Earth and Space Science pulls the ground under your feet and the planets beyond into one running story: change driven by energy. Examiners love catching students who mix up weathering with erosion, get an eclipse alignment backwards, or blame the seasons on Earth being 'closer to the Sun' — every one of those is a specific, avoidable mark loss. Six ideas, one theme: rock is built and destroyed, seasons cycle, moons and shadows line up (occasionally) — because the Sun keeps supplying energy and gravity keeps everything in motion.

Overview — The Shape of This Topic

This topic covers processes at two very different scales: the slow destruction and rebuilding of rock on Earth's surface (weathering, erosion, the rock cycle), and the much larger motions of Earth, Moon and Sun that give us day/night patterns, seasons, phases and eclipses. Underneath it all sits Earth's own internal structure — the layered interior whose heat drives everything from volcanoes to the magnetic field.

  • Surface processes (weathering, erosion, rock cycle) are powered mainly by the Sun's energy and gravity acting on water, ice and wind.
  • Astronomical processes (phases, eclipses, seasons) are all about geometry — the relative POSITIONS of Sun, Earth and Moon, not their temperature or distance.
  • Earth's internal structure explains why the surface is dynamic at all: heat escaping from the interior drives the slow movements that eventually recycle rock.

The shape of the chapter

Command terms this topic tests hardest

Command termWhat it demandsAOMark-earning move
Definestate the precise accepted meaning of a termAO11 mark for the exact accepted definition — a vague paraphrase loses the mark
Describestate the relevant features or steps of a process/observationAO1/AO2marks awarded per correct feature/step named — no reasoning required, just accurate detail
Explaingive the reason or mechanism behind why/how something happensAO2marks reserved for the causal link (the WHY) — restating what happens without the mechanism scores lower
Identifyname or select the correct item from given informationAO11 mark for the correct name/label, no justification unless separately asked
Calculateuse given data to work out a numerical answer with correct unitsAO2/AO3marks for correct method, correct substitution, AND correct units — dropping units can cost the final mark
Comparegive explicit similarities and/or differences between two or more thingsAO2requires a direct link between the two things — two separate descriptions placed side by side earns no comparison mark

Key point

Every idea in this topic connects to ONE theme: Earth is a dynamic system where energy — from the Sun and from Earth's own interior — drives constant change. Rock is destroyed and rebuilt, seasons cycle, and occasionally the Moon's shadow lines up exactly right for an eclipse.

Weathering and Erosion

Weathering is rock breaking down WHERE IT SITS — no movement involved. Erosion is what happens next: an agent (water, wind, ice, gravity) picks up and carries those broken fragments away. Deposition is when that agent runs out of energy and drops the sediment. Confusing these three costs marks even when a student clearly understands the underlying process.

  • Mechanical (physical) weathering breaks rock into smaller pieces WITHOUT changing its chemistry — freeze-thaw, exfoliation (onion-skin peeling from heating/cooling), and abrasion are the classic examples.
  • Chemical weathering changes the actual mineral composition through reactions — acid rain dissolving limestone, or iron minerals oxidising ('rusting') to a reddish-brown colour.
  • Biological weathering is caused by living things — plant roots forcing their way into cracks and widening them, or burrowing animals exposing fresh rock surfaces.
  • Rate of weathering can be measured experimentally (e.g. mass loss of a rock sample in acid over time) and compared between rock types — this is a common data-handling question.
Weathering
The breakdown of rock into smaller pieces at or near Earth's surface, in place, without the fragments being carried away.
Erosion
The transport of weathered rock fragments (sediment) away from their original location by an agent such as water, wind, ice or gravity.
Deposition
The settling/dropping of transported sediment when the agent carrying it loses energy.
Mechanical (physical) weathering
Breakdown of rock into smaller fragments without any change to its chemical composition, e.g. freeze-thaw action.
Chemical weathering
Breakdown of rock through chemical reactions that alter its mineral composition, e.g. acid rain reacting with calcium carbonate.
Biological weathering
Breakdown of rock caused by the physical or chemical action of living organisms, e.g. root growth widening cracks.

Freeze-thaw (frost) weathering

Repeated freeze-thaw cycles gradually widen a crack until the rock fractures.

Liquid water in crackIce (expanded volume)Pressure on crack wallsFracture after repeated cycles

Rate of weathering

average rate of weathering measured as mass lost per unit time

— average rate of mass loss (g/h (or g/day))
— initial mass − final mass (g)
— duration of exposure (h (or days))
Memorise

Match the unit to whatever the question asks for — g/h and g/day are NOT interchangeable without converting.

Worked example

Comparing weathering rates of three rock types

[3]
Three rock samples — sandstone, limestone and granite, each starting with the same mass — are submerged in dilute hydrochloric acid for 24 hours. Mass loss recorded: sandstone 4.8 g, limestone 12.0 g, granite 1.2 g. (a) Calculate the average rate of weathering, in g/h, for each rock. (b) Explain which rock type weathered fastest and why.

Worked example

Acid rain damage to a limestone statue

[3]
A limestone statue is smooth when installed but after 50 years in a heavily polluted city its surface is pitted and crumbling. (a) Identify the type of weathering shown. (b) Explain how acid rain causes this damage, referring to calcium carbonate.

Common mistake

Describing erosion when the question asks about weathering, or vice versa — e.g. writing 'the rock is worn away and carried down the river' when asked to define weathering.

Consequence: The definition mark is not awarded, because movement/transport is the defining feature of EROSION, not weathering.

Fix: Weathering breaks rock apart IN PLACE. Only call it erosion once an agent (water, wind, ice, gravity) actually MOVES the fragments away from where they formed.

Describing freeze-thaw weathering

When a question names the exact terms it wants back — e.g. 'expansion', 'pressure', 'fracture' — build the answer as a chain: water enters the crack → freezes below 0°C → ICE EXPANDS (~9% more volume than liquid water) → this exerts PRESSURE on the crack walls → repeated cycles widen the crack until the rock FRACTURES. Missing any one of the named keywords typically costs a mark even if the general idea is correct.

Frequently confused

Concept AConcept BThe distinction that matters
WeatheringErosionWeathering breaks rock apart WHERE IT SITS; erosion is the actual MOVEMENT of those broken fragments elsewhere. No transport, no erosion.
Mechanical weatheringChemical weatheringMechanical weathering changes only the SIZE/SHAPE of fragments (same minerals, smaller pieces); chemical weathering changes the actual MINERAL COMPOSITION through reactions like dissolving or oxidation.

Mnemonic

Weathering Waits, Erosion Escapes

Weathering happens in place ('waits'); erosion involves the material actually escaping/moving away.

Acid rain vs. real limestone monuments

The Taj Mahal's white marble has visibly yellowed and pitted from sulfur dioxide pollution produced by nearby industry and traffic, and the Parthenon in Athens has lost more surface detail to 20th-century smog than in the previous 2,000 years combined. This is exactly the acid-rain-on-limestone/marble mechanism examiners test in statue and building questions.

Key takeaways

  • Weathering breaks rock down in place; erosion moves the debris away — never merge the two definitions.
  • Mechanical weathering (freeze-thaw, exfoliation, abrasion) changes size/shape only; chemical weathering (acid rain, oxidation) changes the rock's chemistry.
  • Rate calculations: always divide mass loss by the exact TIME stated in the question, and give the correct units (g/h, g/day, etc.).
  • Limestone (calcium carbonate) is far more vulnerable to acid weathering than granite or sandstone because CaCO₃ reacts directly with acids.

The Solar System

The Solar System is the Sun plus everything gravitationally bound to it — eight planets, dwarf planets, moons, asteroids, comets and meteoroids, all held in orbit by the Sun's gravity.

  • Inner (terrestrial) planets — Mercury, Venus, Earth, Mars — are small, rocky, dense, and lie close to the Sun.
  • Outer (gas/ice giant) planets — Jupiter, Saturn, Uranus, Neptune — are large, low-density, made mostly of hydrogen, helium and ices, with ring systems and many moons.
  • The asteroid belt lies between Mars and Jupiter, roughly marking the boundary between the two planet families.
  • Closer planets orbit faster and have shorter years — Mercury completes an orbit in 88 Earth days, Neptune takes 165 Earth years.
Solar System
The Sun together with all objects gravitationally bound to it — planets, dwarf planets, moons, asteroids and comets.
Planet
An object that orbits the Sun, is roughly spherical due to its own gravity, and has cleared its orbital neighbourhood of other debris.
Dwarf planet
An object that orbits the Sun and is roughly spherical, but has NOT cleared its orbital neighbourhood (e.g. Pluto, Ceres).
Asteroid
A small, rocky object orbiting the Sun, mostly found in the asteroid belt between Mars and Jupiter.
Comet
A small icy body that develops a glowing coma and tail as it approaches the Sun and its ices vaporise.
Astronomical Unit (AU)
The average distance from Earth to the Sun, about 150 million km, used as a convenient unit for Solar System distances.

Layout of the Solar System

Not to scale — inner rocky planets sit close to the Sun, outer gas/ice giants lie far beyond the asteroid belt.

SunMercuryVenusEarthMarsAsteroid BeltJupiterSaturnUranusNeptune

Mnemonic

My Very Educated Mother Just Served Us Nachos

Order of the planets outward from the Sun: Mercury, Venus, Earth, Mars, Jupiter, Saturn, Uranus, Neptune (Pluto dropped — it's a dwarf planet, not one of the eight).

Inner (terrestrial) vs outer (gas/ice giant) planets

FeatureInner terrestrial planetsOuter gas/ice giants
CompositionRock and metalHydrogen, helium and ices, with a small rocky/icy core
DensityHigh — rocky and denseLow — mostly gas
SizeSmallLarge
Distance from SunClose (Mercury–Mars)Far (Jupiter–Neptune)
Number of moonsZero to twoMany (dozens each)
RingsNoneYes — Saturn's are most visible

Common mistake

Calling Pluto 'the ninth planet'.

Consequence: Pluto was reclassified as a dwarf planet in 2006 because it hasn't cleared its orbital neighbourhood of other debris — stating it as a full planet is a factual error, not just outdated terminology.

Fix: The eight official planets stop at Neptune; Pluto, Ceres and Eris are classed as dwarf planets.

Missions that mapped the outer Solar System

Voyager 1 and 2 (launched 1977) are the only spacecraft to have flown past all four gas/ice giants, and Voyager 1 is now the most distant human-made object — over 24 billion km from Earth and still transmitting data. Closer to home, the Perseverance rover on Mars searches for evidence of past water and rock weathering on another planet — the same processes covered earlier in this topic, just happening somewhere else.

Key takeaways

  • Order of planets from the Sun: Mercury, Venus, Earth, Mars, Jupiter, Saturn, Uranus, Neptune.
  • Inner planets are small, rocky and dense; outer planets are large, gas/ice-dominated and less dense.
  • Pluto is a dwarf planet, not the 9th planet — it hasn't cleared its orbital neighbourhood.
  • The asteroid belt (between Mars and Jupiter) marks the rough boundary between the two planet families.

Phases of the Moon and Eclipses

The Moon produces no light of its own — we only ever see reflected sunlight. Half of the Moon is lit at any moment (just like half of Earth is in daylight at any moment). Phases arise purely because the Moon orbits Earth, so the fraction of its lit half that we can see from Earth changes over roughly 29.5 days.

  • Waxing means the visible lit fraction is increasing; waning means it's decreasing.
  • Crescent = less than half the visible disc is lit; gibbous = more than half is lit.
  • An eclipse only happens when Sun, Earth and Moon line up almost exactly — rare, because the Moon's orbit is tilted about 5° relative to Earth's orbital plane.
  • Solar eclipse: Moon passes directly between Sun and Earth (only possible at new moon). Lunar eclipse: Earth passes directly between Sun and Moon (only possible at full moon).
New Moon
The Moon sits between Earth and Sun; its lit side faces away from Earth, so it's invisible (or a thin sliver at most).
Full Moon
Earth sits between Sun and Moon; the Moon's fully lit side faces Earth.
Solar eclipse
The Moon passes directly between the Sun and Earth, casting its shadow onto Earth — Sun-Moon-Earth alignment, only at new moon.
Lunar eclipse
Earth passes directly between the Sun and Moon, casting Earth's shadow onto the Moon — Sun-Earth-Moon alignment, only at full moon.
Umbra
The full, darkest part of a shadow, where the light source is completely blocked.
Penumbra
The partial, lighter part of a shadow, where the light source is only partly blocked.

The Moon phase cycle

The Moon is always half-lit — phases change only because our viewing angle from Earth changes as the Moon orbits.

New MoonWaxing CrescentFirst QuarterWaxing GibbousFull MoonWaning GibbousLast QuarterWaning Crescent

Solar and lunar eclipse geometry

Solar eclipse: Moon's shadow falls on Earth. Lunar eclipse: Earth's shadow falls on the Moon.

SunMoonEarthUmbraPenumbra

Common mistake

Saying Moon phases are caused by 'Earth's shadow falling on the Moon'.

Consequence: This describes a LUNAR ECLIPSE, not ordinary phases, and is marked wrong even with a plausible-looking diagram.

Fix: Phases are caused by the changing ANGLE from which we view the permanently half-lit Moon as it orbits Earth — Earth's shadow plays no part in everyday phases.

State the alignment order explicitly

Eclipse questions are graded on getting the alignment order exactly right. Solar eclipse = Sun–Moon–Earth (Moon's shadow hits Earth, new moon only). Lunar eclipse = Sun–Earth–Moon (Earth's shadow hits Moon, full moon only). Write the three-body order out rather than just naming 'solar' or 'lunar' — mark schemes often reserve a mark specifically for the correct order.

Frequently confused

Concept AConcept BThe distinction that matters
Solar eclipseLunar eclipseSolar eclipse = Moon blocks the Sun as seen from Earth (Moon's shadow on Earth, new moon only); lunar eclipse = Earth blocks sunlight from reaching the Moon (Earth's shadow on Moon, full moon only).

Key takeaways

  • The Moon produces no light of its own — every phase is reflected sunlight seen from a changing angle as the Moon orbits Earth.
  • New Moon → Waxing Crescent → First Quarter → Waxing Gibbous → Full Moon → Waning Gibbous → Last Quarter → Waning Crescent, roughly a 29.5-day cycle.
  • Solar eclipses need Sun-Moon-Earth alignment at new moon; lunar eclipses need Sun-Earth-Moon alignment at full moon.
  • Eclipses aren't monthly because the Moon's orbit is tilted about 5° to Earth's orbital plane — perfect alignment is rare.

Seasons and the Earth's Tilt

Earth's axis is tilted at 23.5° from vertical relative to its orbital plane, and this tilt stays pointing in the SAME fixed direction in space throughout the year — it does not wobble to follow the orbit. As Earth travels around the Sun, that fixed tilt means different hemispheres receive more direct sunlight at different points in the orbit, producing seasons.

  • Direct (steep-angle) sunlight concentrates the same amount of energy over a SMALLER surface area — warmer conditions.
  • Oblique (shallow-angle) sunlight spreads the same energy over a LARGER surface area — cooler conditions.
  • June solstice: Northern Hemisphere tilted toward the Sun → NH summer, SH winter. December solstice: the reverse.
  • March/September equinoxes: neither hemisphere tilted toward or away from the Sun → roughly equal day and night everywhere.

Earth's tilt and the seasons

The 23.5° tilt stays pointed the same way in space all year — only Earth's position in orbit changes.

23.5° tiltJune solsticeSeptember equinoxDecember solsticeMarch equinox

Common mistake

Explaining seasons as 'Earth is closer to the Sun in summer'.

Consequence: This is factually backwards for the Northern Hemisphere — Earth is actually closest to the Sun in early January, during NH winter — and scores zero for the explanation mark.

Fix: Seasons are caused by the TILT of Earth's axis changing which hemisphere receives more direct/concentrated sunlight, not by orbital distance.

Explain using energy-per-area, not just 'more sunlight'

Direct rays hit a hemisphere at a steeper angle and concentrate their energy over a SMALLER area (warmer); oblique rays spread the same energy over a LARGER area (cooler). Naming 'tilt' alone without this angle/area reasoning usually earns only partial credit on 'explain' questions.

Key point

Earth's axial tilt (23.5°) stays pointing in the same fixed direction in space all year — it's the CHANGING ANGLE of sunlight hitting each hemisphere as Earth orbits, not distance from the Sun, that causes seasons.

Key takeaways

  • Axial tilt = 23.5°, fixed in direction throughout the year — only Earth's orbital position relative to the Sun changes.
  • Solstices (June/December): one hemisphere tilted maximally toward or away from the Sun — longest/shortest days.
  • Equinoxes (March/September): neither hemisphere tilted toward the Sun — roughly 12 hours day and night everywhere.
  • Distance from the Sun barely changes and is NOT the cause of seasons — the angle of incoming sunlight is.

Structure of the Earth

Earth is made of four main layers, distinguished by composition and physical state. Temperature and pressure both increase with depth, which is why the inner core stays solid despite being the hottest layer — the immense pressure prevents it from melting.

  • Crust: thin, rigid, outermost layer — oceanic crust is thinner and denser (basalt); continental crust is thicker and less dense (granite).
  • Mantle: thick layer of solid rock that can flow very slowly over millions of years due to heat — this slow convection drives the movement of tectonic plates above it.
  • Outer core: liquid iron and nickel; convection currents here generate Earth's magnetic field.
  • Inner core: solid iron and nickel, kept solid by extreme pressure despite being the hottest part of the planet.
Lithosphere
The rigid outer shell of Earth made of the crust plus the uppermost part of the mantle, broken into tectonic plates.
Asthenosphere
The weaker, more plastic layer of the upper mantle beneath the lithosphere, over which tectonic plates slowly move.
Tectonic plate
A large, rigid section of the lithosphere that moves slowly over the asthenosphere, driven by mantle convection.

Earth's internal structure

Layers are defined by composition and physical state, not just depth.

CrustMantleOuter CoreInner Core

Earth's layers at a glance

LayerStateApprox. thicknessMain composition
CrustSolid (rigid)5–70 kmSilicate rock — basalt (oceanic), granite (continental)
MantleSolid but flows slowly over time~2900 kmSilicate rock rich in iron and magnesium
Outer coreLiquid~2200 kmIron and nickel
Inner coreSolid~1220 km (radius)Iron and nickel

Common mistake

Describing the mantle as 'liquid rock' or 'magma'.

Consequence: Examiners mark this wrong — the mantle is SOLID rock that flows extremely slowly over millions of years, not molten liquid like lava.

Fix: Only the outer core is liquid. The mantle is solid but capable of slow plastic flow (convection currents), which drives plate movement.

Key takeaways

  • Four layers by depth: crust (thin, solid), mantle (thick, solid but slowly flowing), outer core (liquid iron-nickel), inner core (solid iron-nickel, kept solid by pressure despite the highest temperature).
  • Lithosphere = crust + rigid uppermost mantle, broken into moving tectonic plates.
  • The mantle is SOLID, not molten — don't confuse it with magma/lava.
  • Outer core convection currents generate Earth's magnetic field.

Rocks and the Rock Cycle

Rocks are grouped into three families based on HOW they form, and the rock cycle links all three together — over geological time, any rock type can transform into either of the other two.

  • Igneous rock forms when magma (underground) or lava (at the surface) cools and crystallises — fast cooling gives fine crystals, slow cooling gives coarse crystals.
  • Sedimentary rock forms when weathered/eroded sediment is compacted and cemented together, usually in distinct layers (strata), and often contains fossils.
  • Metamorphic rock forms when an existing rock is transformed by heat and/or pressure WITHOUT melting — if it does melt, it becomes magma and starts the cycle over as igneous.
Magma
Molten rock beneath Earth's surface.
Lava
Molten rock that has reached Earth's surface, e.g. through a volcanic eruption.
Sediment
Loose fragments of weathered and eroded rock, transported and deposited by water, wind or ice.
Compaction
Sediment layers being squeezed together under the weight of overlying layers, squeezing out water and air.
Cementation
Dissolved minerals crystallising between sediment grains, binding them together into solid rock.

The rock cycle

No fixed starting point — any rock type can become either of the other two given the right conditions.

Igneous RockSedimentary RockMetamorphic RockMagma/LavaCooling and crystallisationWeathering, erosion, deposition, compaction, cementationHeat and pressureMelting

The three rock types

Rock typeHow it formsTypical textureExample
IgneousMagma or lava cools and crystallisesCrystalline; interlocking crystals (fine if cooled fast, coarse if cooled slowly)Granite, basalt
SedimentarySediment compacted and cemented together, often underwater in layersLayered (strata), often with fossils/visible grainsSandstone, limestone
MetamorphicExisting rock changed by heat and/or pressure without meltingOften banded/foliated, denser than the original rockMarble (from limestone), slate (from mudstone)

Naming every process on a rock-cycle path

Rock cycle questions often ask you to trace ONE path (e.g. 'describe how a metamorphic rock could eventually become a sedimentary rock'). Name every process on that path in order — weathering, erosion, deposition, compaction, cementation — don't jump straight from one rock name to another without the linking processes.

Key takeaways

  • Igneous = cooling and crystallising of magma/lava.
  • Sedimentary = weathered/eroded sediment that gets compacted and cemented, usually in layers.
  • Metamorphic = existing rock changed by heat and/or pressure WITHOUT melting — if it melts, it becomes magma and restarts the cycle as igneous.
  • The rock cycle has no fixed starting point — any rock type can transform into either of the other two given enough time and the right conditions.

Quick Reference

Earth and Space Science — everything on one page

Formulas

  • units g/h or g/day — always match the unit the question asks for

Key facts

Earth's axial tilt
23.5°
Moon's synodic (phase) cycle
≈29.5 days
Number of official planets
8 (Pluto = dwarf planet)
Thickness of Earth's crust
5–70 km
Radius of Earth's inner core
≈1220 km

Mnemonics

  • My Very Educated Mother Just Served Us NachosPlanet order from the Sun: Mercury, Venus, Earth, Mars, Jupiter, Saturn, Uranus, Neptune
  • Weathering Waits, Erosion EscapesWeathering breaks rock down in place; erosion is the fragments actually moving away

Don't confuse

  • Weathering vs Erosion: in place (weathering) vs actually moved away (erosion)
  • Solar eclipse vs Lunar eclipse: Moon blocks Sun — Sun-Moon-Earth, new moon — vs Earth blocks Sun from Moon — Sun-Earth-Moon, full moon
  • Mantle vs Outer core: mantle is solid rock that flows very slowly; outer core is genuinely liquid metal

Command terms

Define:
give the precise accepted meaning only — no example needed unless asked
Describe:
state what happens/what it looks like, step by step, no reasons required
Explain:
give the reason or mechanism — state the WHY, not just the what
Identify:
name it briefly — one word or phrase is enough
Calculate:
show working and give a final numerical answer with correct units

Exam checklist

  • Have I said whether a process happens IN PLACE (weathering) or involves MOVEMENT (erosion)?
  • Did I correctly name mechanical, chemical or biological weathering for the example given?
  • Rate calculations: did I divide by the exact time stated, with matching units?
  • Eclipse answers: did I state the full Sun-Moon-Earth or Sun-Earth-Moon alignment order?
  • Seasons: did I explain using the ANGLE of sunlight, not distance from the Sun?
  • Rock cycle: did I name every process (weathering, erosion, deposition, compaction, cementation, heat, pressure, melting) along the path asked about?
