MYP Year 3 Sciences — Ecology and Environment

24 min readStandardMajor unit — tested through Criterion A (Knowing & Understanding) and Criterion C (Processing/Evaluating) tasks, plus recurring pond/ecosystem stimulus questions in unit tests and on-screen assessments

Ecology is the study of how living things interact with each other and with the non-living parts of their surroundings — get that one distinction wrong (calling water 'biotic' because fish live in it) and you'll lose marks on almost every question in this unit. Energy pyramids, food webs, pollution, conservation — every subtopic here is the same relationship (organism ↔ environment) examined from a different angle, usually via a pond diagram.

Overview

Why this topic keeps repeating itself

Every subtopic here is secretly asking the same three questions: what is present (biotic/abiotic components), how does energy move through it, and what happens when something changes. If you can answer those three for any diagram — a pond, a desert, a forest — you can answer almost any exam question in this unit, because ecosystem questions are diagram questions wearing different biomes.

The shape of the chapter

Command terms this unit tests hardest

Command termWhat it demandsAOMark-earning move
Identifyname/select the correct component or factor from a diagram or listAO11 mark for the correct word only — no explanation needed or rewarded, so don't waste time justifying it
Describegive a detailed account of WHAT happens, not whyAO2marks go for accurate detail, not mechanism — save the 'why' for an Explain question
Explaingive a cause AND its effect, explicitly linkedAO2/AO3the second mark is almost always for the linking word ('because', 'which means', 'so that') — two unlinked facts score half marks
Distinguishstate the actual point of difference between two similar termsAO2defining both terms separately without contrasting them scores zero
Discusspresent multiple factors/sides with some evaluationAO3one-sided answers cap at half marks even if factually correct
Suggestapply science logically to an unfamiliar scenarioAO3no single 'correct' fact required — credit goes to a sensible, science-based justification

Key point

Abiotic vs biotic is the exam's favourite trap: rocks, water, sunlight, air and temperature are abiotic (non-living) even though living things depend on them constantly. If it was never alive, it's abiotic — full stop.

Ecosystems and Biomes

Levels of organisation

  • Population — all individuals of one species living in the same area at the same time, e.g. all the fish in a pond.
  • Community — all the different populations (all species) living and interacting in the same area, e.g. fish + water lilies + frogs + bacteria together.
  • Ecosystem — the community PLUS the abiotic (non-living) environment it interacts with: water, rocks, sunlight, mud, air.
  • Biome — a large-scale region defined by climate and dominant vegetation (e.g. tropical rainforest, desert, tundra) containing many similar ecosystems.

Every 'describe the pond ecosystem' question is really testing whether you can sort a list into biotic and abiotic, then explain how the two groups depend on each other — that dependency is where the marks live, not the sorting itself.

Ecosystem
A community of living organisms interacting with each other and with the non-living (abiotic) components of their environment.
Biotic component
Any living or once-living part of an ecosystem.plants, animals, fungi, bacteria, and dead organic matter
Abiotic component
Any non-living physical or chemical factor in an ecosystem.water, rocks, sunlight, temperature, air, pH, soil minerals
Habitat
The specific physical place where an organism lives within an ecosystem.e.g. under a rock, in the mud, on a lily pad
Biome
A large geographic region characterised by a particular climate and community type.e.g. desert, taiga, coral reef

A pond ecosystem: sorting biotic from abiotic

Same pond, two different lenses: what's alive (biotic) and what supports life without being alive (abiotic).

water liliesfrogfishinsectssunlightwaterrocksmudair

Worked example

Identifying the independent variable in a light experiment

[2]
A student places a potted plant under a lamp and measures the number of new leaves that grow over one week. The student keeps the soil type and amount of water the same throughout. (a) Identify the independent variable in this investigation. [1] (b) Explain why keeping the soil type and amount of water the same is important in this investigation. [1]

Losing the second mark on 'effects of removing sunlight'

For a question like 'describe the effects on living components if sunlight were permanently removed', most students write only 'the plants would die' and stop.

Consequence: That answer only earns 1 mark out of 2 — the knock-on effect on consumers isn't stated.

Fix: Follow the chain to the next living thing: no sunlight → water lilies can't photosynthesise → they die and stop producing food/oxygen → frogs and fish lose their food source and oxygen supply → their populations decline too. State BOTH the direct effect on producers AND the indirect effect on consumers.

Classification questions want exact matching

When sorting a list (e.g. fish, water, rocks, lily pads, sunlight, air, bacteria) into biotic/abiotic, write each word under the heading exactly as given — don't paraphrase. Markers tick off specific words against a scheme; 'plants' when the list says 'lily pads' can cost the mark. Bacteria and dead matter count as biotic even though they're not 'plants or animals'.

Key takeaways

  • Ecosystem = community (all species) + abiotic environment they interact with; keep the levels in order: population → community → ecosystem → biome.
  • Biotic = ever alive (including bacteria, dead leaves); abiotic = never alive (water, rocks, air, sunlight, temperature).
  • 'Effects of removing X' questions need a chain: effect on producers, THEN the knock-on effect on consumers, for full marks.

Energy Flow and Pyramids

Energy only goes one way

Energy enters an ecosystem as sunlight, gets captured by producers through photosynthesis, and then flows in one direction only — through consumers, eventually to decomposers — before being lost as heat. Unlike nutrients (carbon, nitrogen), energy is never recycled; every joule lost as heat from respiration is gone for good, which is why ecosystems need a constant input of sunlight.

  • Trophic level 1 = producers (make their own food, e.g. plants, algae — always the base of every pyramid).
  • Trophic level 2 = primary consumers/herbivores (eat producers).
  • Trophic level 3 = secondary consumers (eat primary consumers).
  • Trophic level 4 = tertiary consumers/top predators (eat secondary consumers).
  • Decomposers (bacteria, fungi) act at every level, breaking down dead matter and waste and returning nutrients — not energy — to the abiotic environment.

The 10% rule

Only about 10% of the energy at one trophic level is transferred to the next; roughly 90% is lost as heat (respiration), movement, or in unconsumed/undigested parts.

— trophic level number
Memorise

This is why food chains rarely exceed 4-5 trophic levels — there simply isn't enough energy left to support a fifth.

The 90% that doesn't transfer isn't 'wasted' — it's the unavoidable cost of staying alive (respiration, movement, growing body parts the next consumer won't eat, like roots or bones).

Energy pyramid for a grassland food chain

Energy pyramids are ALWAYS upright — never inverted — because energy is always lost, never gained, moving up.

Producers (grass) — 10,000 kJPrimary consumers (grasshoppers) — 1,000 kJSecondary consumers (frogs) — 100 kJTertiary consumers (snakes) — 10 kJ

Worked example

Comparing producer-to-consumer ratios across ecosystems

[2]
An ecologist recorded: Forest — producers 5000, primary consumers 800. Grassland — producers 3000, primary consumers 600. Pond — producers 2000, primary consumers 400. Desert — producers 500, primary consumers 100. (a) Calculate the ratio of producers to primary consumers for each ecosystem. Describe the pattern you see. [2]

Assuming all pyramids are the same shape

Students assume every ecological pyramid narrows smoothly upward like the energy pyramid.

Consequence: A pyramid of NUMBERS can actually be inverted — e.g. one large oak tree (1 producer) supporting thousands of caterpillars (primary consumers) gives a wide top, narrow base.

Fix: Only the pyramid of ENERGY is always upright, because energy transfer always loses roughly 90% per level — number and biomass pyramids can take irregular shapes depending on organism size.

Key point

Whatever shape the numbers or biomass pyramid takes, energy always decreases going up — that's the one pyramid rule examiners never let you get wrong.

Key takeaways

  • Energy flows one way (sun → producers → consumers → decomposers → heat lost); it's never recycled, unlike nutrients.
  • Only ~10% of energy transfers between trophic levels; ~90% is lost as heat, movement and undigested material — this caps food chains at about 4-5 levels.
  • Energy pyramids are always upright; number/biomass pyramids can occasionally be inverted.

Environmental Change and Pollution

Natural change vs human-caused change

  • Natural environmental change — volcanic eruptions, wildfires, floods, seasonal cycles — ecosystems have evolved some resilience to these.
  • Human-caused change — deforestation, urbanisation, industrial emissions, agricultural runoff — usually happens far faster than ecosystems can adapt to, which is why it causes more dramatic biodiversity loss.
  • Pollution is the introduction of a harmful substance or energy (heat, noise, light) into the environment at a rate faster than it can be broken down, diluted or absorbed safely.

Almost every pollution question is secretly asking you to trace a chain reaction: pollutant enters environment → it changes an abiotic factor (oxygen level, temperature, pH, light) → that change harms a biotic population, directly or through the food chain. Structure your answer as that chain and you'll hit both marks on an 'explain' question.

Pollutant
Any substance or form of energy released into the environment that causes harm to living organisms or damages a habitat.
Bioaccumulation
The build-up of a toxic substance (e.g. pesticide, heavy metal) in an individual organism's body over its lifetime because it cannot be excreted or broken down.e.g. DDT accumulating in a bird's fat tissue over years
Biomagnification
The increasing concentration of a toxin at each successive trophic level as predators eat many contaminated prey.top predators end up with the highest, most dangerous concentrations
Eutrophication
Excess nutrients (e.g. fertiliser nitrates/phosphates) entering water causing algal overgrowth, which later dies, decomposes, and depletes dissolved oxygen, killing aquatic life.
Global warming
The enhanced, human-accelerated increase in Earth's average temperature caused mainly by excess greenhouse gases (CO2, methane) from burning fossil fuels.

Types of pollution

TypeCommon sourceTypical pollutantMain effect on organisms
Air pollutionVehicle exhaust, factories, power plantsCarbon monoxide, sulfur dioxide, particulatesRespiratory damage; sulfur dioxide causes acid rain, damaging plants and acidifying water
Water pollutionFertiliser/sewage runoff, industrial waste, oil spillsNitrates/phosphates, heavy metals, oilEutrophication, oxygen depletion, poisoning of aquatic life, bioaccumulation up the food chain
Soil pollutionPesticides, industrial waste, landfill leachatePesticide residues, heavy metals, plasticsKills soil organisms/decomposers, contaminates crops, reduces soil fertility
Thermal pollutionPower station cooling water, warmer climateHeated water dischargeLowers dissolved oxygen, raises metabolic demand of aquatic organisms, can cause population decline

Worked example

Explaining a temperature-driven fish decline

[2]
The diagram shows a pond ecosystem with fish, aquatic plants, rocks, sunlight, and water. Explain how a significant increase in water temperature could lead to a decline in the fish population. [2]

Frequently confused

Concept AConcept BThe distinction that matters
Greenhouse effectGlobal warmingThe greenhouse effect is a natural, essential process (gases trapping heat to keep Earth warm enough for life); global warming is the enhanced, human-caused increase in that effect from excess CO2/methane — one is natural and necessary, the other is the harmful acceleration of it.

Lake Erie's algal blooms

Fertiliser runoff from farms around the Great Lakes has repeatedly triggered massive algal blooms in Lake Erie — the algae grow explosively on the extra nitrates/phosphates, then die and are decomposed by bacteria that consume huge amounts of dissolved oxygen, creating 'dead zones' where fish suffocate. It's eutrophication playing out at the scale of an entire lake, and it's the textbook example examiners expect you to explain step by step.

Key takeaways

  • Trace pollution effects as a chain: pollutant → abiotic change (oxygen, temperature, pH) → biotic harm — both marks of an 'explain' question live in that chain.
  • Bioaccumulation builds up in one organism; biomagnification increases concentration UP the food chain — top predators suffer worst.
  • Greenhouse effect is natural and necessary; global warming is the human-enhanced, harmful version of it.

Biodiversity and Conservation

Three levels of biodiversity

  • Species diversity — the number and variety of different species in an area.
  • Genetic diversity — the variety of genes/alleles within a single species; higher genetic diversity means a population is more likely to survive disease or environmental change, since some individuals will carry resistant traits.
  • Ecosystem diversity — the variety of different ecosystems/habitats within a region.

Biodiversity matters because it makes ecosystems more resilient — the more species and genetic variety present, the more likely SOME organisms survive a disturbance (disease, drought, new predator) and the ecosystem recovers rather than collapses.

Biodiversity
The variety of life in an area, measured at species, genetic and ecosystem level.
Endangered species
A species whose population has declined so severely that it is at high risk of extinction in the near future.
Extinction
The permanent disappearance of a species from Earth — no living individuals remain.
Conservation
The active protection, management and sustainable use of species and ecosystems to prevent their loss.different from preservation, which means leaving an area completely untouched

Mnemonic

HIPPO

The five biggest threats to biodiversity, roughly in order of impact: Habitat destruction, Invasive species, Population growth (human), Pollution, Overharvesting (hunting/fishing/logging).

Threats matched to conservation strategies

ThreatExampleConservation strategy that targets it
Habitat destructionDeforestation for farmland/loggingProtected areas / national parks; reforestation programmes
Invasive speciesNon-native predator/plant outcompeting localsControlled removal/culling programmes; biosecurity/quarantine laws
OverharvestingOverfishing, poachingFishing quotas, hunting bans, CITES trade restrictions
PollutionAgricultural runoff, plastic wasteLegislation limiting emissions/discharge; clean-up and monitoring programmes
Small/isolated populationsFragmented habitat leaves too few individualsCaptive breeding and reintroduction programmes; wildlife corridors linking fragments

Explain vs Identify on conservation questions

'Identify a conservation strategy' needs only the named strategy (e.g. 'captive breeding') for 1 mark. 'Explain how [strategy] helps' needs the MECHANISM plus the benefit — e.g. 'captive breeding increases population numbers in a controlled, predator-free environment before reintroduction, boosting genetic diversity and reducing extinction risk' — for full marks.

Key takeaways

  • Biodiversity has three levels — species, genetic, ecosystem — and genetic diversity is the one examiners most often find missing from answers.
  • HIPPO threats: Habitat loss, Invasive species, Population growth, Pollution, Overharvesting.
  • Conservation ≠ preservation: conservation allows sustainable, managed use; preservation means hands-off protection.

Habitats and Adaptations

Habitat, niche, and three types of adaptation

  • Habitat — the physical place an organism lives (e.g. a burrow, a lily pad, the desert floor).
  • Niche — the organism's specific ROLE in the ecosystem: what it eats, when it's active, how it interacts with other species; two species can share a habitat but not the exact same niche.
  • Structural adaptation — a physical body feature, e.g. a cactus's spines (reduced surface area = less water loss) or a camel's wide feet (spreads weight on sand).
  • Behavioural adaptation — an action, e.g. nocturnal activity in desert animals to avoid daytime heat, or migration to follow food/warmth.
  • Physiological adaptation — an internal body process, e.g. a camel tolerating large body-temperature swings without sweating, conserving water.
Habitat
The specific place within an ecosystem where a particular organism normally lives.
Niche
The functional role an organism plays in its ecosystem, including its interactions with other species and use of resources.
Adaptation
An inherited feature (structural, behavioural or physiological) that increases an organism's chance of survival and reproduction in its environment.

Structural adaptations of a desert-dwelling camel

Every labelled feature here is structural — a physical body part, not a behaviour.

wide flat feetsingle fat humplong eyelashesclosable nostrilsthin coat on legs, thick coat on back

Frequently confused

Concept AConcept BThe distinction that matters
HabitatNicheHabitat is WHERE an organism lives (the address); niche is WHAT it does there (the job) — two species can share a habitat (a pond) while occupying different niches (one eats algae, one eats insects).

Describing an adaptation with no survival link

Answering 'the camel has thick fur' or 'the cactus has spines' and stopping there.

Consequence: This only describes the feature — scores 0 or 1 out of a possible 2 marks because it hasn't explained WHY the feature helps the organism survive.

Fix: Always finish the sentence with the survival benefit: '...spines have a small surface area, which reduces water loss through transpiration, helping the cactus survive in low-rainfall conditions.' Feature + mechanism + benefit = full marks.

Key takeaways

  • Habitat = where; niche = role/job — don't conflate the two even though questions often use them in the same sentence.
  • Three adaptation types: structural (body part), behavioural (action), physiological (internal process) — identify which type before explaining it.
  • An adaptation answer only scores full marks once the survival benefit is stated, not just the feature.

Food Chains and Webs

From chains to webs

  • Producer — makes its own food via photosynthesis (always the start of every food chain).
  • Primary consumer / herbivore — eats producers only.
  • Secondary consumer / carnivore or omnivore — eats primary consumers.
  • Tertiary consumer / top predator — eats secondary consumers; usually has no natural predators of its own.
  • Decomposer — breaks down dead organisms and waste at every level, releasing nutrients back into the abiotic environment (this recycles matter, not energy).

A food chain is a single straight-line path (grass → rabbit → fox); a food web is what happens when you draw ALL the chains in an ecosystem overlapping, because almost every organism eats more than one thing and is eaten by more than one predator. Webs are more realistic — and more resilient, because losing one species doesn't necessarily collapse the whole system.

Consumer types and examples

CategoryDietPond example
Herbivore (primary consumer)Plants/producers onlyTadpole grazing on algae
Carnivore (secondary/tertiary consumer)Other animals onlyHeron eating fish
OmnivoreBoth plants and animalsSome fish species eating both insects and plant matter
DecomposerDead organic matter and wasteBacteria breaking down dead leaves in the mud

A pond food web

Follow any arrow: it always points FROM the organism being eaten TOWARD the one doing the eating.

Aquatic plantsAlgaeInsectsTadpolesSmall fishFrogsHeronsBacteria (decomposers)

Rabbit and fox populations over 8 years

The fox curve mirrors the rabbit curve but lags behind it by roughly a year — the classic predator-prey pattern.

YearPopulation (thousands)RabbitsFoxes

Worked example

Reading a predator-prey population graph

Rabbit and fox population sizes (thousands) over 8 years in a grassland: Year 1: rabbits 40, foxes 15. Year 2: rabbits 90, foxes 25. Year 3: rabbits 55, foxes 40. Year 4: rabbits 10, foxes 25. Year 5: rabbits 45, foxes 5. Year 6: rabbits 80, foxes 20. Year 7: rabbits 50, foxes 35. Year 8: rabbits 15, foxes 10. Identify the feeding relationship between rabbits and foxes. Explain how an increase in the rabbit population leads to a later change in the fox population.

Drawing food chain arrows backwards

Students draw the arrow from predator to prey (e.g. fox → rabbit) because that's the direction they're thinking 'eats'.

Consequence: This is marked as incorrect even if every organism named is correct, because the arrow convention specifically represents the direction of ENERGY flow.

Fix: The arrow always points FROM the organism being eaten TO the organism eating it: grass → rabbit → fox (energy flows from grass, into the rabbit that eats it, into the fox that eats the rabbit).

Roles and interactions, not just a list

A question asking you to 'describe the roles of biotic and abiotic components and explain how ONE interaction sustains life' wants: (1) what producers/consumers/abiotic factors each contribute, AND (2) one specific linked interaction, e.g. 'sunlight and water allow aquatic plants to photosynthesise, releasing oxygen that fish need for respiration' — naming the components without connecting them in a mechanism earns only partial credit.

Key takeaways

  • Food chain = single path; food web = all overlapping chains in an ecosystem, which makes webs more resilient to losing one species.
  • Arrows always point from eaten organism to eater — this represents energy flow, not 'who is dominant'.
  • Predator-prey graphs cycle with a time lag: prey population peaks first, predator population peaks shortly after, then both crash in sequence.

Quick Reference

Ecology and Environment — everything on one page

Formulas

  • ~10% transferred per trophic level; ~90% lost as heat/movement/waste

Key facts

Energy transferred per trophic level
~10%
Energy lost per trophic level (heat/movement/waste)
~90%
Typical maximum trophic levels in a chain
4-5

Mnemonics

  • HIPPOHabitat loss, Invasive species, Population growth, Pollution, Overharvesting — the five biggest biodiversity threats

Don't confuse

  • Biotic vs Abiotic: Biotic = ever alive (plants, animals, bacteria, dead matter); abiotic = never alive (water, rocks, sunlight, temperature)
  • Habitat vs Niche: Habitat is WHERE an organism lives; niche is WHAT role it plays there
  • Greenhouse effect vs Global warming: Greenhouse effect is natural and essential; global warming is the human-enhanced, harmful acceleration of it
  • Bioaccumulation vs Biomagnification: Bioaccumulation builds up within ONE organism over its life; biomagnification increases concentration UP the food chain between trophic levels
  • Conservation vs Preservation: Conservation allows sustainable, managed use of resources; preservation means leaving an area completely untouched

Command terms

Identify:
name only, no explanation needed or rewarded
Describe:
state WHAT happens in detail, no mechanism required
Explain:
cause + effect, LINKED — the link is usually the second mark
Suggest:
apply logic to an unfamiliar scenario, no single fixed answer

Exam checklist

  • Can you sort ANY list of pond/forest/desert items into biotic vs abiotic without hesitating?
  • Can you state the 10% rule and explain why food chains rarely exceed 4-5 levels?
  • Can you trace a pollution 'chain reaction' from pollutant → abiotic change → biotic harm?
  • Do you know all three levels of biodiversity (species, genetic, ecosystem) and the HIPPO threats?
  • Can you classify an adaptation as structural/behavioural/physiological AND state its survival benefit?
  • Do your food chain arrows point from eaten organism to eater, every time?
