowing the light down.

NormalIncident rayRefracted rayAngle of incidenceAngle of refractionAirGlass

Reflection and refraction equations

law of reflection

— angle of incidence (degrees)
— angle of reflection (degrees)
Memorise

refractive index of a medium

— refractive index
— speed of light in vacuum (m s^{-1})
— speed of light in the medium (m s^{-1})

Snell's law

— refractive indices of the first and second media
— angle of incidence in medium 1 (degrees)
— angle of refraction in medium 2 (degrees)
Memorise

Worked example

Applying Snell's law across an air-glass boundary

[3]
Light travels from air () into glass () hitting the boundary at an angle of incidence of . Calculate the angle of refraction.

Easy mix-ups

Concept AConcept BThe distinction that matters
ReflectionRefractionReflection keeps the ray in the same medium (bounces back); refraction sends the ray into a new medium with a changed speed and direction.
Angle measured from the surfaceAngle measured from the normalEvery reflection/refraction angle in physics is measured from the normal (perpendicular to the surface) — measuring from the surface itself gives the wrong angle even if the ray drawing is correct.

Common mistake

Measuring the angle of incidence or refraction from the boundary surface instead of the normal.

Consequence: Produces an angle that's the complement of the correct one (i.e., minus the right answer) — an automatic mark loss even with otherwise perfect diagram construction.

Fix: Draw the dashed normal line first, before drawing any ray, and always label the angle between the ray and that dashed line.

Ray diagram marks

On 'draw a labelled ray diagram' questions, the normal must be drawn as a dashed (not solid) line perpendicular to the boundary — a solid line, or one drawn at any angle other than exactly 90° to the surface, forfeits the diagram accuracy mark even if your angles are numerically correct.

Key takeaways

  • Law of reflection: , both from the normal.
  • Refraction bends light towards the normal entering a denser medium, away from it leaving one — driven by a change in speed, captured by .
  • Snell's law links the two media's refractive indices to the incidence/refraction angles.
  • Beyond the critical angle, refraction stops and total internal reflection takes over — the principle behind optical fibres.

Quick Reference

Waves, Sound and Light — everything on one page

Formulas

  • universal wave equation — sound, EM waves, any wave
  • period-frequency reciprocal
  • photon energy; J s
  • law of reflection, angles from the normal
  • refractive index
  • Snell's law
  • critical angle for total internal reflection
  • echo/sonar distance — halve the round trip

Key facts

Speed of light in vacuum
m s
Speed of sound in air (room temp)
m s
Speed of sound in water
m s
Planck's constant
J s

Mnemonics

  • Rico's Mother Insists Visiting Uncle Xavier's GarageEM spectrum order: Radio, Microwave, Infrared, Visible, Ultraviolet, X-ray, Gamma
  • T-Trouble Travels sideways, L-ongitudinal Lines upTransverse oscillates sideways to travel direction; longitudinal oscillates along it

Don't confuse

  • Frequency vs Period: Reciprocals: ; never equal unless Hz
  • Reflection vs Refraction: Reflection stays in the same medium; refraction crosses into a new one and bends
  • Ionizing EM waves vs Non-ionizing EM waves: UV, X-ray, gamma strip electrons (dangerous); radio, microwave, infrared, visible don't

Command terms

State:
One fact, no reasoning needed
Explain:
Must include a 'because...' causal link
Deduce:
Show working from given data, not recall
Justify:
Conclusion + specific supporting evidence
Discuss/Evaluate:
Present and weigh more than one side

Exam checklist

  • Can you state the EM spectrum in order and link frequency to photon energy?
  • Can you explain why radio waves fail in tunnels using diffraction, not just 'blocked'?
  • Can you read amplitude, wavelength, frequency and period off a wave diagram?
  • Can you calculate sonar/echo distance and remember to halve the round trip?
  • Can you draw a correctly labelled ray diagram with the normal as a dashed line and apply Snell's law?
