MYP Year 2 Sciences — Forces and Motion (Physics strand)

17 min readStandardCore physics unit in MYP Year 2 Sciences — assessed through Criterion A (Knowing & Understanding) and Criterion C (Communication) in unit tests, plus data-based investigation tasks using toy-car/friction experiments like the ones below.

Every question on this topic is secretly asking the same three things: what's making the object speed up, slow down, or stay put — and can you show it with numbers or a diagram? Toy cars on ramps, blocks dragged across carpet, a distance-time curve that flattens out near the end — underneath the props it's always friction, net force, or reading a gradient correctly. Get precise with force names (never just "the force") and treat graph shape as speed information, and this stops being six separate ideas and becomes one physical story.

Overview — The Shape of This Topic

Forces and motion in MYP Year 2 is built from two skills examiners test relentlessly: (1) can you read a distance-time graph as a speed story, and (2) can you correctly name which force is doing what, then add forces up with direction in mind. Almost every exam question — toy cars, blocks on force meters, sliding books — is a variation of these two skills wrapped in a different everyday object.

  • Friction, air resistance and drag are all the same family: contact/fluid forces that oppose motion.
  • Speed, velocity and acceleration are the three numbers you calculate to describe HOW an object is moving.
  • Force diagrams and net force are how you combine multiple forces into one overall answer.
  • Balanced vs unbalanced forces is the single idea that decides whether something accelerates at all.

The shape of the chapter

Command terms that actually appear in this topic's questions

Command termWhat it demandsAOMark-earning move
IdentifyGive a short, factual answer straight from data or observation — no reasoning required.AO1One correct pattern/fact = full marks; extra explanation earns nothing extra.
DescribeGive a detailed account that references the actual data or trend direction.AO1/AO2Must quote the data direction (e.g. 'as roughness increases, distance decreases'), not just 'they are different'.
ExplainGive reasons — cause AND effect linked in one chain.AO31 mark for naming the force, 1 mark for linking it to the observed effect. Naming the force alone caps you at half marks.
CalculateShow substitution into a formula and give a final answer with a unit.AO2Marks for correct substitution AND correct unit; a bald final answer with no working risks the method mark.
EstimateGive a reasoned approximate value using the given data as reference points.AO2Must justify the value's position relative to given data — a value outside the given range loses the mark even with good reasoning.
CompareState similarities AND differences between two things.AO2A one-sided answer (only differences, or only similarities) loses marks.

Key point

Net force decides everything: balanced forces (net = 0) mean constant velocity, including staying still; unbalanced forces (net ≠ 0) mean acceleration. If a question says 'steady speed' or 'constant velocity', the forces are balanced — full stop.

Friction, Air Resistance and Drag

  • Friction is a contact force that opposes relative motion (or attempted motion) between two touching surfaces — it always acts backward, opposite to the direction of movement.
  • No surface is perfectly smooth: even 'smooth' tile has microscopic bumps and ridges that interlock with the bumps on whatever it's sliding against. Rougher surfaces have bigger, more numerous interlocking points, so they generate a bigger friction force.
  • Air resistance is friction's cousin — air molecules colliding with a moving object create a force opposing its direction of travel, and it increases with speed and surface area.
  • Drag is the general term for this resistive effect in any fluid, gas or liquid — air resistance is simply drag caused by a gas.

Both friction and drag convert kinetic energy into heat (and a little sound) — that's exactly why a pushed toy car eventually stops without you touching it again. The surface (and the air around it) has quietly taken its kinetic energy away.

Friction
A contact force that opposes the relative sliding motion between two touching surfaces, acting parallel to the surfaces and opposite to the direction of motion (or attempted motion).Depends on surface roughness and how hard the surfaces are pressed together — not on how big your original push was.
Air resistance
A type of drag force exerted by air on an object moving through it, acting opposite to the direction of travel and increasing with speed and surface area.
Drag
The general resistive force a fluid (gas or liquid) exerts on an object moving through it; air resistance is drag in a gas.

Why rough surfaces create more friction

Rougher surfaces have more/bigger interlocking bumps at contact points, generating a bigger friction force — the entire reason ice, wood, carpet and sandpaper give the toy car four completely different stopping distances.

Applied forceFriction forceMicroscopic bumps (rough)Fewer/smaller bumps (smooth)

Distance travelled before stopping is inversely proportional to the friction force acting — double the friction, half the distance, for the same starting push.

— distance travelled before stopping (m or cm)
— friction force from the surface (N)
— constant of proportionality (same push force each trial) (N·m)

Only valid when the initial push/force is identical on every surface — exactly the setup in Q1, Q4, Q5 and Q6.

Worked example

Finding an unknown friction force from an inverse relationship

[5]
A toy car pushed with the same force travels: Ice 120 cm, Wood 80 cm, Carpet 45 cm, Sandpaper 15 cm before stopping. The car takes 2 s to cross the carpet. The friction force on wood is 0.6 N. (a) Calculate the average speed of the car on the carpet. (b) The distance is inversely proportional to the friction force — find the friction force on ice, carpet and sandpaper.

Naming friction without linking it to the effect

Writing 'because of friction' as the entire answer to a 2-mark 'explain why the car slows down' question (Q2, Q7 style).

Consequence: Scores 1 mark out of 2 — the examiner has evidence you know a keyword, not that you understand the mechanism.

Fix: State the force AND its effect in one linked sentence: 'Friction acts between the wheels and the carpet, opposing the car's motion, which decelerates it and brings it to rest sooner than on the smoother wood floor.'

'Identify the trend' wants one sentence, not a paragraph

Q4(a), Q5(a) and Q6(a) all ask you to identify or describe the relationship between surface and stopping distance. It's worth 1 mark. Write: 'As the surface gets rougher, the stopping distance decreases' — quoting the actual data direction. Don't launch into a friction explanation there; that's the next part's marks, and repeating the idea earns nothing twice.

Worked example

Estimating between two data points (interpolation)

Stopping distances: smooth tile 45 cm, carpet 28 cm, sandpaper 12 cm. Astroturf is rougher than carpet but smoother than sandpaper. Estimate its stopping distance.

Ice, tyres, and the toy car experiment aren't so different

Winter tyres are cut with deep, jagged treads purely to raise friction against snow and ice — the same physics as sandpaper stopping the toy car in just 15 cm versus ice's 120 cm. When friction drops (icy road, worn tyres), stopping distance rises dramatically, which is why real braking distances roughly double on wet roads and can be far longer still on ice.

Key takeaways

  • Friction opposes relative motion and comes from surface roughness — rougher = bigger friction force = shorter stopping distance for the same push.
  • Air resistance and drag are the same mechanism as friction, just caused by fluid molecules (air, water) instead of solid-on-solid contact.
  • 'Distance × friction force = constant' is the exam relationship — use it to find an unknown friction force whenever one surface gives you both values.
  • 'Explain' questions on this topic always need force + mechanism/effect — never just the keyword 'friction' on its own.

Motion Graphs: Distance-Time

  • A distance-time graph plots how far an object has travelled (never decreasing, since distance can't be 'undone') against time elapsed.
  • The gradient (slope) of the line at any point IS the speed at that point — steep = fast, shallow = slow, zero (flat) = stationary.
  • A straight line means constant speed. A curve means the speed is changing: getting steeper = speeding up, flattening out = slowing down.

In Q3, the car is on a rough, straight track with nothing pushing it after release — the curve flattening as time goes on is exactly what friction does to a free-moving object: it decelerates the whole way, never speeding back up.

Reading a distance-time graph: four signature shapes

Same axes, four completely different stories — always read the gradient, never just the height of the line.

Stationary — zero gradientConstant speed — constant gradientAccelerating — gradient increasingDecelerating — gradient decreasing

Worked example

Reading distance and calculating average speed from a curve

[3]
A toy car released on a rough track gives the distance-time points (0,0), (2,4), (4,7), (6,9), (8,10), (10,10.5). (a) Identify the distance travelled between t=0s and t=4s. (b) Calculate the average speed between t=0s and t=4s.

Frequently confused

Concept AConcept BThe distinction that matters
Steepening curveFlattening curveSteepening = gradient increasing = speeding up (accelerating); flattening = gradient decreasing = slowing down (decelerating). Judge by how the slope changes, not by which way the curve visually bends.

Reading graph height as speed

Saying 'the car is fastest at t=8s because the graph is highest there' — confusing total distance covered with current speed.

Consequence: Loses the mark on any question asking where the object moves fastest/slowest — height shows distance-so-far, not speed.

Fix: Speed = gradient (steepness), not height. In the example above, between t=8s and t=10s the graph is nearly flat (10 m to 10.5 m) — the car is almost stopped, even though it has travelled the furthest total distance by that point.

Key takeaways

  • Gradient of a distance-time graph = speed; the height of the line alone tells you nothing about how fast the object is currently moving.
  • Straight line = constant speed; curve = changing speed; flat = stationary.
  • A curve flattening over time is the graph signature of friction decelerating a free-moving object, exactly like the released toy car in Q3.
  • Average speed over an interval is not the same as instantaneous speed at the end of that interval — check which one the question is actually asking for.

Speed, Velocity and Acceleration

  • Speed tells you how fast something is moving — distance covered per unit time. It's a scalar: no direction attached.
  • Velocity is speed with a direction specified (e.g. '5 m/s north'). It's a vector — two cars both doing 20 m/s but in opposite directions have the same speed but different velocities.
  • Acceleration is how quickly velocity changes — it can mean speeding up, slowing down (a negative value), or changing direction, even at constant speed (like going round a corner).

Average speed — what almost every calculation in this course actually uses — is total distance ÷ total time. It smooths out any speeding up or slowing down that happened along the way, which is exactly why Q3(b)'s 'average speed' answer doesn't match the car's actual speed at the end of the interval.

Speed
Distance travelled per unit time; a scalar quantity with magnitude only.
Velocity
Displacement per unit time; a vector quantity with magnitude AND direction.Same units as speed (m/s), but with a direction attached that speed doesn't carry.
Acceleration
The rate of change of velocity — how quickly speed and/or direction is changing.

average speed = distance ÷ time

— average speed (m/s)
— distance travelled (m)
— time taken (s)
Memorise

acceleration = change in velocity ÷ time taken for that change

— acceleration (m/s^2)
— final velocity (m/s)
— initial velocity (m/s)
— time taken (s)

A negative result just means the object is decelerating — it isn't a 'different formula for slowing down'.

Worked example

Calculating acceleration from rest

[2]
A toy car pushed from rest reaches 0.6 m/s after 3 s. Calculate its acceleration.

Frequently confused

Concept AConcept BThe distinction that matters
SpeedVelocityVelocity always carries a direction — changing direction at constant speed still counts as acceleration for velocity, but never for speed alone.

Mnemonic

Cover-up triangle: D on top, S and T on the bottom row. Cover the quantity you want and the triangle shows you the formula: D = S×T, S = D/T, T = D/S.

A quick way to rearrange under exam pressure without algebra panic — the exact same trick rearranges using (v−u) in place of D.

Key takeaways

  • Speed = scalar (magnitude only); velocity = vector (magnitude + direction) — same units, different information carried.
  • for average speed; for acceleration — always identify u, v and t before substituting.
  • Deceleration is negative acceleration, not a separate formula.
  • Units matter for marks: m/s for speed/velocity, m/s² for acceleration — a missing square is an easy mark lost.

Force Diagrams and Net Force

  • A free-body diagram shows ONE object in isolation with arrows for every force acting on it — arrow direction shows force direction, arrow length shows relative size.
  • Net force (resultant force) is what you get when you add up all the forces as vectors — forces in the same direction add, forces in opposite directions subtract.
  • If forces in opposite directions are equal in size, they cancel and the net force is zero — the object's motion doesn't change (this leads directly into balanced/unbalanced forces, next section).

For a toy car being pushed across a table, four forces typically act: applied (push) force forward, friction backward, weight downward, and normal (support) force upward. Vertically, weight and normal force are usually equal and opposite; horizontally, applied force competes directly with friction, and whichever is bigger decides the net force's direction.

Free-body diagram of a pushed toy car

Normal force balances weight vertically, while applied force and friction compete horizontally — whichever arrow is bigger in that direction wins as the net force.

Applied force (push)FrictionWeightNormal force
Net force / resultant force
The single overall force found by combining (vector-summing) every individual force acting on an object; it determines whether the object accelerates and in which direction.
Free-body diagram
A simplified diagram showing one object and arrows for every force acting on it, with arrow length roughly representing force size and direction showing where each force pushes or pulls.

Net force is the vector sum of every individual force — forces in the same direction add, opposite directions subtract.

— resultant/net force (N)

Direction matters: assign a positive/negative sign (or state a direction) before adding — this is the step where marks are most often lost.

Worked example

Calculating net force with direction

[2]
A toy car is pushed forward with an applied force of 5 N while friction acts backward with 3.2 N (its calculated value on sandpaper). Calculate the net force and state its direction.

Adding forces without accounting for direction

Writing net force = 5 + 3.2 = 8.2 N when the two forces act in opposite directions.

Consequence: Loses both the magnitude and direction marks — the answer treats force like a scalar, ignoring that it's a vector.

Fix: Always define a positive direction first, give opposing forces a negative sign, then add — net force = larger force − smaller force when only two forces act in a straight line.

Key takeaways

  • Free-body diagrams isolate one object and show every force acting on it — arrow length ≈ size, direction = where it acts.
  • Net force = vector sum of all forces; the direction of the bigger force always wins.
  • On a flat horizontal surface, weight and normal force usually cancel vertically, leaving applied force vs friction to decide horizontal net force.
  • Always state a direction with any net force answer — a magnitude alone is an incomplete answer to a vector quantity.

Types of Forces

  • Forces fall into two broad families: contact forces (objects must be touching) and non-contact/field forces (act at a distance, no touching needed).
  • Contact forces you'll meet constantly: friction (opposes sliding), normal/support force (surface pushes back perpendicular to itself), tension (a stretched string/rope pulls inward), applied force (a push or pull from a person or motor), air resistance/drag (fluid opposing motion).
  • Non-contact forces: gravity (attraction between masses, always pulling toward Earth's centre near the surface), magnetic force (between magnets/magnetic materials), electrostatic force (between charged objects).

Weight is simply the force of gravity acting on an object's mass — don't confuse it with mass itself. Mass is 'how much stuff' (kg, unchanging); weight is 'how hard gravity pulls on that stuff' (N, would change on the Moon).

Tension
A pulling force transmitted through a stretched string, rope, or cable, directed along its length.
Weight (gravity)
The force of gravitational attraction pulling a mass toward the centre of the Earth (or any large body).
Magnetic force
A non-contact force acting between magnets or between a magnet and a magnetic material (e.g. iron, steel).
Electrostatic force
A non-contact force acting between electrically charged objects — attractive between opposite charges, repulsive between like charges.

Forces at a glance

ForceContact or non-contact?Typical example in this topic
FrictionContactToy car sliding to a stop on carpet
Air resistance / dragContact (fluid)Slowing a fast-moving car or falling object
Normal forceContactTable pushing up on the toy car
TensionContactA string pulling a cart along
Applied forceContactA hand pushing the toy car
Weight (gravity)Non-contactEarth pulling the car down onto the table
Magnetic forceNon-contactA maglev train levitating above its track
Electrostatic forceNon-contactA balloon sticking to a wall after rubbing

Contact forces vs non-contact (field) forces

FeatureContact forcesNon-contact (field) forces
Requires touching?Yes — objects must be in physical contactNo — acts across empty space
ExamplesFriction, tension, normal force, applied force, dragGravity, magnetic force, electrostatic force
RangeOnly right at the point of contactCan act over large distances (usually weaker further away)
In the toy car experimentsFriction is the star force controlling stopping distanceGravity (weight) acts throughout but doesn't change between surfaces

Frequently confused

Concept AConcept BThe distinction that matters
MassWeightMass is the amount of matter in an object (kg, scalar, constant everywhere); weight is the force of gravity acting on that mass (N, vector, changes with location) — the same toy car has the same mass and weight on every surface in the friction experiments, only friction changes.

Maglev trains skip the friction problem entirely

Maglev trains use magnetic (non-contact) force to levitate the train above the track, removing wheel-on-rail friction completely — a major reason they can reach speeds over 600 km/h using less energy per kilometre than a wheeled train travelling at the same speed, where rolling friction would otherwise fight the motor constantly.

Key takeaways

  • Two families: contact forces need touching (friction, tension, normal, applied, drag); non-contact/field forces act at a distance (gravity, magnetic, electrostatic).
  • Weight is gravity acting on mass — using 'weight' and 'mass' interchangeably in an explain answer is a specific error examiners check for.
  • The toy car experiments across this topic only ever vary contact forces (friction) between trials — weight and normal force stay constant throughout.

Balanced and Unbalanced Forces

  • When all forces on an object vector-sum to zero net force, the forces are balanced — the object either stays still or continues at constant velocity in a straight line.
  • When forces don't cancel out, they're unbalanced — there's a net force, and the object accelerates: speeds up, slows down, or changes direction.
  • 'Constant speed' or 'steady speed' in a question is exam code for balanced forces — the applied force must exactly equal the opposing friction force at that moment.

A toy car slowing down after being pushed has unbalanced forces the whole time it decelerates: friction is bigger than the (now zero) applied force once your hand lets go, so the net force points backward, decelerating the car until it stops — at which point the forces become balanced again (both friction and applied force are zero).

Worked example

Reading friction force from a steady-speed pull

[2]
A student pulls a wooden block at a steady speed across carpet, tile, and sandpaper using a force meter. Readings: Carpet 4.5 N, Tile 1.2 N, Sandpaper 6.8 N. (a) Identify which surface produces the greatest friction force. (b) Explain why the force needed on carpet is greater than on tile.

Frequently confused

Concept AConcept BThe distinction that matters
Balanced forcesNo forces actingBalanced forces means multiple forces ARE acting but their vector sum is zero (e.g. a block at steady speed still has friction AND applied force acting, just equal and opposite) — it never means the forces have vanished.

'Steady speed' / 'constant velocity' is the trigger phrase

Whenever a question says the object moves at constant or steady speed, that's your instruction that forces are balanced. Use it immediately: applied force = opposing force (usually friction). This shortcut answers Q8-style questions without needing any extra formula.

Assuming a stationary object has no forces acting on it

Claiming a book resting on a table has 'no forces' because it isn't moving.

Consequence: Loses marks on any force-diagram or balanced-forces question about stationary objects — the correct picture always includes weight AND normal force, just balanced.

Fix: Say 'the forces are balanced (weight downward = normal force upward), so net force is zero and the book stays at rest' — name the forces even when their net effect is zero.

Key point

Balanced = net force zero = constant velocity (including staying at rest). Unbalanced = net force ≠ zero = acceleration (speeding up, slowing down, or turning). 'Steady speed' in a question is always code for 'balanced forces here.'

Key takeaways

  • Balanced forces (net = 0) → constant velocity, including remaining at rest; unbalanced forces (net ≠ 0) → acceleration.
  • 'Steady/constant speed' in a question means applied force = opposing force exactly — use this to read off an unknown force directly.
  • A stationary or constant-velocity object still has forces acting on it — they're just balanced, never absent.
  • A toy car decelerating after a push has unbalanced forces (friction > applied force, which drops to zero) until it stops, then becomes balanced again at rest.

Quick Reference

Forces and Motion — everything on one page

Formulas

  • average speed
  • acceleration
  • inverse relationship — same push force across surfaces
  • vector sum of all forces; direction matters

Key facts

Ice vs sandpaper stopping distance (same push force)
120 cm vs 15 cm — 8× further on ice
Unit for acceleration
m/s² (metres per second, per second)

Mnemonics

  • D over S,T triangleCover the unknown to get d=v×t, v=d/t, or t=d/v — same trick works for a=(v−u)/t.

Don't confuse

  • Speed vs Velocity: Velocity has a direction attached; speed doesn't.
  • Balanced forces vs No forces: Balanced means forces cancel to zero net force, not that they're absent.
  • Steepening curve vs Flattening curve: Steepening = speeding up; flattening = slowing down.
  • Mass vs Weight: Mass = amount of matter (kg); weight = force of gravity on it (N).

Command terms

Identify:
One-line fact or pattern, no explanation needed.
Explain:
Name the force AND link it to the observed effect.
Calculate:
Show substitution, give final answer with correct unit.
Estimate:
Give a reasoned value that stays within the given data range.

Exam checklist

  • Convert all distances/times to consistent units before calculating.
  • State a direction with every net force or velocity answer.
  • Link the force name to its effect in every 'explain' answer.
  • Check any calculated friction/force trend matches the surface roughness order.
  • Remember: 'steady speed' = balanced forces = applied force equals opposing force.
