MYP Sciences Year 1 – Waves, Sound and Light

19 min readFoundationalAssessed through MYP Criteria A–D (Knowing & Understanding, Inquiry & Designing, Processing & Evaluating, Reflecting) — no fixed external exam percentage, but this is a heavily tested unit for short-answer and data-based questions.

Light and sound are both waves — that's the whole trick to this unit. Once you accept that a rainbow, a guitar string and a dog whistle are all just 'energy moving through space in a repeating pattern', the exam questions stop being separate topics and become the same three ideas asked four different ways: what carries the wave, how do we describe it (amplitude, wavelength, frequency), and what happens when it hits something.

Overview: How This Chapter Fits Together

Every topic in this chapter is really the same question wearing different clothes: how does energy travel without matter travelling with it? Light and sound are both waves, but they differ in the one fact examiners test again and again — light is transverse and needs no medium; sound is longitudinal and always needs one. Everything else (colour, pitch, loudness, sonar, fibre optics) is just that one fact applied to a specific situation.

  • Colour is what happens when your eye detects a narrow band of the electromagnetic spectrum, split apart or reflected selectively.
  • Sound is what happens when a vibrating source disturbs a medium in a longitudinal pattern that your eardrum can pick up.
  • Pitch and loudness are just the human interpretation of two wave properties — frequency and amplitude — nothing more mysterious than that.
  • Technology (sonar, radar, fibre optics) is just people borrowing wave behaviour that already exists in nature and pointing it at a problem.

The shape of the chapter

Command terms that decide your mark in this unit

Command termWhat it demandsAOMark-earning move
ListGive a sequence of names/answers with no explanation.Criterion AEach correctly ordered item earns credit alone — writing reasons here earns nothing extra and wastes time.
IdentifyPick out and name one specific feature from data, a graph, or a diagram.Criterion AA bare correct name secures the mark — don't justify it unless the question also says 'and explain'.
DescribeGive a detailed account, including a trend or characteristic, not just a label.Criterion ANeeds a full sentence with a pattern or direction (e.g. 'wavelength decreases') — a single word rarely gets full marks.
CompareState how two things relate — similarities, differences, or a quantitative link.Criterion AMust mention BOTH items in the same sentence (e.g. 'red has a longer wavelength than violet') — two separate descriptions without a link loses the mark.
ExplainGive the reason or mechanism behind an observation — the 'why', not the 'what'.Criterion ANeeds cause-and-effect reasoning; restating the observation without a mechanism scores zero.
NameGive only the correct term or word.Criterion ASame as List but for a single answer — one word/phrase is expected and sufficient.

Key point

Every wave carries ENERGY, not matter. Whether it's a compression racing through air (sound) or an oscillating field (light), the same three quantities — amplitude, wavelength, frequency — describe it, linked by .

Colour and the Electromagnetic Spectrum

  • White light (sunlight, a torch) isn't 'colourless' — it's a mixture of every visible wavelength travelling together, which is exactly why it can be split apart.
  • Visible light is one narrow band inside the electromagnetic (EM) spectrum, sitting between infrared and ultraviolet; every EM wave travels at m/s in a vacuum but differs in wavelength and frequency.
  • Order of the visible spectrum by decreasing wavelength: red, orange, yellow, green, blue, indigo, violet (ROYGBIV) — red has the longest wavelength/lowest frequency, violet the shortest wavelength/highest frequency.
  • A prism splits white light into colours because each wavelength refracts (bends) by a slightly different amount going from air into glass and back into air — this separation is called dispersion.
  • The colour you see an opaque object as is the wavelength(s) it REFLECTS back to your eye; every other wavelength hitting it is absorbed and converted to heat instead.
Dispersion
The splitting of white light into its component colours as it passes through a medium like a prism, because each wavelength refracts by a different amount.Not the same as ordinary refraction — dispersion is refraction happening differently for every wavelength at once.
Refraction
The bending of a wave as it passes from one medium into another, caused by a change in speed.
Reflection (of colour)
Light of a particular wavelength bouncing back off a surface rather than being absorbed — this is the colour you perceive an opaque object to be.
Absorption
Wavelengths of light taken in by a material and converted to heat instead of being reflected or transmitted; a surface looks black if it absorbs all visible wavelengths.
Transmission
Light passing through a transparent/translucent material largely unchanged — e.g. a red filter transmits red light and absorbs the rest.
Electromagnetic (EM) spectrum
The full continuous range of electromagnetic waves, from long-wavelength/low-frequency radio waves to short-wavelength/high-frequency gamma rays; visible light is just one narrow band of it.

Dispersion of white light through a prism

Each wavelength bends by a different amount, spreading white light into ROYGBIV.

white light (incident ray)glass prismnormalRedOrangeYellowGreenBlueIndigoViolet

The electromagnetic spectrum

EM waveWavelength (approx.)Everyday use
Radio waves
1 m
Broadcasting radio and TV signals
Microwaves1 mm – 1 mMicrowave ovens, mobile phone signals, satellite links
Infrared700 nm – 1 mmTV remote controls, thermal cameras, heat lamps
Visible light400–700 nmHuman sight, photography, optical fibres
Ultraviolet10–400 nmSunburn/tanning, sterilising equipment, forensic detection
X-rays0.01–10 nmMedical and dental imaging, airport security scanners
Gamma rays< 0.01 nmCancer radiotherapy, sterilising medical equipment

Mnemonic

Richard Of York Gave Battle In Vain

First letter of each word = first letter of each visible spectrum colour, in order from longest to shortest wavelength: Red, Orange, Yellow, Green, Blue, Indigo, Violet.

Worked example

Predicting the colour of an object under coloured light

[3]
A green leaf and a red apple are lit only with red light (no other colours present). State what colour each object appears, and explain why.

Worked example

Which colour bends the most inside a prism?

[2]
Inside a glass prism, the angle each colour makes with the normal is: Red 19.5°, Yellow 19.0°, Blue 18.5°. Identify which colour bends the most, and explain why.

Worked example

Identifying variables in a prism investigation

[2]
A student changes the prism angle (30°, 45°, 60°) and measures the width of the rainbow produced on a screen each time. Identify the independent and dependent variables.

Frequently confused

Concept AConcept BThe distinction that matters
Reflection of colourAbsorption of colourAn object appears the colour it REFLECTS back to your eye; every wavelength it absorbs instead turns to heat and never reaches your eye at all.
Additive colour mixing (light)Subtractive colour mixing (paint/pigment)Mixing coloured LIGHT adds wavelengths together (red + green light = yellow light; all three = white); mixing paints/pigments absorbs more wavelengths as you add colours, tending toward black.

Applying paint rules to light

Assuming red and green LIGHT mixed together make brown or grey, because that's what happens when mixing red and green paint.

Consequence: Loses the mark on any question about combining coloured lights (not pigments) — examiners test this precisely because the intuitive 'paint' answer is wrong for light.

Fix: Light mixing is ADDITIVE: red + green light = yellow light; red + green + blue light = white light. Only pigments/paints subtract wavelengths toward black.

'List' wants speed, not explanation

Questions like 'List the seven colours of white light' are worth 1 mark for the correctly ordered sequence alone. Writing 'because red has the longest wavelength' here earns nothing extra — save the explaining for an 'Explain' question.

Why rainbows always show the same colour order

A rainbow forms when sunlight enters a water droplet, refracts (bends and slows), reflects off the inside back surface of the droplet, then refracts again on exiting — separating into colours exactly like a glass prism. Because each wavelength bends by the same fixed, predictable amount in water every single time, the colour order (red on the outside, violet on the inside) never changes from one rainbow to the next.

Key takeaways

  • White light is a mixture of all visible wavelengths; a prism separates them through dispersion because each wavelength refracts by a different amount.
  • ROYGBIV runs from longest wavelength/lowest frequency (red) to shortest wavelength/highest frequency (violet).
  • An opaque object's colour is the wavelength(s) it reflects — shine light with no matching wavelength on it and it looks black.
  • Mixing coloured LIGHT is additive (toward white); mixing pigments is subtractive (toward black) — never mix up the two systems.

Sound Waves and Vibrations

  • Sound is produced by a vibrating source — a guitar string, vocal cords, a speaker cone — pushing and pulling on the particles of a surrounding medium.
  • Sound travels as a longitudinal wave: particles of the medium vibrate back and forth PARALLEL to the direction the wave travels (unlike light or water waves, which are transverse).
  • As the source vibrates it creates alternating compressions (particles squeezed close together, higher pressure) and rarefactions (particles spread apart, lower pressure) that travel outward.
  • Sound MUST have a medium — solid, liquid, or gas — to travel through. No particles means no vibration to pass along, which is why sound cannot cross a vacuum.
  • Sound travels fastest through solids, slower through liquids, and slowest through gases like air, because tightly packed particles pass a vibration to their neighbours more quickly.
Vibration
A repeated back-and-forth motion of a particle or object about a fixed rest position — the source of every sound.
Longitudinal wave
A wave in which particles of the medium vibrate parallel to the direction of energy transfer; sound is the classic example.
Compression
A region within a longitudinal wave where particles are pushed close together, creating higher pressure.
Rarefaction
A region within a longitudinal wave where particles are spread further apart, creating lower pressure.
Medium
The material (solid, liquid or gas) a mechanical wave like sound needs in order to travel; no medium means no sound.

A longitudinal sound wave in a slinky

Particles vibrate parallel to the direction of travel, unlike a transverse wave.

compressionrarefactiondirection of energy transferparticle vibration (parallel to wave travel)transverse wave (for comparison)

Sound travelling through a vacuum

Believing sound can travel through empty space, as shown in most sci-fi film explosions.

Consequence: Directly contradicts the 'needs a medium' fact tested in short-answer questions — an easy mark lost if written as 'sound travels through space just like light'.

Fix: Sound is mechanical — it needs particles to bump into each other and pass the disturbance along. No particles (a vacuum) means no sound. Light needs no medium; sound always does.

Labelling compressions vs rarefactions

On a diagram, compressions are where coils/particles are CLOSE together, not far apart. Swapping the two labels on a diagram-reading question is a common way to lose the identification mark.

Key point

'No medium, no sound' is the single most examined fact in this section — it's why astronauts can't hear an explosion in space, and it's the reasoning examiners want in any 'explain' question about sound and vacuums.

Key takeaways

  • Sound is a longitudinal wave: particle vibration runs parallel to the direction of travel.
  • A vibrating source creates alternating compressions (bunched particles, high pressure) and rarefactions (spread particles, low pressure).
  • Sound cannot cross a vacuum — unlike light, it always needs a medium.
  • Speed of sound: solids > liquids > gases, because tightly packed particles transmit vibrations faster.

Pitch, Loudness and Hearing

  • Pitch is how high or low a sound seems, and it is determined entirely by frequency: more vibrations per second = higher pitch; fewer vibrations per second = lower pitch.
  • Loudness is how loud or quiet a sound seems, determined by amplitude: a bigger vibration (more energy) = louder sound, measured in decibels (dB).
  • Human hearing range is roughly 20 Hz to 20,000 Hz (20 kHz). Below this range is infrasound (elephant calls, earthquake tremors); above it is ultrasound (dog whistles, bat calls, medical ultrasound).
  • Hearing works because sound vibrations reach the eardrum, making it vibrate; tiny bones in the middle ear pass this on and it's converted into electrical signals the brain interprets as sound.
  • Loudness fades with distance from a source because the same sound energy spreads over a larger area — pitch, however, stays exactly the same regardless of how far away you are.
Pitch
How high or low a sound is perceived to be, determined by the frequency of the sound wave.
Loudness
How loud or quiet a sound is perceived to be, determined by the amplitude of the sound wave; measured in decibels (dB).
Frequency
The number of complete wave cycles (vibrations) passing a point every second, measured in hertz (Hz).
Amplitude
The maximum displacement of a vibrating particle from its rest position; linked directly to the energy the wave carries.
Ultrasound
Sound with a frequency above the human hearing range (above ~20,000 Hz).
Infrasound
Sound with a frequency below the human hearing range (below ~20 Hz).

Worked example

Comparing two sounds using frequency and amplitude data

[3]
Sound A has a frequency of 200 Hz and amplitude 2 units. Sound B has a frequency of 800 Hz and amplitude 6 units. Compare the pitch and loudness of the two sounds.

Frequently confused

Concept AConcept BThe distinction that matters
PitchLoudnessPitch depends on FREQUENCY (how fast the source vibrates — high/low note); loudness depends on AMPLITUDE (how big the vibration is — soft/loud volume). Changing one does not automatically change the other.

Don't swap frequency and amplitude in explanations

If asked to explain why a sound got louder (not higher-pitched), your reasoning must talk about amplitude/energy increasing. Mentioning frequency in that answer — even if correct elsewhere — scores 0 for that specific reasoning mark.

Key takeaways

  • Pitch ↔ frequency (vibrations per second, Hz); loudness ↔ amplitude (size of vibration, measured via decibels).
  • Human hearing range is roughly 20 Hz–20,000 Hz; infrasound sits below it, ultrasound above it.
  • The eardrum vibrates in response to sound pressure changes, converted by the middle ear into signals the brain reads as sound.
  • Distance from a source reduces perceived loudness (energy spreads over more area), but does not change pitch.

Uses of Light and Sound in Technology

  • Sonar (SOund Navigation And Ranging) sends ultrasound pulses from a ship and times the echo bouncing off the seabed or a submarine to calculate distance — the same principle bats use naturally to navigate.
  • Medical ultrasound imaging sends high-frequency sound into the body; different tissues reflect echoes differently, building a live image without using ionising radiation like X-rays.
  • Fibre-optic cables carry information as pulses of light bounced along the inside of a thin glass or plastic fibre by total internal reflection, letting huge amounts of data travel fast with minimal loss.
  • Radar uses reflected radio waves (not sound) to detect the position and speed of aircraft, ships, and weather systems.
  • Remote controls use pulses of infrared light — invisible to the eye — to send coded signals to a TV or air-conditioning unit.
  • Lasers (concentrated, single-wavelength light) are used in barcode scanners, surgery, and CD/DVD players reading data off a reflective disc.
Sonar
SOund Navigation And Ranging — technology using reflected ultrasound pulses and echo timing to measure distance underwater.
Radar
RAdio Detection And Ranging — technology using reflected radio waves to detect the position and speed of distant objects such as aircraft.
Total internal reflection
When light travelling inside a denser medium (like glass) strikes the boundary at a shallow enough angle that it reflects entirely back inside instead of escaping — the principle that keeps light trapped inside an optical fibre.
Fibre optics
Thin, flexible strands of glass or plastic that carry information as pulses of light, kept inside the fibre by total internal reflection.

Matching a technology to its wave

TechnologyWave usedWhat it does
SonarUltrasound (sound)Measures distance to the seabed/objects underwater by timing an echo
Medical ultrasound scanUltrasound (sound)Images soft tissue/a foetus using reflected sound, no radiation used
RadarRadio wavesDetects distance/speed of aircraft, ships, storms via reflected radio pulses
TV/AC remote controlInfrared lightSends coded on/off/channel signals invisibly to a receiver
Fibre-optic cableVisible/infrared lightCarries phone and internet data as light pulses via total internal reflection
X-ray scannerX-raysImages bones/luggage contents using penetrating high-energy waves

Sound-based vs light-based technology

FeatureSound-based tech (e.g. sonar)Light-based tech (e.g. radar/fibre optics)
Needs a medium?Yes — cannot work in a vacuum (no sonar in space)No — light/EM waves travel through a vacuum too
Typical speed~1500 m/s in water, ~340 m/s in air (comparatively slow)3×10⁸ m/s (extremely fast, near-instant)
Best used forUnderwater distance/depth, medical imagingLong-distance communication, detecting fast-moving objects

Nature invented sonar first

Bats and dolphins evolved natural echolocation millions of years before humans invented sonar — sending out sound pulses and timing the returning echo to 'see' in complete darkness or murky water. Naval sonar operators today run the exact same echo-timing calculation on a screen that a bat's brain runs instantly to catch a moving insect.

Key takeaways

  • Sonar and medical ultrasound both use reflected sound (ultrasound) and echo timing to measure distance or build an image.
  • Fibre optics and remote controls both use light (visible or infrared) travelling as pulses to carry information.
  • Sound-based tech needs a medium and travels relatively slowly; light/EM-based tech needs no medium and travels at ~3×10⁸ m/s.
  • Choosing sound vs light depends on the available medium (water vs air/vacuum) and safety (ultrasound avoids the ionising-radiation risk of X-rays).

Properties of Waves

  • Every wave transfers ENERGY from one place to another without transferring matter — the medium itself doesn't travel with the wave (a cork bobs up and down on water; it doesn't ride the wave to shore).
  • Transverse waves: particles vibrate PERPENDICULAR to the direction of energy transfer (light, water ripples, a wiggled rope). Longitudinal waves: particles vibrate PARALLEL to the direction of travel (sound, a pushed slinky).
  • Amplitude: maximum displacement from the rest position — linked to the energy the wave carries (loudness for sound, brightness for light).
  • Wavelength (λ): the distance between two identical points on successive cycles, e.g. crest to crest.
  • Frequency (f): number of complete wave cycles passing a point per second, in hertz (Hz). Period (T): time taken for one complete cycle, in seconds.
Crest
The highest point of a transverse wave above the rest position.
Trough
The lowest point of a transverse wave below the rest position.
Amplitude
The maximum displacement of a particle from its rest (equilibrium) position — measured from the rest line to a crest, NOT crest to trough.
Wavelength
The distance between two identical, adjacent points on a wave — e.g. from one crest to the next crest.
Frequency
The number of complete wave cycles passing a fixed point every second, measured in hertz (Hz).
Period
The time taken for one complete wave cycle to pass a point, measured in seconds.

Labelled transverse wave

Amplitude is measured from the rest line to a crest only; wavelength is measured crest-to-crest.

cresttroughamplitude (A)wavelength (λ)equilibrium/rest position

wave speed = frequency × wavelength

— wave speed (m/s)
— frequency (Hz)
— wavelength (m)
Memorise

Works for ANY wave — light, sound, water ripples — as long as f and λ describe the same wave.

period = 1 ÷ frequency

— period (time for one full cycle) (s)
— frequency (Hz)
Memorise

Frequency and period are reciprocals — a wave of frequency 5 Hz has a period of 0.2 s.

Worked example

Reading wavelength and calculating speed from an untidy graph

[3]
A transverse wave travels along a rope. The diagram shows 3.5 complete wave cycles spread across a total length of 84 cm. The source vibrates 5 times every second. Determine the wavelength and the speed of the wave.

Measuring amplitude from trough to crest

Reading amplitude as the full vertical distance from the lowest trough to the highest crest.

Consequence: Doubles the true amplitude value — an automatic wrong answer even if every other step in the calculation is done correctly.

Fix: Amplitude is measured from the rest (equilibrium) position up to a crest only (or down to a trough only) — half of the total crest-to-trough distance.

Transverse vs longitudinal waves

FeatureTransverse waveLongitudinal wave
Particle vibration directionPerpendicular to wave travelParallel to wave travel
ExamplesLight, water ripples, a shaken ropeSound, a pushed slinky, seismic P-waves
Visible featuresCrests and troughsCompressions and rarefactions
Needs a medium?No (EM waves) / Yes (water, rope)Yes, always

Key takeaways

  • A wave transfers energy, not matter — the medium's particles oscillate about a fixed rest point.
  • Transverse: vibration is perpendicular to travel direction (crests/troughs). Longitudinal: vibration is parallel to travel direction (compressions/rarefactions).
  • links speed, frequency and wavelength for ANY wave; links period and frequency.
  • Always count complete wave cycles (not just peaks) when reading wavelength off a diagram, and measure amplitude from the rest line, not crest-to-trough.

Quick Reference

Waves, Sound and Light — everything on one page

Formulas

  • wave speed = frequency × wavelength — works for light AND sound
  • period = 1 ÷ frequency

Key facts

Human hearing range
20 Hz – 20,000 Hz
Speed of light (vacuum)
3×10^8 m/s
Typical speed of sound in air
~340 m/s
Visible spectrum wavelength range
400–700 nm

Mnemonics

  • Richard Of York Gave Battle In VainROYGBIV — spectrum colour order, red (longest λ) to violet (shortest λ)

Don't confuse

  • Pitch vs Loudness: Pitch = frequency (Hz); loudness = amplitude (dB)
  • Reflection vs Absorption: Reflected wavelength = colour you see; absorbed wavelengths vanish as heat
  • Transverse wave vs Longitudinal wave: Vibration perpendicular to travel (light) vs parallel to travel (sound)

Command terms

List:
Just names/order — no reasons needed
Describe:
State the trend/pattern with detail, not one word
Compare:
Link both items in one sentence with a relational word
Explain:
Give the reason/mechanism, not just a restatement

Exam checklist

  • Can you list ROYGBIV in wavelength order both ways (longest→shortest and reverse)?
  • Can you state whether an object under coloured light will look its own colour or black, and explain why?
  • Do you know sound needs a medium and is longitudinal, while light doesn't and is transverse?
  • Can you distinguish pitch (frequency) from loudness (amplitude) in an explanation?
  • Can you read wavelength/amplitude correctly off a wave graph — cycles not peaks, rest-line not trough-to-crest?
  • Can you match a technology (sonar, radar, fibre optics, remote control) to the wave type it uses?
